Fanuc Machines

Fanuc Palletizer Robotic M410IHS

• Manufacturer: Fanuc
• Model Number: M410IHS
• Frain Number: 5G8900

Fanuc, Model M-410iHS, 4 axes robotic, servo, vacuum, pic-n-place palletizer arm. Rated from 5 to 15 cycles per minute – depending on materials, application, pack pattern and machine configuration. Unit is cable of moving product between floor level and 123" in height and rated to pick up maximum weight of 220 lbs. Equipped with (1) 18" x 44" (52) suction cup vacuum head mounted on a robotic arm with a 78" horizontal reach. Fanuc R-J3 model controllers with hand held to each pendants. Mounted on pedestal base frame.

OAD: 75" L x 42" W x 150" H

Fanuc Palletizer Robotic M410IHS

• Manufacturer: Fanuc
• Model Number: M410IHS
• Frain Number: 5H1752

Fanuc, Model M-410iHS, 4 axes robotic, servo, vacuum, pic-n-place palletizer arm. Rated from 5 to 15 cycles per minute – depending on materials, application, pack pattern and machine configuration. Unit is cable of moving product between floor level and 123" in height and rated to pick up maximum weight of 220 lbs. Equipped with (1) combination finger gripper / suction cup vacuum head mounted on a robotic arm with a 78" horizontal reach. Fanuc R-J3 model controllers with hand held teach pendants. Mounted on pedestal base frame with light curtain safety.

OAD: 82"L x 50"W x 121"H

Fanuc Palletizer Robotic M410IHS

• Manufacturer: Fanuc
• Model Number: M410IHS
• Frain Number: 5G8903

Fanuc, Model M-410iHS, 4 axes robotic, servo, vacuum, pic-n-place palletizer arm. Rated from 5 to 15 cycles per minute – depending on materials, application, pack pattern and machine configuration. Unit is cable of moving product between floor level and 123" in height and rated to pick up maximum weight of 220 lbs. Equipped with (1) 18" x 44" (52) suction cup vacuum head mounted on a robotic arm with a 78" horizontal reach. Fanuc R-J3 model controllers with hand held teach pendants. Mounted on pedestal base frame.

OAD: 110" L x 41" W x 140" H

Fanuc Palletizer Robotic M410IHW

• Manufacturer: Fanuc
• Model Number: M410IHW
• Frain Number: 5G8901

Fanuc, Model M-410iHW, 4 axes robotic, servo, vacuum, pic-n-place palletizer arm. Rated from 5 to 15 cycles per minute – depending on materials, application, pack pattern and machine configuration. Unit is cable of moving product between floor level and 123" in height and rated to pick up maximum weight of 550 lbs. Equipped with (1) ___" x ___" (___) suction cup vacuum head mounted on a robotic arm with a 78" horizontal reach. Fanuc R-J3 model controllers with hand held teach pendants. Mounted on pedestal base frame.

OAD: 93" L x 42" W x 140" H

Fanuc Palletizer Robotic M400

• Manufacturer: Fanuc
• Model Number: M400
• Frain Number: 5E9640

4 axis robotic arm vaccum pic-n-place palletizer capable of indexing up to 1000 mm/sec. Unit is able to move product between floor level and 80"(H) and is rated to pick up a maximum weight of 110 lbs. Equipped with 8 1/2" x 10" vaccum head (4 cup) mounted on 80"(L) robotic arm and LCD display w/input keyboard & Fanuc System R Model H PLC control. Robotic arm is controlled by two servomotors and is capable of moving in three dimensions.
OAD: 400"L x 28"W x 106"H
