Filamatic Machines


Filamatic Machines In Stock

Filamatic Filler Liquid Pos Disp VLA

  • Manufacturer: Filamatic
  • Model Number: VLA
  • Frain Number: 5H4260

Filamatic, Model VLD, 4 head inline piston filler. Rated from 12 to 60 bottles per minute with a fill range of 60ml to 520ml with proper change parts – depending on materials, application and machine configuration. Equipped with 96" long by 3¼" wide Delrin conveyor, star wheel indexing, adjustable guide rails, (4) 520cc pistons and (4) (5/8)" OD diving nozzles with positive cut off mounted on a 16" long slide bar. Control panel with Omron PLC and push button start / stop / reset / e-stop controls. Mounted on base frame with leveling legs.

OAD: 102"L x 32"W x 72"H

Get a Free Quote Call: 630-629-9900

Filamatic Filler Liquid Pos Disp DAB16

  • Manufacturer: Filamatic
  • Model Number: DAB16
  • Frain Number: 5H4120

Filamatic, Model DAB-16, automatic 2 piston filler. Rated from 3 to18 cycles per minute with number of container – depending on materials, application and machine configuration. Fill range of: 60cc to 520cc with proper change parts and is equipped with (2) FKS 130cc pistons with fill accuracies of ± 0.5%, pneumatic gate indexing, 7/16" OD diving nozzles and a 3¼" wide x 102" long delrin conveyor. Control panel with on / off switch and variable speed dial.
Mounted base frame with casters and leveling legs.

OAD: 105"L x 40"W x 64"H

Get a Free Quote Call: 630-629-9900

Filamatic Filler Liquid Pos Disp DAB54

  • Manufacturer: Filamatic
  • Model Number: DAB54
  • Frain Number: 5A2040

Filamatic, Model DAB-5-4, automatic four head piston filler. Rated from 4 to 72 bottles per minute – depending on materials, application and machine configuration. Fill size: 1 ml to 130 ml. Fill accuracy: ± 0.05%. Change parts required to accommodate fill / size range. Equipped with diving nozzles and bimba indexing.

OAD: 34"L x 24"W x 48"H

Get a Free Quote Call: 630-629-9900

Filamatic Filler Liquid Monoblock MNB/P-LD

  • Manufacturer: Filamatic
  • Model Number: MNB/P-LD
  • Frain Number: 5F7727

Filamatic Model MNB/P-LD, 1-up, automatic, stainless steel, monoblock filler, tipper and capper rated from 10 to 50 containers per minute – depending on materials and application. Container size range: 1/2" to 2-14" in Diameter; 1" to 5" in Height. Fill range: 0.5ml to 500ml with proper change parts and accuracies of +/- .5%. Equipped with 138" long x 3-1/4" wide plastic delrin container conveyor, with container feed station, 1-up piston filler, tip and cap feed have dual vibratory stainless steel, hoppers with level detection and single head screw capper, star wheel in feed and discharge, bottom up fill and missing bottle, tip, cap detection. Touch pad controller with panel view, tip, cap bowl and fill controls with start, stop and e-stop with operator interface data information control system. Last doing 5ml eye dropper style bottle.

OAD: 156" L x 72" W x 61" H

Get a Free Quote Call: 630-629-9900

Filamatic Filler Liquid Pos Disp AL100

  • Manufacturer: Filamatic
  • Model Number: AL100
  • Frain Number: 5E4720

Automatic, S/S, 4 head, inline piston filler rated up to 40 cpm – depending on materials and application. Equipped with 3" wide Delran conveyor, pneumatic cylinder container indexing system, four FUS 60ml (2 oz) pistons, diving nozzles and e-stop. Mounted on a S/S frame. Able to accommodate piston sizes up to 520ml.

OAD: 93" L x 60" W x 60" H

Get a Free Quote Call: 630-629-9900

Filamatic Filler Liquid Pos Disp ALZ700CE

  • Manufacturer: Filamatic
  • Model Number: ALZ700CE
  • Frain Number: 5E0322

Automatic, stainless steel, 6 head, inline, closed environment, piston filler rated from 12 to 60 containers per minute – depending on materials and application. Equipped with a 144" long Delran conveyor, container indexing system, six FSV XL 560cc pistons, 5/16 OD nozzles, centering guides, bottom up fill and micrometer fill drip controls. Enclosed fill area capable of hot fills up to 200 Deg F. Additionally features Lexan guarding. Piston fill range from 1ml to 560 ml with proper pistons and assemblies.

