Commercial and industrial powder mixer equipment and machines encompass a broad range of equipment designed to mix and blend dry:
Powder Mixer equipment and machines are designed to fit their specific mixing and blending application whether it be powder with powder, or liquid with powder, though different types of mixing and mixing processes can be used to mix the same two components together.
The proper powder mixer for an application requires knowledge of the different substances that are to be mixed together as well as their mixing properties. To determine the proper mixer for the application, the desired outcome or end product for the mixing application needs to be known.
Commercial and industrial mixers are mostly batch but some mixing applications, such as powder to liquid, can be continuous. Batch mixers take a certain amount (batch) of product and process it for a certain amount of time.
Once the product is processed, the batch is removed from the mixer and another batch can be placed in the mixer. Continuous mixers move the product through the mixer so that a continuous stream of mixed product is being discharged.
See also: Liquid Mixers
20 cubic foot 304 stainless steel mixer with paddle and sweep agitation. Center bottom discharge, 2" ID, with butterfly valve. Interlocked safety guarding. Internal dimensions: 60" in Length; 22" in Width; 30" in Depth.
OAD: 84" (L) x 30" (W) x 46" (H)
30 cu ft 316 S/S Vacuum rated, Jacketed 30 cu ft "V" blender with maximum density of 100 pounds per cubic foot. Full vacuum @ 15psi internal rating. Jacket rated to 30 psi and maximum temperature of 250 degree F. (Test pressure: Internal full vacuum to 23 psi, jacket 75 psi). Two 18" diameter charge ports. Discharge, 10" butterfly valve. 27" high pedestal legs. Has drive motor for a bar. Bar NOT included.
OAD: 168" L x 48" W x 112" H with legs
Amfec, Model 510, 7 ft³ (5 ft³ working capacity), 304 stainless steel, dual paddle mixer with pounds of product per hour – depending on materials and application. Equipped with dual mixing troughs and has inner dimensions of: 48" in Length; 26" in Width; 22" in Depth with flip up top safety guarding style cover and has dual 12" wide x ¼" thick stainless steel paddles on 2" OD shaft, with dual 5 Hp motor drives, tilt to dump operation and 30" discharge height. Control panel has start / stop push button controls. Mounted on (4) stainless steel legs.
OAD: 100" L x 57" W x 66" H
Patterson Kelley, Model 3 ft³, 304 stainless steel twin shell mixer. Rated up to 125 lbs per ft³ – depending on materials and application. Equipped with (2) 16" ID product ports, 26" long outer V-Walls and 12" long inner V-Walls, pin bar agitation powered by a ¾ hp drive and 6"ID discharge with 37" ground clearance. Shell powered by a ¾ Hp motor drive. Requires 80" ceiling clearance with a 21" swing radius / 42" swing diameter. Mounted on painted base frame.
OAD: 74"L x 41"W x 74"H
Patterson Kelly, Model 40 ft³, 304 stainless steel, twin shell mixer. Rated up to 65 lb/ft³ total. Equipped with (2) 18" ID product ports with bolt down covers, (2) 64" long side V-Walls, (2) 24" long inner V-Walls and liquid solids bar powered by a 15 Hp drive. 10" ID flanged discharge with 41" ground clearance. Shell powered by 5 Hp drive. Requires 145" ceiling clearance with 50" swing radius / 100" swing diameter. Mounted on heavy duty base frame.
OAD: 132"L x 48"W x 130"H
22 ft³, (20 ft³ working capacity), double ribbon mixer with pounds of product per hour – depending on materials and application. 304 stainless steel contact parts. Inner mixing chamber dimensions of 72" in Length; 24" in Width; 30" in Depth with a 18" straight wall. Equipped with flip up cover, lift out safety screens, 2½" OD motor shaft, 1½" wide x ¼" thick (outer) and 2" wide x ¼" thick (inner) stainless steel ribbons. 8" x 8" bottom discharge with 62" floor clearence and Eriez magnetic separator. Mounted on stainless steel (4) leg frame.
