Meat Machines

Stephan Machinery Corp Meat Equipment Emulsifier MCH20

• Manufacturer: Stephan Machinery Corp
• Model Number: MCH20
• Frain Number: 5G8537

Stephan Machinery, Model MCH20, stainless steel Microcut emulsifying processor. Rated from 0 to 2645 lbs per hour – depending on materials, application and machine configuration. Equipped with 27" long x 35" wide x 19" deep product hopper, feed auger into cutting set and a rectangular flange discharge port with a 2½" OD / 2" ID Tri-clamp adapter. Knives and auger powered by a 20 hp drive with push button start / stop controls. Mounted on a stainless steel base with casters.

OAD: 56"L x 37"W x 39"H

Poly Clip Meat Equipment Chub DFC 8161

• Manufacturer: Poly Clip
• Model Number: DFC 8161
• Frain Number: 5E5368

PART OF COMPLETE LINE

Poly Clip Model DFC8161, automatic, double clip, chub filler, rated from 10 to 50 cycles per minute – depending on materials and application. Capable of uniform portioning from medium to large products up to 60mm in diameter. Equipped with a 400 clip capacity, double clip magazines (places two clips with each cycle) and utilizes 8700 series clips. 40" Long product roller conveyor, adjustable link sizer flap, iris separator and skin brake that automatically withdraws, prevents skins from being over stretched, capable of handling fibrous, collagen, and synthetic type casings, with A/B PLC.

OAD: 74" L x 42" W x 78" H

Buffalo Meat Equipment Stuffer 500

• Manufacturer: Buffalo
• Model Number: 500
• Frain Number: 5D9872

500 Lb capacity stuffer ideal for meat, and dairy products. Unit has a top 24" diameter easy loading product opening with screw down cover and 46" high stuffing area. (2) 3" diameter top product ports, (1) 5" diameter, and (1) 2 1/2" diameter bottom product ports. Last running in a food application.

OAD: 64"H x 44" W x 30"L

Buffalo Meat Equipment Stuffer 500

• Manufacturer: Buffalo
• Model Number: 500
• Frain Number: 5D9873

500 Lb capacity stuffer ideal for meat, and dairy products. Unit has a top 24" diameter easy loading product opening with screw down cover with 46" high stuffing area. (2) 3" diameter top product ports. Last running in a food application.

OAD: 64"H x 44" W x 30"L

Stein Meat Equipment Batter, Breader machine HERITAGE

• Manufacturer: Stein
• Model Number: HERITAGE
• Frain Number: 5G7636

Stein, Heritage model, automatic stainless steel breading applicator. Capable of running flour and fine granular free flow coating materials with number of product per hour – depending on materials and application. Equipped with a 36" wide x 36" long product in feed conveyor belt with 27" wide top applicator and bottom breading reservoir to cover belt and fully coat product, 30" wide x 35" long stainless steel wire product discharge belt with hooded blow off for excess breading removal. Coating material is transferred from filling station to top applicator by a 7½" diameter x 65" long stainless steel screw conveyor and further transferred to bottom station with a 3" diameter x 28" long stainless screw conveyor. Unused breading from conveyor belt is returned to the filling station by a 6½" diameter x 50" long stainless steel screw conveyor. Mounted on stainless steel base frame with casters.

OAD: 87"L x 56"W x 82"H

Vemag Meat Equipment Stuffer 500

• Manufacturer: Vemag
• Model Number: 500
• Frain Number: 5G9171

Vemag, Model 500, continous, double screw, vacuum stuffer and portioner. Rated from 500 to 2200 Kg’s per hour and protion weights of 15 to 10,000 grams – depending on materials, application and machine configuration. Filling pressure approximatly 20 Bar. Equipped with 38" OD x 32" deep stainless steel, tilt back product hopper with auger, side scaper and center baffle, double screw feed system (change part per application), side vacuum pot and plug port with filter screen, knee level adjustment lever, vacuum pressure gauge, oil-less vacuum pump and 3½" OD / 3" ID seated bevel discharge port with 43" floor clearence. Control panel has portion controls, speed control dials, vacuum control dial and start / stop push button controls. Mounted on (4) leg base frame with casters.

OAD: 43" L x 38" W x 77" H

Hobart Meat Equipment 4732A

• Manufacturer: Hobart
• Model Number: 4732A
• Frain Number: 5G9692

Hobart, Model 4732A, stainless steel meat grinder. Rated from 25 to 40 lbs per minute – depending on materials, application and machine configuration. Equipped with a 34" long x 21" wide x 4½" deep pan, 3½" diameter x 10" long auger and 3½" diameter discharge with 21" ground clearance. Mounted on a stainless steel base with casters.

