Fitzpatrick Model FA10, 310 Liter or 11 cu ft stainless steel fluid bed dryer, recommended batch weights 190-470 lbs, or 86-214 KG. Fan rate 2200 cfm. Drying is achieved in a FitzAire sytstem as gas flows upward through the solids in the container. Gas is pulled through the bed, partially suspending the particles in the gas stream in a random, boiling motion. Drying occus as moisture is transferred from the particles to the fluidizing gas. Has one bowl and cart and second available at additional cost.
Fitzpatrick Model IR520, 316 stainless steel, pilot or small volume roller compactor, rated up to 150 kg of product per hour – depending on materials, application machine configuration and environment being run in. (2) screw feed design with 13" long x 9" wide x 10" deep ID stainless steel product hopper and rotary assist feeder to 3" OD x 12" long horizontal screw that eliminates vacuum dearation to 2" OD x 18" long vertical pre-compression screw that compresses product for more uniformity prior to feeding into the 2" wide x 8" OD groved product compaction rollers with roller force of 26.3 KN/CM and roll gap of 1mm to 6mm and has a capacity of 150 Kg an hour and powered by 5 Hp motor drive with noise level rating of 75 DB. Mobile control panel has A/B controller with parker panel view touch pad controls, A/B vari-speed controllers and e-stop. Mounted on (4) stainless steel legs with casters.
OAD: 48" L x 45" W x 70" H Roller Compactor 48" L x 32" W x 60" H Control Panel
Fitzpatrick Model 4LX10D, 316 stainless steel, free standing roller compactor, chilsonator with onboard stainless steel Fitzmill Model DKASO12 knife rotor hammer mill and the system is rated from 250 – 400 kg of product per hour – depending on materials, application, machine configuration and environment being run in. Equipped with 4" OD horizontal metering screw with 1 Hp motor drive that eliminates vacuum dearation to 4 OD" vertical pre-compression screw with 5 Hp motor drive, that compresses product for more uniformity prior to feeding into the 4" OD x 10" long face cored product compaction rollers with 7.5 Hp motor drive and bulk densities of feed from 10 to 100 lbs per cubic foot and roll force of 17.5 KN/cm with roll gap range of 1mm to 6mm. Has Fitzmill model DKASO12 knife rotor hammer mill with 10 Hp motor drive. Control cabinet with AMP meters and digital RPM indicators for rolls, verticle and horizontal screws, variable frequency speed controls with start and stop push buttons and e-stop. Mounted on (4) stainless steel legs.
OAD: 86"L x 74"W x 125"H
Fitzmill, Model DASO6, 316 stainless steel hammer mill with production rates per hour – depending on materials, application and machine configuration. Equipped with 12" long x 12" wide x 10" deep hopper, 3" diameter feed auger powered by ¾ Hp drive and (16) fixed knife / impact blades powered by 7½ Hp motor drive. Product discharge is 15½” long x 5½” wide with 36” floor clearance. Control panel has push button start and stop controls. Mounted on a stainless steel frame with casters. Used for precision grinding and controlled particle size reduction in pharmaceutical processing and other sanitary industries.
OAD: 42"L x 65"W x 72"H
Fitzmill, Model DASO6, stainless steel hammer mill with production rates per hour – depending on materials, application and machine configuration. Equipped with 24" long x 12" wide x 12" deep feed pan, 6" wide x 11" high feed throat and (16) fixed impact / knife blades powered by 7½ Hp motor drive. product discharge port is 16” long x 5” wide with 37” floor clearance. Mounted on (4) leg frame.
OAD: 42" L x 42" W x 70" H
Fitzmill Model DAS06, Stainless steel, particle reduction hammer mill with pounds of product per hour – depending on materials and application. Equipped with 12" long x 12" wide x 9" deep product hopper with safety grid, 4" OD x 18" long single auger feed screw powered by ¼ Hp motor drive with variable speed gearbox, (16) fixed, reversible stainless steel knife / impact blades and has 15" long x 6" wide product discharge port with safety grid and 36" floor clearence. Control panel has mill and feed screw start, stop push buttons. Mounted on (4) leg stainless steel frame with locking casters. Used for precision grinding and controlled particle size reduction in pharmaceutical processing and other sanitary industries.