OAD: 124"L x 34"W x 94"H
40 ft³, (35 ft³ working capacity), double ribbon mixer with pounds of product per hour – depending on materials and application. 304 stainless steel contact parts. Inner mixing chamber dimensions of 76" in Length; 32" in Width; 36" in Depth with a 21" straight wall. Equipped with sliding cover, lift out safety screens, 3" OD motor shaft, 1½" wide x ?" thick (outer) and 4¼" wide x ¼" thick (inner) stainless steel ribbons. 8" OD bottom discharge with 58" floor clearence and 15 Hp motor. Mounted on stainless steel (4) leg frame.
OAD: 162"L x 42"W x 102"H
Patterson Kelly, 10 ft³, 316 stainless steel, twin shell mixer with amount of product per hour – depending on materials and application. Equipped with (2) 18" ID product ports with bolt down covers, (2) 42" long side V-Walls, (2) 20" long inner V-Walls, 8" ID butterly valve discharge with 38" ground clearance. shell powered by 1 Hp drive. Requires 105" ceiling clearance with 32" swing radius / 64" swing diameter. Control panel has control switches and start, e-stop push buttons. Mounted on (4) leg stainless steel frame with safety guarding and locking caster.
OAD: 86" L x 63" W x 83" H
Morcos, Model RM1000, 40 ft³, (35 ft³ working capacity), double ribbon mixer with pounds of product per hour – depending on materials and application. 316L stainless steel contact parts. Inner mixing chamber dimensions of 76" in Length; 30" in Width; 33" in Depth. Equipped with flip up cover, lift out safety screens, 2¾" OD motor shaft, 2" wide x ¼" thick (outer) and 2½" wide x (¼)" thick (inner) stainless steel ribbons. 11" OD center bottom discharge with 50" floor clearence and 14.75 Hp motor. Mounted on stainless steel (4) leg frame with 41" wide x 143" long stainless steel platform set 70" off the ground with 36" high rails and a 7-step staircase.
OAD: 146"L x 109"W x 114"H
Morcos, Model RM2000, 65 ft³, (60 ft³ working capacity), double ribbon mixer with pounds of product per hour – depending on materials and application. 316L stainless steel contact parts. Inner mixing chamber dimensions of 90" in Length; 36" in Width; 40" in Depth. Equipped with flip up cover, lift out safety screens, 3½" OD motor shaft, 7" OD mixing shaft with 2¾" wide x (5/16)" thick (outer) and 2¾" wide x (5/16)" thick (inner) stainless steel ribbons. 11" OD center bottom discharge with 51" floor clearence and 20 Hp motor. Mounted on stainless steel (4) leg frame with 48" wide x 168" long stainless steel platform with an 8-step staircase.
OAD: 172"L x 124"W x 117"H
Morcos, Model RM2000, 65 ft³, (60 ft³ working capacity), double ribbon mixer with pounds of product per hour – depending on materials and application. 316L stainless steel contact parts. Inner mixing chamber dimensions of 90" in Length; 36" in Width; 40" in Depth. Equipped with flip up cover, lift out safety screens, 3½" OD motor shaft, 7" OD mixing shaft with 2¾" wide x (5/16)" thick (outer) and 2¾" wide x (5/16)" thick (inner) stainless steel ribbons. 11" OD center bottom discharge with 51" floor clarence and 20 Hp motor. Mounted on stainless steel (4) leg frame with 48" wide x 168" long stainless steel platform with an 8-step staircase.
Morcos, Model RM1000, 35 ft³, (30 ft³ working capacity), double ribbon mixer with pounds of product per hour – depending on materials and application. 316L stainless steel contact parts. Inner mixing chamber dimensions of 71" in Length; 28" in Width; 31" in Depth. Equipped with flip up cover, lift out safety screens, 2¾" OD motor shaft, 2" wide x ¼" thick (outer) and 2½" wide x (¼)" thick (inner) stainless steel ribbons. 11" OD center bottom discharge with 50" floor clearence and 12.3 Hp motor. Mounted on stainless steel (4) leg frame with 40" wide x 133" long stainless steel platform set 67" off the ground with 36" high rails and a 7-step staircase.
OAD: 136"L x 103"W x 109"H
