Thiele, Model 410, automatic, horiztontal, case erector, packer and hot melt glue sealer. Rated from 5 to 20 cases per minute with number of product – depending on materials, application and machine configuration. Maximum case size: 24" in Length; 18" in Width; 12" in Depth. Equipped with a 40" wide x 16" long roller conveyor carton infeed, 48" long 5 band eagle belt 90° transfer into carton upender, 116" long carton accumulation belt with a 1" wide overhead hold down conveyor, single side load ram arm, 30" wide x 84" long powered case magazine, 3 suction cup reciprocating pick and place, 2 lugged chains set on 45" centers, Nordson hot melt glue system and case tipper discharge. Control panel has an AB controller with an AB DL30 display, push button start / stop and run / jog switch. Mounted on heavy duty base frame.
OAD: 290"L x 115"W x 84"H
Thiele, Model T7600, high speed rotary pick and place feeder. Rated from 50 – 250 placements per minute – depending on materials, application and machine configuration. Equipped with a 3¼" wide x 150" long Delrin style conveyor powered by a ½ hp drive, 32" long timing screw, 76" long single belt powered magazine, (6) head rotary pick and place, Piab vacuum system and reject station. Control panel with an AB PLC and touch screen display.
OAD: 150" L x 50" W x 98" H
Thiele, automatic, rotary feeder and hot glue system. Rated from 10 to 400 picks per minute – depending on materials, application and machine configuration. Product size: 1½" to 8" in Length; 1½" to 10" in Width. Equipped with 52" long magazine, with (4) head, rotary vacuum suction cup pick n place, Nordson hot melt system, worm screw feed, safety guarding, vacuum pump and motor drive. Control switches for vacuum on / off, glue on / off and push button start / stop / manual glue. Mounted on "H" style base frame.
OAD: 88" L x 48" W x 76" H
Thiele, automatic, rotary feeder. Rated from 10 to 400 picks per minute – depending on materials, application and machine configuration. Product size: 1½" to 18" in Length; 1½" to 20" in Width. Equipped with 18" long magazine, with (4) head, rotary vacuum suction cup pick n place, safety guarding, vacuum pump and motor drive. Control switch for vacuum on / off and push button start. Mounted on "H" style base frame.
OAD: 57" L x 46" W x 75" H
Thiele, Model T7500, topsert feeder. Rated from 25 to 400 picks per minute – depending on materials, application and machine configuration. Product size range: 1" to 7" in Width x 1" to 5" in Length. Equipped with a 51" long (2) belt powered product magazine, (4) head rotary pick n place, vacuum pump and drive motor. Control panel with an AB PLC.
OAD: 87"L x 50"W x 57"H
Thiele, shrink bundling system with right angle laner infeed. Rated from 10 to 30 bundles per minute – depending on materials, application pack pattern and machine configuration. Maximum product height: 6¼"; maximum film width: (2) 13" rolls. Equipped with a 9" wide x 115" long 1 to 3 lane 90° infeed, (2) pusher plate feeders, 27" wide seal bar, product hold down clamp, stainless steel shrink tunnel with 32" wide x 15" high aperture and 48" long chamber with 30" wide x 94" long thru belt conveyor and 36" discharge height. All stainless steel frame and enclosure with lexan doors and machine leveling pads and casters. Fully automated with AB PLC rack and AB PanelView Plus 600 touch screen display, digital temp controllers for heat tunnel and seal bars with statis light bar. Mounted on base frame with leveling legs.
OAD: 180" L x 160" W x 90" H
Thiele, automatic, reciprocating feeder. Rated from 10 to 45 cycles per minute – depending on materials, application and machine configuration. Product size: 1½" to 34" in Length; 1½" to 22" in Width. Equipped with 24" long adjustable magazine, (8) vacuum suction cup pick n place, safety guarding and vacuum pump. Control switches for on / off, vacuum on / off and push button cycle. Mounted on H style base frame.
OAD: 84" L x 68" W x 84" H
Thiele, automatic, reciprocating feeder. Rated from 10 to 45 cycles per minute – depending on materials, application and machine configuration. Product size: 1½" to 43" in Length; 1½" to 10" in Width. Equipped with 36" long adjustable magazine, (8) vacuum suction cup pick n place, safety guarding and vacuum pump. Controled by a AB Panelview Plus 600. Mounted on H style base frame.
OAD: 58" L x 52" W x 66" H
Thiele, semi-automatic, reciprocating feeder. Rated from 10 to 45 cycles per minute – depending on materials, application and machine configuration. Product size: 1½" to 22" in Length; 1½" to 22" in Width. Equipped with 18" long adjustable magazine, (27) vacuum suction cup pick n place, safety guarding and vacuum pump. Control switches for on / off, vacuum on / off and product pick / drop. Mounted on H style base frame.
OAD: 68"L x 35"W x 77"H
Thiele, automatic, reciprocating feeder. Rated from 10 to 45 cycles per minute – depending on materials, application and machine configuration. Product size: 1½" to 21" in Length; 1½" to 34" in Width. Equipped with 24" long adjustable magazine, (8) vacuum suction cup pick n place, safety guarding and vacuum pump. Control switches for on / off, vacuum on / off and recycle / cycle. Mounted on H style base frame.
OAD: 84" L x 66" W x 84" H
Thiele Model Automatic, intermittent motion, tray erector, end load tray packer capable of speeds from 5 to 30 trays per minute – depending on material and application. Tray size range of: 8" to 15" in Length x 4" to 21" in Width x 1-1/2" to 6" in Depth blank tray magazine with reciprocating pic in place feeder, leaflet magazine, 48" Long x 3" Wide product in feed conveyor currently set on 6" centers, mechanical pusher tray loader, Nordson hot melt glue system, with compression section discharge. A/B PLC controller with A/B Dataliner and Eletrocam 5000 PLS controls and statis light bar. Mounted on heavy duty frame with safety guarding.
OAD: 21′ L x 8′ W x 7′ H
