Benchmark Model VAC-BL-LH, stainless steel, servo driven, 3 belt, smart belt feed system with number of products per minute – depending on material, application and machine intergrated with. Equipped with 70" long 3-1/2" wide plastic product in feed conveyor to 36" long 3-1/2" wide neophreme backlog conveyor, 11" long 3-1/2" wide neopreme metering conveyor to dual 24" long x 1" wide belt conveyors that feed product into the lugs of the wrapper with product sensors and adjustable guide rails, vacuum system with 30" in feed and discharge height. Control cabinet has A/B CPU controller and A/B panelview controller with readout, VFD and e-stop. Mounted on stainless steel frame.
OAD: 156" L x 26" W x 46" H
Sig, Model Crossfeeder, servo driven, stainless steel, 72" long, single chain, lugged, infeed conveyor. Equipped with ½" high lugs set on 13" centers and adjustable guide rails. Mounted on a stainless steel frame with casters.
OAD: 95"L x 23"W x 34"H
Arpac, Model 70LS, lugged infeed conveyor. Equipped with dual star wheel indexing and 40" long lugged chain with 1" wide x 2" high lugs set on 7½" centers. Control panel with an AB controller, Arpac HMI display and push button start / jog / stop controls.
OAD: 53"L x 45"W x 50"H
Vortex ICS individual, carrier system, product feeder and conveying system rated from 100 to 600 products per minute – depending on materials and application. Has a synchronised product infeed picking product and placing them in each individual holder on servo driven carrier conveyor providing very high loading and handling of different products with different sizes without any need for hardware changes, and a different number of products to be handled simultaneously with its high speed floating bucket, and jam free technology. ICS system can be integrated for feeding to any horizontal cartoner, or flow wrapper substituting the traditional bucket conveyor of these machines. Control panel A/B CPU with swing arm touch pad controller and A/B panelview, and saftey guarding. Was last feeding Rovema SBS brick pack machine.
OAD: 276" L x 72" W x 84" H Carrier System 95" L x 24" W x 87" H Control Panel
Doboy Model SBF, stainless steel, 2 belt, servo in feed system with number of product per minute – depending on material, application and machine intergrated with. Equipped with 32" long 4-1/2" wide neopreme vacuum in feed conveyor timed to speed of wrapper intergrated with and 16" long 4-1/2" wide vacuum neopreme product metering conveyor to separate product into the wrapper. Control cabinet has individual servo drive controls, with start, stop, vacuum on / off controls and e-stop. Mounted on stainless steel base frame.
OAD: 54" W x 36" W x 51" H
FMC Air Conveyor, 94"L x 11"W, air conveyor infeed, last used with FMC WM18 wrapper feeding prewrapped product into a multipack wrap. Unit has a 1/4 hp drive and blower, adjustable height and width guide rails, variable speed controls, and a touchpad controller with LED display. Mounted on a common base frame with (4) height adjustable legs.
OAD: 96"L x 36"W x 40"H
Bosch IL-2, 80"L x 9-1/2"W, S/S, in-line, neoprene belt product feeder capable of speeds up to 150 ppm (depending on application). Unit has a 1 hp drive, 1"H adjustable width guide rails, pre-programmable set up for 20 products, and on / off and E-stop controls. Mounted a S/S frame with (4) height adjustable legs.
OAD: 84"L x 32"W x 44"H
