Rotary blister machines are designed to seal a blister to a card. (A blister is a depression formed out of plastic that is normally used to hold a product.) A rotary blister machine uses a rotating disc to index the product below the heat sealing head, which is designed to seal the blister to the card. Rotary blister machines can be design to operate semi-automatically, fully automatically, or somewhere in between the two. Semi-automatic rotary blister sealers require an operator to load the blister, the product into the blister, and load the card onto the blister. These operations can be accomplished by one or more than one operators around the circumference of the rotary disc. The rotary disc then indexes below the heat sealing head where the blister card is sealed to the blister. The rotary disc indexes again to an operator who discharges the sealed blister package. A fully automatic rotary blister machine will perform all of the operations automatically without requiring operator input. Because operations can be performed concurrently at different locations on the rotary disc, rotary blister machines generally have a greater output than shuttle blister machines.
Alloyd, Model 6SM1216CBE, 6 Station, Semi automatic rotary blister sealer rated up to 20 cycles per minute with number of product – depending on materials, application and operator dexterity. Equipped with 60" OD rotary table with (6) product stations with 12" x 16" seal platen area, blister and card feed magazines with vacuum pick-offs. Control panel has blister and card feed, vacuum and heat controls on / off switches with eject single cycle switches, speed control dial, start / cycle stop and e-stop push buttons. Mounted on heavy duty frame.with locking casters and safety guarding.
OAD: 132" L x 84" W x 72" H
Alloyd Model 6S, Automatic, 6 station, rotary blister sealer rated to 20 cycles per minute, with number product – depending on materials, application and operator dexterity. Equipped with 56" OD rotary table with (6) product stations, 14" x 10" seal platen area, blister, and card feed sections with vacuum pick-offs. Control panel has start / stop, blister and card feed, vacuum and heat controls with static elimanator switch and e-stop. Mounted on heavy duty frame.
OAD: 88" L x 68" W x 70" H
Alloyd, Model 6S-CBE, Automatic, 6 station, rotary blister sealer. Rated from 5 to 20 cycles per minute, with number product – depending on materials, application and operator dexterity. Equipped with a 56" OD rotary table with 6 product operator load stations, 16" x 10" seal platen area, blister and card feed sections with vacuum pick-offs. Control panel has start / stop, blister and card feed, vacuum and heat controls and e-stop. Mounted on heavy duty frame.
OAD: 90" L x 65" W x 68" H
Koch, Model KDT-NP, automatic, 4 station, rotary blister sealer. Rated from 5 to 12 cycles per minute, with number product – depending on materials, application, machine configuration and operator dexterity. Equipped with 40" diameter rotary table with (4) product stations, 13¾" x 9¾" seal platen area, blister and card feed sections with vacuum pick-offs and hand load product area. Control panel has push button start and stop with touchpad controller. Mounted on base frame with safety guarding and casters.
OAD: 76"L x 45"W x 72"H
Alloyd Model 6SC1216QC, semi automatic, 6 station, rotary, quick change blister sealer rated from 6 to 20 cycles per minute with number of product – depending on materials, application and operator dexterity. Equipped with feed magazines, vacuum suction cup pick-off for both cards and blisters and operator load section, 56" OD rotary table has (6) product stations with 16" x 12" seal platen area. Control panel has tempature controller 0 – 800 Deg F, pressure gauge, start / stop, blister / card feed and vacuum pump control switches with start, cycle and e-stop push button controls. Mounted on heavy duty base frame.
OAD: 96"L x 72"W x 72"H
Alloyd, Model 6S-CBE, automatic, 6 station, rotary blister sealer. Rated up to 20 cycles per minute, with number product – depending on materials and application. Equipped with a 56" diameter rotary table with 6 product stations, with 16" x 10" seal platen area, blister and card feed sections with vacuum pick-offs. Control panel has start / stop, blister and card feed, vacuum and heat controls with static elimanator switch and e-stop.
OAD: 90" L x 64" W x 62" H
Alloyd, Model 6S-CBE, automatic, 6 station, rotary blister sealer rated up to 20 cycles per minute, with number product – depending on materials and application. Equipped with a quick change heat plate, adjustable time heat seal, 56" diameter rotary table with 6 product stations, with 16" x 10" seal platen area, blister and card feed sections with vacuum pick-offs. Control panel has start / stop, blister and card feed, vacuum and heat controls and e-stop.
OAD: 84" L x 65" W x 70" H
Semi automatic 6 station rotary blister sealer is rated to 20 cycles per minute. Equipped with variable heat temperature controls from 0 to 800 degrees F, automatic card feeder and automatic blister denester. Max blister depth 2-1/2". Heat seal area is 10" x 16".
(OAD 99"L x 64"W x 68"H
Alloyd, Model 6SMCBE, 6 Station rotary blister sealer. Rated to 20 cycles per minute. 10" X 16" Tool/Platten size (3" tooling), 15" x 17" nesting trays 2¼" blister depth. Equipped with a dual pressure cylinder, variable seal time, automatic blister feeder, automatic card feeder & automatic eject.
OAD: 6′ W x 9′ L x 6′ H.
Alloyd Model 6SCBE, Automatic, 6 station, rotary blister sealer rated to 20 cycles per minute, number product – depending on materials and application. Equipped with 56" diameter rotary table with six product stations, 14" x 10" seal platen area, blister, and card feed sections with vacuum pick-offs. Control panel has start / stop, blister and card feed, vacuum and heat controls with static elimanator switch and e-stop.
Alloyd Model 4SC1216QCT, Automatic 4-station rotary blister packaging machine with number of product per minute – depending on materials, application and operator dexterity. Equipped with automatic blister feed, card feed, sealing with 12" x 16" seal area and Blister depth of 3.25" with package eject. Mounted on heavy duty frame with safety guarding.
OAD: 61" H x 87" W x 70" D
Alloyd, automatic, 6 station, rotary blister sealer rated to 20 cycles per minute, number product – depending on materials and application. Equipped with 56" diameter rotary table with six product stations, 14" x 10" seal platen area, suction cup vacuum pick-offs and vacuum pump. Control panel has start / stop, blister and card feed, vacuum and heat controls with static elimanator switch and e-stop. Does not have card or blister feed magazines change parts per application.
OAD: 84" L x 72" W x 70" H
