MRM Elgin Filler Liquid Pos Disp RPF-8

  Back to All Equipment

MRM Elgin, Model RPF-8, Automatic, 8-hd left to right, rotary piston filler rated from 30 to 150 containers per minute – depending on materials and application. Fill range: up to 35oz with accuracies + / – 1/4 of 1% depending on product. Maximum container size: up to 6" in Diameter; up to 12" in Height. Equipped with 3¼" wide conveyor, worm screw to star wheel in feed, 13½" diameter x 22" deep (14 gallon) stainless steel reservoir with level detector, 7" x 6" container pedestals, (8) (4" ID x 7-1/2") pistons, with 5/8" OD nozzles set on 8" centers, drip trough, no container / no fill, E-stop and safety guarding. Mounted on stainless steel frame.

OAD: 128"L x 54"W x 80"H