OAD: 53"L x 42"W x 66"H
Fitzpatrick Model IR520, Stainless steel, medium volume, roller compactor chilsonator, with on board M5A Fitzmill hammer mill rated up to 150 kg of product per hour – depending on materials, application, machine configuration and environment being run in. 316 stainless steel construction. (2) screw feed design has 13" long x 9" wide x 10" deep ID stainless steel product hopper and rotary product assit to 3" OD x 12" long horizontal screw that eliminates vacuum dearation to 2" OD x 18" long vertical pre-compression screw that compresses product for more uniformity prior to feeding into the 5cm x 20cm or 2" wide x 8" OD groved product compaction rollers with a roller force of 26 KN/CM and roller gaps of 1mm to 6mm, powered by 5 Hp motor drive with noise level rating of 75 DB and has Fitzmill M5A hammer mill intergrated at discharge. Mounted on (4) leg frames with locking casters. Control panel with AB controller and touch screen HMI.
OAD: 35" L x 45" W x 85" H Chilsonator 45" L x 28" W x 63" H Control Cabinet
Fitzpatrick Model FA 150, 150 Kg, stainless steel fluid bed, batch dryer with maximum capacity of 150 Kg or 330.6 Ibs per batch or 8.6 cu ft total container volume with 1500 to 2000 cfm standard and up to 2500 cfm with volumes of product per hour – depending on materials and application. All 304 stainless steel construction with 2B finish exterior and # 4 finish interior and has 45" OD x 40-1/4" long stainless steel main chamber with 10Hp motor drive blower fan mounted above filtration and heating system with (4) 1/2" OD, NPT side drains and bottom lower transition discharge section with 1" bottom drain and (2) product carts on casters. HEPA filter gauges with chart recorder has magnehelic and pressure gauges. Remote above mounted climate control air handling system with dehumitifier, pre-heater, humidifier, final heater and Farr 30/30 95% HEPA filters to fluid bed dryer. NEMA 7 enclosure mounted on dryer with start, stop buttons for fan and agitator, electrical wiring and equipment designed for hazardous locations class l & ll division 1. Mounted on stainless steel frame with leveling legs.
Drying is achieved in a FitzAire system as gas flows upward through the solids in the container. Gas is pulled through the bed, partially suspending the particles in the gas stream in a random, boiling motion. Drying occurs as moisture is transferred from the particles to the fluidizing gas.
OAD: 96" L x 60" W x 102" H
Fitzmill, Model DAS012, Hammer mill with production rates per hour – depending on materials, application and machine configuration. All stainless steel contact parts. Equipped with 20" x 24" x 4" product feed pan, 13" x 5" feed throat, (32) fixed knife blades powered by 30 Hp drive and 16" x 14" product discharge with 42” floor clearance. Mounted on a (4) leg stainless steel frame with casters.Used to grind, de-lump, pulverize and process wet / dry products.
OAD: 60"L x 48"W x 75"H
Fitzpatrick, Model DM 1.5L X 8D, Chilsonator roller compactor mill, capable of processing from 35Kg to 135Kg (77 lbs to 297 lbs) of product per hour – depending on materials, application, environment and machine configuration. Stainless steel contact parts. Equipped with agitated, vertical screw feed product hopper with 1-1/2" OD product feed screw driven by variable speed motor drive, 1.5" L x 8" OD compaction rollers and hammer mill with (16) rotary knife blades for in air impact for harder compacts, and reduction screen (change part per application). Control cabinet has push button start, stop for main power, granulator, compactor, rollers, vertical and horizontal feed screws, with oil, air and amp gauges, panel purged and granulator on, start and stop push buttons. Mounted on stainless steel frame.
OAD: 54" L x 46" W x 72" H
Fitzmill, Model DASO6, stainless steel hammer mill with production rates per hour – depending on materials, application and machine configuration. Equipped with 26" long x 20" wide x 4" deep feed pan, 6" wide x 4" high feed throat and (16) fixed knife / impact blades powered by 7½ Hp motor drive. Product discharge port is 15” long x 5¾” wide with 29” floor clearance. Mounted on (4) leg frame.
OAD: 41" L x 34" W x 64" H
Fitzmill Model DAS06, 316 stainless steel, particle reduction, hammer mill with pounds of product per hour – depending on materials and application. Equipped with 12" long x 12" wide x 10" deep product hopper with safety grid, 4" OD x 18" long single auger feed screw powered by ¼ Hp motor drive with variable speed gearbox, (16) fixed, reversible stainless steel knife / impact blades driven by 10 Hp motor drive and has 15" long x 6" wide product discharge port with safety grid and 36" floor clearence. Control panel has mill and feed screw start, stop push buttons. Mounted on (4) leg stainless steel frame with locking casters. Used for precision grinding and controlled particle size reduction in pharmaceutical processing and other sanitary industries.
