Photo of Gaulin Homogenizer Single Stage MS18-2.5TBS

Gaulin Homogenizer Single Stage MS18-2.5TBS

  Back to All Equipment
  • Manufacturer: Gaulin
  • Model: MS18-2.5TBS
  • Frain Number: R24901
  • Category: Homogenizer
  • Subcategory: Single Stage
  • Condition: Used, in excellent condition
  • Availability: In Stock

Gaulin, Model MS18-2.5TBS 2200, single stage, stainless steel homogenizer. Rated for an output capacity of up to 1600 gallons per hour – depending on materials and application. Maximum operating pressure up to 2,200 psi. Equipped with ball valve cylinders and standard style valve seat. Hydraulic homogenizing valve actuator assembly with a 2½" OD / 2" ID tri-clamp style charge port, 2½" OD / 2" ID Tri-clamp style discharge port and pressure gage up to 2,500 psi. Ball valve head is ideally suited for high-viscosity or abrasive products like, peanut butter, evaporated milk, wax emulsions and lubricants. Standard valve seat is used for most emulsion and dispersion applications.

OAD: 96"L x 48"W x 52"H
