Twin Screw Machines
Used Twin Screw Equipment
The twin screw extruder has many of the requirements of a single screw extruder but has the ability to be self cleaning and wiping and by using a combination of screw elements and barrel section to profile the product to the required condition or consistency. Twin screw extruders are very precise machines and can be used for simple compounding to continuous chemical reactor for a variety of thick and difficult to handle product
Twin Screw Equipment In Stock
- Manufacturer: Polar Process / Advanced Stain
- Model Number: PP352HU3
- Frain Number: 5G9731
Polar Process, Model PP352HU3, stainless steel, twin screw extruder. Hopper dimensions: 12½" in Length; 7½" in Width; 9" in Depth. Equipped with two 3½" diameter x 26" long stainless steel screws and cross direction corrugated feed roller. 3½"OD / 3"ID Tri-clamp style discharge. Control panel with push button start/stop and touch pad speed controls. Mounted on a stainless steel base with locking casters.
OAD: 53"L x 29"W x 52"HGet a Free Quote Call: 630-629-9900
- Manufacturer: ToGum / Bosch Company
- Model Number: TOE 40
- Frain Number: 5G1234
ToGum Model TOE 40, variable speed, counter rotating, twin screw extruder. Equipped with two 33mm diameter x 16" long screws, two variable temperature controllers, and push button controls. Mounted on casters.
OAD: 57" L x 25" W x 53" HGet a Free Quote Call: 630-629-9900
- Manufacturer: Werner & Pfleiderer
- Model Number: ZSK-57-W50P
- Frain Number: 5D4095
Co-rotating Twin screw, 57mm carbon steel compounding extruder with optional high torque drive rated at up to 350 kg/hour – depending on materials and application. L to D ratio 34:1 Equipped with 9 jacketed barrels in 7" long sections for heating and cooling, 3.5" diameter feed area with additional infeed area of 28" downstream from the first.
OAD: (L) 186" x (W) 40" x (H) 78"