OAD: 42"L x 24"W x 39"H

Mixer Powder Other V-PD

• Model Number: V-PD
• Frain Number: 5G7639

Process System, Model V-PD, stainless steel auger and pump feed system. Volumes of product per hour – depending on materials, application, environment and machine configuration. Equipped with 18" long x 12" wide x 18" deep (1 ft³) dry product hopper with safety grid and side vibrator, 3" diameter x 13" long screw with ¾ Hp motor drive, 8" diameter x 9" deep (2 gal.) mixing hopper and (2) Jabsco positive displacement pumps powered by (1) 2 hp and (1) 3 hp drives. Mounted on stainless steel base frame.

OAD: 58"L x 22"W x 50"H

Stein Meat Equipment Batter, Breader machine APB

• Manufacturer: Stein
• Model Number: APB
• Frain Number: 5G7648

Stein, Model APB Overflow, batter applicator. For use with conventional pumpable batters. Products per minute – dependant on materials and application. Equipped with a 34" wide x 92" long stainless steel wire belt powered by a 2 hp drive with variable speed control, 34" wide batter quad curtain to coat top and sides of product, lowered belt section to coat bottom of product, 5 hp batter pump and 2 hp blower for removal of excess batter. Includes on/off switches for pump and blower and push button start/stop control for conveyor. Mounted on a stainless steel base with casters.

OAD: 93" L x 57"W x 65"H

MAJA Food Tech Inc Meat Equipment ESB4434/1

• Manufacturer: MAJA Food Tech Inc
• Model Number: ESB4434/1
• Frain Number: 5G9030

MAJA, Model ESB4434/1, stainless steel membrane skinning machine. Lbs of product per hour dependent on – materials, application, machine configuration and operator dexterity. Equipped with a 15" wide x 30" long infeed conveyor, 17" wide cutting head and 15" wide x 30" long discharge conveyor. Discharge conveyor has (4) height settings; 34½", 39", 43" and 46½". Can be converted from manual to automatic operation with no tools. Includes push button start / stop controls. Machine mounted on Casters.

OAD: 70"L x 34"W x 49"H (with conveyors in extended position)

Stein Meat Equipment Batter, Breader machine APB

• Manufacturer: Stein
• Model Number: APB
• Frain Number: 5G7641

Stein, Model APB Overflow, batter applicator. For use with conventional pumpable batters. Products per minute – dependant on materials and application. Equipped with a 30" wide x 88" long stainless steel wire belt powered by a 2 hp drive with variable speed control, 29" wide batter double curtain to coat top and sides of product, lowered belt section to coat bottom of product, 3 hp batter pump and 2 hp blower for removal of excess batter. Includes on/off switches for pump and blower and push button start/stop control for conveyor. Mounted on a stainless steel base with casters.

OAD: 90" L x 55"W x 65"H

Stein Meat Equipment Batter, Breader machine APB/HERITAGE

• Manufacturer: Stein
• Model Number: APB/HERITAGE
• Frain Number: 5G7649

Stein, Heritage model and APB Overflow model, automatic stainless steel batter and breading applicator system. Capable of running pump able batters and flour or fine granular, free flowing, coating materials. Number of product per hour – depending on materials and application.

Stein, APB Overflow model, batter applicator. For use with conventional pump able batters. Products per minute – dependant on materials and application. Equipped with a 30" wide x 97" long stainless steel wire belt powered by a 2 hp drive with variable speed control, 29" wide batter double curtain to coat top and sides of product, lowered belt section to coat bottom of product, 2 hp batter pump and 2 hp blower for removal of excess batter. Includes on/off switches for pump and blower and push button start/stop control for conveyor. Mounted on a stainless steel base with casters.

Stein, Heritage model, breader for applying flour and fine granular free flowing coating materials. Equipped with a 36" wide x 36" long product in feed conveyor belt with 27" wide top applicator and bottom breading reservoir to cover belt and fully coat product, 30" wide x 35" long stainless steel wire product discharge belt with hooded 3 hp blower for excess breading removal. Coating material is transferred from filling station to top applicator by a 7½" diameter x 65" long stainless steel screw conveyor and further transferred to bottom station with a 3" diameter x 28" long stainless screw conveyor. Unused breading from conveyor belt is returned to the filling station by a 6½" diameter x 50" long stainless steel screw conveyor. Mounted on stainless steel base frame with casters.

OAD: 98" L x 57"W x 65"H (Batter)
OAD: 87"L x 56"W x 82"H (Breader)