OAD: 147" L x 62" W x 81" H

Get a Free Quote Call: 630-629-9900

Filamatic Filler Liquid Pos Disp AL100

  • Manufacturer: Filamatic
  • Model Number: AL100
  • Frain Number: 5G4540

Filamatic Model AL100, inline piston filler rated from 12 to 70 bottles per minute – depending on materials and application. Equipped with (4) __ " OD nozzles mounted on 24" long adjustable slide bar with centering system. Control Panel with on / off main, filler, auto / prime and conveyor switches with conveyor speed control. Mounted casters with leveling legs. Designed to handle from a water to a light oil product.

OAD:

Get a Free Quote Call: 630-629-9900

Filamatic Filler Liquid Pos Disp AL100

  • Manufacturer: Filamatic
  • Model Number: AL100
  • Frain Number: 5G9681

Filamatic, Model AL-100, semi automatic two head table top stainless steel piston filler. Rated from 10 to 70 bottles per minute with number of containers – depending on materials, application, machine configuration and operator dexterity. Fill size: 13 ml to 280 ml. Fill accuracy: ± 0.5%. Currently equipped with (2) 280cc FKS pistons and foot pedal operation. Control panel with on / off switch, continuous / manual switch and variable speed dial.

Get a Free Quote Call: 630-629-9900

Filamatic Filler Liquid Pos Disp CVK500

  • Manufacturer: Filamatic
  • Model Number: CVK500
  • Frain Number: 5H0762

Filamatic Model CVK-500 12 head, high speed in line, automatic piston filler for free flowing, semi viscous and viscous product rated from 24 to 120 containers per minute – depending on materials and application. Fill volume: 0.10cc to 1300cc single stroke (with proper change parts) Currently set with 30cc pistons. Equipped with 136" long x 3-1/4" wide plastic delran conveyor with star wheel indexing, currently set with (12) 30cc pistons, set on 3-1/2" centers. Control panel has filler, conveyor and hesitation speed controls with start, stop and e-stop push buttons. Mounted on stainless steel base frame with height adjustable legs.

OAD: 156" L x 60" W x 58" H

Get a Free Quote Call: 630-629-9900

Filamatic Filler Liquid Pos Disp DAB-16-4

  • Manufacturer: Filamatic
  • Model Number: DAB-16-4
  • Frain Number: R27280

Filamatic, Model DAB-16-4, automatic 4 piston filler. Rated from 3 to18 cycles per minute with number of container – depending on materials, application and operator dexterity. Fill range of: 60cc to 520cc with proper change parts and is equipped with (4) FUS 520cc pistons with fill accuracies of ± 0.5%, pneumatic gate indexing, 6½mm ID diving nozzles and a 4½" wide x 112" long delrin conveyor. Start/stop push button controls, continuous/single cycle switch and variable speed dial. Mounted on heavy duty base frame. Ideal for viscous, semi-viscous, or free-flowing products.

OAD: 115"L x 48"W x 70"H

Get a Free Quote Call: 630-629-9900

Filamatic Filler Liquid Pos Disp DAB8

  • Manufacturer: Filamatic
  • Model Number: DAB8
  • Frain Number: 5E4951

Semi-automatic, heavy duty, 2 piston, table top filler rated from 4 to16 cycles per minute – depending on materials and application. Fill range of: 1ml to 260ml – with appropriate sized pistons/syringes. Currently equipped with 260cc pistons/syringes and foot pedal control. Accuracies: +/- 0.5% of fill. Ideal for viscous, semi-viscous, or free-flowing products. Change parts required to accommodate fill range. Speeds dependant on materials, application, machine configuration and operator dexterity.

OAD: 20" L x 24" W x 24" H

Get a Free Quote Call: 630-629-9900

Filamatic Filler Liquid Pos Disp DABA32-2

  • Manufacturer: Filamatic
  • Model Number: DABA32-2
  • Frain Number: 5G6010

Filamatic, Model DAB-A-32-2, semi automatic two head table top stainless steel piston filler. Equipped with (2) 560cc FSV-XL-560-1 pistons, foot pedal operation and E-Stop. 316 S/S contact parts. Rate / Speed dependant on materials, application, machine configuration and operator dexterity.
(Fill size range of 3 ml to 1100 ml. Change parts required to accommodate fill / size range.)

OAD: 28"L x 28"W x 30"H

Get a Free Quote Call: 630-629-9900
