Bartelt Machines


Bartelt Machines In Stock

Bartelt Form & Fill Auger IM1017

  • Manufacturer: Bartelt
  • Model Number: IM1017
  • Frain Number: 5E7734

Bartelt Model IM1017, Automatic, servo driven, intermittent motion, horizontial, form, fill, seal machine rated 10 to 70 pouches per minute – depending on Materials and application. Equipped with chain pouch feed conveyor has 17 stations set on 10" centers with pouch size range of: 3" to 8-03/4" in Width x 3" to 9-1/2" in Length, adjustable forming plow, 9-1/2" High film tension rollers, dual side seal, and cut-off stations, no pouch detection, suction cup style pouch opener, (2) Bartelt auger fillers, with top seal cleaning, heat seal bar, pouch pick-off, and can handle a 18" OD maximum film roll, with 21" maximum web width on 3" OD core. G E Fanuc PCU has touch pad controller, with digital readout and Omeron heat controls. Mounted on heavy duty frame.
(2) Syntron Vib Fillers W/FMC controls at additinal cost.

OAD: 320" L x 54" W x 90" H

Get a Free Quote Call: 630-629-9900

Bartelt Form & Fill Auger IM714

  • Manufacturer: Bartelt
  • Model Number: IM714
  • Frain Number: 5G9960

Bartelt Model IM7-14, automatic, horizontal, mechanical driven, intermittent motion, dual auger, form, fill, seal pouch machine rated from 14 to 100 pouches per minute – depending on materials and application. Pouch size range: 2" to 5-3/4" in Width; 2" to 9-1/2" in Length. Equipped with chain feed pouch conveyor with 14 stations set on 7" centers, film forming plow, film tension rollers, film side seal and cut-off stations, suction cup style pouch opener, (2) auger fillers with spinning wheel top pouch dust-off, and heat seal bar with pouch pick-off station. 18" OD maximum film roll, with 20" maximum web width, on 1" OD core. Control panel has PLC controller with auger and agitator, filler, airjet, vari speed, top, bottom and side heat seal control switches with start, stop e-stop and web feed stop push button controls. Mounted on heavy duty base frame with caster.

OAD: 228" L x 48" W x 74" H

Get a Free Quote Call: 630-629-9900

Bartelt Form & Fill No Filling Head 010XL

  • Manufacturer: Bartelt
  • Model Number: 010XL
  • Frain Number: 5H7770

Bartelt, Model 010XL, automatic, horizontal, servo driven, intermittent motion zipper pouch forming machine. Pouch size range: 3" to 25" in Width; 4" to 16" in height. Equipped with forming plow, zipper attachment, tension rollers, pouch side seal and cut-off station. 24" OD maximum film roll, with 36" maximum web width. Control panel has push button start / stop controls and on / off switches for individual stations. Speed dependent on materials, application and machine configuration.

OAD: 260"L x 64"W x 86"H

Get a Free Quote Call: 630-629-9900

Bartelt Form & Fill Auger IMF6.5

  • Manufacturer: Bartelt
  • Model Number: IMF6.5
  • Frain Number: 5H7310

Bartelt Model IMF6.5, Automatic, intermittent motion, horizontal, form, fill, seal machine rated from 40 to 100 pouches per minute – depending on materials and application. Pouch size range: 2" to 4-3/4" in Width; 2" to 6" in Length. Equipped with height adjustable gusseted film forming plow, side seal station, 9-1/2" high film tension rolls, knife cut off station, vacuum pouch opener, 14 rotary head fill station set on 6-1/2" centers, single head auger filler buckets, top heat seal stations and recipricating suction cup pic n place discharge. Control panel has Siemens Simatic 505 PLC controller with touchpad controller, and variable heat seal controls, with interlocking safety guarding. Film Specifications: up to 22" in Width; up to 18" in diameter with a max 3" OD core. Mounted on heavy duty frame.

Optional filler, zipper attachment, coder, tear notch, available at additional cost.

OAD: 228" L x 48" W x 67" H

Get a Free Quote Call: 630-629-9900

Bartelt Form & Fill Auger IM712

  • Manufacturer: Bartelt
  • Model Number: IM712
  • Frain Number: R32180

Bartelt Model IM712, automatic, horizontal, mechanical driven, intermittent motion, auger, form, fill, seal machine rated from 12 to 60 pouches per minute – depending on materials and application. Pouch size range: 2″ to 5-3/4″ in Width; 2″ to 9-1/2″ in Length. Equipped with chain fed pouch conveyor with 12 stations set on 7″ centers, film forming plow, tension rollers and pouch side seal with cut-off stations, suction cup pouch opener, (1) auger filler with controller, spinning wheel top pouch dust-off, and heat seal bar with pouch pick-off station. 18″ OD maximum film roll, with 20″ maximum web width, on 1″ OD core. Control panel has PLS controls with auger, start, run, jog, registration, top, bottom and side heat seal control switches with start, stop e-stop and web feed push button controls. Mounted on heavy duty base frame.

OAD: 198″ L x 48″ W x 85″ H

Get a Free Quote Call: 630-629-9900

Bartelt Form & Fill Auger IM1017

  • Manufacturer: Bartelt
  • Model Number: IM1017
  • Frain Number: 5E7688

Automatic, servo driven, intermittent motion, horizontial, f/f/s machine capable of speeds 10 to 70 ppm ppm depending on application. Has a chain pouch feed conveyor with 17 stations set on 10" centers and a pouch size range of: 3" – 8 3/4" W x 3" – 9-1/2" L, adjustable forming plow, 9 1/2" H film tension rollers, side seal, and cut-off stations, no pouch detection, suction cup style pouch opener, with top seal cleaning, heat sealing bar, and pouch pick-off station, can handle a 18" OD max film roll, with 26" max web width, on 3" OD core, servo driven, plc, with touch pad controller, digital readout, and Omeron heat seal controllers.

