Home » Feeder » Outserter
2-head rotary hot melt outserter capable of up to 100 cycles per minute. Product size: (1 1/2" – 6") x (1 1/2" – 8"). Features 3 1/2"L pick & place arms, 27"L worm screw in feed, 36"L product magazine, (40" – 52") high product placement, sensor for presence, Equipped with Nordson hot melt glue system, Nordson time interval control, hand crank for height adjustment, barrier guarding with electrical interlocks, and sensor for container presence. Mounted on painted steel frame with casters. Designed to be mounted above conveyor.
OAD: 63"L x 50"W x 86"H
Automatic hot melt glue coupon outserter (top placer) rated up to 600ppm – depending on materials and application. Container size range: 1/2" to 5 1/8" in diameter. Equipped with four head rotary vacuum pick & place, 88"L coupon magazine with a chain pusher for coupons (1 1/2" – 3 1/2")W by (1 1/8" – 3 1/2")H, timing worm screw in feed, hot melt glue application system, integrated vacuum pump, A/B PLC and E-stops
OAD: 133"L x 61"W x 81"H
Automatic intermittent motion pick and place coupon feeder, capable of up to 70 cycles per minute for horizontal placements and 100 cycles per minute for vertical placements. Label size range in inches per magazine: Min-1" x 1", Max- 6" x 6". Equipped with Nordson 3100 dual hot melt glue system. Unit designed to automatically pick product from magazine and place horizontally on a conveyor. Will accept a variety of materials from single sheet paper stock to trays and packets.
MGS, Model RPP-4210, high speed (4) head rotary, pick and place coupon feeder. rated from 40 to 600 cycles per minute – depending on materials and application. Product size range: 1" to 7" in Width; 1" to 4" in Height and .06" to .75" thick with (4) heads. Equipped with (4) head rotary vacuum suction cup pick n place. Control panel has glue and vacuum on / off, fault reset, main drive on and e-stop push button controls, Mounted on "H" style base frame with safety guarding, leveling legs and statis light bar.
OAD: 40"L x 48"W x 76"H
MGS Model RPP-421T Top Sorter, high speed (4) head rotary, pick and place coupon feeder rated from 40 to 240 cycles per minute with timing screw and number of coupons – depending on materials and application. Product size range: 1.12" to 2" in Width; 1.12" to 2" in Height and .06" to .75" thick with (4) heads. Equipped with 90" long x 3/4" wide x 1" high single coupon magazine, (4) head rotary vacuum suction cup pick n place, 42" long feed screw, Nordson Problue hot melt glue system and vacuum pump. Control panel has bypass, run mode, glue and vacuum on / off, pitch small, large switches, barcode teach, fault reset, main drive on and e-stop push button controls, Mounted on "H" style base frame with safety guarding, casters, leveling legs and statis light bar.
OAD: 60" L x 48" W x 80" H
MGS Model Topserter ll, high speed, 4 head rotary, pick and place coupon feeder rated from 40 to 240 cycles per minute with timing screw – depending on materials and application. Product size range: 1.12" to 2" in Width; 1.12" to 2" in Height and .06" to .75" thick with 4 heads. Equipped with 36" long x 1-3/4" wide x 1" high single coupon magazine, 4-head rotary vacuum suction cup pick n place, 24" long worm screw, Nordson Problue hot melt glue system, vacuum pump, with seko guages and is hand crank adjustable. Control panel has A/B controller and A/B Panelview with on and e-stop push button controls, and statis light bar. Mounted on "H" style base frame with safety guarding, casters and leveling legs.
OAD: 84" L x 48" W x 64" H
Thiele, Model T7600, high speed rotary pick and place feeder. Rated from 50 – 250 placements per minute – depending on materials, application and machine configuration. Equipped with a 3¼" wide x 150" long Delrin style conveyor powered by a ½ hp drive, 32" long timing screw, 76" long single belt powered magazine, (6) head rotary pick and place, Piab vacuum system and reject station. Control panel with an AB PLC and touch screen display.
OAD: 150" L x 50" W x 98" H
Thiele, automatic, rotary feeder and hot glue system. Rated from 10 to 400 picks per minute – depending on materials, application and machine configuration. Product size: 1½" to 8" in Length; 1½" to 10" in Width. Equipped with 52" long magazine, with (4) head, rotary vacuum suction cup pick n place, Nordson hot melt system, worm screw feed, safety guarding, vacuum pump and motor drive. Control switches for vacuum on / off, glue on / off and push button start / stop / manual glue. Mounted on "H" style base frame.
OAD: 88" L x 48" W x 76" H
