California Pellet Mill Mill Pellet CL

  Back to All Equipment

California Pellet Mill, Model CL, Laboratory size pellet Mill. Rated from 30 to 200 pounds of pellets per hour – depending on materials, application and machine configuration. Equipped with a 17" long x 13" wide x 17" deep product hopper, 4" wide x 20" long vibratory feeder, 36" long x 4" diameter continuous paddle mixer and conditioner powered by a ¾ hp drive, 7" long x 1½" diameter auger feeder powered by a (1/3) hp drive and pellet mill housing powered by a 2 hp drive with a 5" wide discharge chute with 15" ground clearance. Control panel with push button start / stop for mill, auger and mixer. On / off switch and variable speed dial for vibratory feeder. System mounted on a painted base frame with casters.

OAD: 60"L x 35"W x 86"H

The Frain Advantages

  • Complete Line Integration
  • Machinery Retrofit and Recondition
  • In-House Testing, Proof of Concept, Trial Runs
  • On-Site Installation and Training
  • Factory Acceptance Testing
  • 35 Years In Business

630-629-9900

Call us to discuss your packaging or processing project with an experienced Frain Industries engineer

Related Mill Equipment