OAD: 295" L x 45" W x 83" H

Get a Free Quote Call: 630-629-9900

Bartelt Form & Fill Auger IM914

  • Manufacturer: Bartelt
  • Model Number: IM914
  • Frain Number: 5H4479

Bartelt, Model IM 9-14, automatic, horizontal, mechanical driven, intermittent motion, form, fill, seal machine. Rated from 12 to 60 pouches per minute – depending on materials, application and machine configuration. Pouch size range: 2" to 7¾" in Width; 2" to 9½" in Length. Equipped with chain fed pouch conveyor with (14) stations set on 9" centers, film forming plow with tension rollers, side pouch seal with cut-off stations, suction cup pouch openers and heat seal bar with pouch pick-off station. 24" OD maximum film roll, with 20" maximum web width. Control panel has push button start / stop controls, digital temperature controls and on / off switches for individual stations. Mounted on heavy duty painted base frame.

OAD: 240"L x 50"W x 96"H

Get a Free Quote Call: 630-629-9900

Bartelt Form & Fill SLITTER

  • Manufacturer: Bartelt
  • Model Number: SLITTER
  • Frain Number: 5H3029

3¾" wide x 40" long (3) chain lugged conveyor. Equipped with fixed pockets on 7" centers, (2) cutting wheels and (2) suction cup reciprocating pick and place discharge.

OAD: 60"L x 20"W x 48"H

Get a Free Quote Call: 630-629-9900

Bartelt Form & Fill Auger IM610

  • Manufacturer: Bartelt
  • Model Number: IM610
  • Frain Number: 5H4470

Bartelt, Model IM 6-10, automatic, horizontal, mechanical driven, intermittent motion form, fill, seal machine. Rated from 12 to 100 pouches per minute – depending on materials, application and machine configuration. Pouch size range: 2" to 4½" in Width; 2" to 9½" in Length. Equipped with chain fed pouch conveyor with (10) stations set on 6" centers, film forming plow, tension rollers and pouch side seal with cut-off stations, suction cup pouch openers and heat seal bar with pouch pick-off station. 20" OD maximum film roll, with 20" maximum web width. Control panel has push button start / stop controls, digital temperature controls and on / off switches for individual stations. Mounted on heavy duty painted base frame.

OAD: 165"L x 48"W x 94"H

Get a Free Quote Call: 630-629-9900

Bartelt Form & Fill Auger IM714

  • Manufacturer: Bartelt
  • Model Number: IM714
  • Frain Number: 5H1940

Bartelt Model IM714, Automatic, horizontal, mechanical, intermittent motion, auger, form, fill, seal machine rated from 10 to 100 packages per minute – depending on materials and application. Equipped with chain pouch feed conveyor with 14 stations set on 7" centers and pouch size range: 2" to 5-3/4" in Width x 2" to 9 -1/2" in Length. Forming plow and 9-1/2" high film tension rollers, (1) side seal and cut-off station, no pouch detection suction cup style pouch opener, Bartelt auger filler and pouch pick-off station, can handle a 18" OD max film roll, with 21" max web width, on 3" OD core, mechanical drive, and Omeron heat seal controllers. Mounted on 8 leg base frame.

OAD: 231" L x 48" W x 83" H

Get a Free Quote Call: 630-629-9900

Bartelt Form & Fill Auger IMF 6.5

  • Manufacturer: Bartelt
  • Model Number: IMF 6.5
  • Frain Number: 5F3762

Automatic, intermittent motion, horizontal, Form, Fill & Seal machine rated up to 20 to 140 ppm – depending on materials and application. Pouch size range: 2" to 4-3/4" in Width; 2" to 9-1/2" in Length. Equipped with a height adjustable gusseted film forming plow, dual side seal, 9-1/2" high film tension rolls, knife cut off station, vacuum pouch opener, Spee Dee 3500 servo driven auger filler, quick change spout oval filling system with dizzing buckets, dual top heat seal stations, 2-head recipricating suction cup pic n place discharge station, Siemens Simatic 505 PLC, variable heat seal controls, touchpad controller, and interlocking safety guarding. Film Specifications: up to 22" in Width; up to 18" in diameter with a max 3" OD core.

OAD: 228" L x 48" W x 67" H

Get a Free Quote Call: 630-629-9900

Bartelt Form & Fill Auger IMF6.5

  • Manufacturer: Bartelt
  • Model Number: IMF6.5
  • Frain Number: 5F3751

Automatic, intermittent motion, horizontal, Form, Fill & Seal machine rated 40 to 100 ppm – depending on materials and application. Pouch size range: 2" to 4-3/4" in Width; 2" to 9-1/2" in Length. Equipped with a height adjustable gusseted film forming plow, side seal station, 9-1/2" high film tension rolls, knife cut off station, vacuum pouch opener, 14 head fill station set on 6-1/2" centers, quick change spout oval filling system with dizzing buckets, top heat seal stations, recipricating suction cup pic n place discharge station, Siemens Simatic 505 PLC, variable heat seal controls, touchpad controller, and interlocking safety guarding. Film Specifications: up to 22" in Width; up to 18" in diameter with a max 3" OD core.

Optional filler, zipper attachment, coder, tear notch, available at additional cost.

OAD: 228" L x 48" W x 67" H

Get a Free Quote Call: 630-629-9900
