Inever Group / Matrix Form & Fill Liquid/Paste MLS6/10

  Back to All Equipment

Inever Pack / Matrix Model MLS6/10, stainless steel, 10 head, vertical, stick pack, form / fill / seal machine rated up to 450 packets per minute – depending on materials and application. Minimum / Maximum packet size range: 17mm to 25mm in Width; 60mm to 200mm in Length. Equipped with stainless steel pressurized product hopper has sanitary pistons with liquid dosers and servo drives, both mounted above stick pack machine with CIP and ultrasonic level controls. Film slitters and forming tubes, with (10) 1" OD filling nozzles set on 2-1/2" centers, and 1" long vertical lap sealer with 25" wide cross-cut seal bars. Maximum film reel diameter of 600mm and maximum reel width of 600mm and has film registaration with 120" long x 2-1/4" wide incline cleated discharge conveyor with 3/4" wide x 3/4" high cleats set on 2-1/4" centers. Control panel has PLC controller with touch pad controls and readout, servo drives with vari-speed controller and start, stop, reset, e-stop push buttons and hand held controller. Stick Pack machine mounted on stainless steel base frame with interlock safety doors and statis light.

OAD: 80" L x 84" W x 89" H Stick Pack
120" L x 27" W x 56" H Inclined Conveyor
