Grinders are designed to grind different kinds of products. Grinders are used to reduce the size of a product or material to facilitate in the subsequent processing of that product. Grinders are used in a wide array of industries and are adapted to the product being grinded. Meat grinders take in fresh or frozen meats or poultry and reduce it down to size using a cutting and compression screw in a fluted barrel.
Rietz, Model RE15-K5E328, stainless steel extructor designed for grinding frozen, partially frozen, or thawed 40 lb blocks of product from 40 to 30,000 lbs of product per hour – depending on materials, application and machine configuration. Equipped with 28" x 21" OD (23" x 15" ID) crevice free product hopper, with 6" OD shaft and 4" x 2" stationary anvils, with 15" ID product reduction port. Chain to sprocket 40 Hp motor drive with safety guarding. Mounted on heavy duty (4) leg base frame. Reduction screen is change part per application.
OAD: 82" L x 34" W x 75" H
Rietz Model RE24K7E,Stainless steel, extructor, designed for grinding frozen, partially frozen, or fully thawed 40 lb blocks of product and is rated from 40 to 30,000 lbs per hour – depending on materials and application. Equipped with 30" long x 27" wide x 34" deep stainless steel crevice free product hopper with (6) 10" long x 7" high hammer blades on 8" OD shaft and (6) 5" long x 8 high stationary anvils (no knives / no sharpening, low maintenance), 24" ID rotary product reduction port, with swing open, bolt down cover, reduction screen (change part per application) with 75" floor clearance, chain to sprocket 40 Hp motor drive with safety guarding, start / stop push button controls, with e-stop. Mounted on (4) leg bolt down base frame. Reduction screen is change part per application.
OAD: 90" L x 48" W x 107" H
Rietz, Model RE-24, Stainless steel extructor designed for grinding frozen, partially frozen, or fully thawed 40 lb blocks of product and is rated from 40 lbs to 30,000 lbs per hour – depending on materials, application and machine configuration. Equipped with 37" long x 32" wide x 37" deep stainless steel product hopper, (9) 3" wide x 10" high hammer blades on 7" OD shaft and (8) 5" long x 7" high stationary anvils, 24" ID rotary product reduction port, with swing open, bolt down cover, reduction screen (change part per application) and (6) blade cut off knife with 55" floor clearance, chain to sprocket 60 Hp motor drive with safety guarding. Mounted on (4) leg bolt down stainless steel base frame. Reduction screen is change part per application.
OAD: 109" L x 53" W x 112" H
Weiler, Model 878, heavy duty grinder. Equipped with 22" in Length; 17" in Width; 18" in Depth product chamber with 40" Long x 7" OD grinding screw with 8" OD self-sharpening cut off blades, 7½"ID threaded product discharge port with 8-5/8" diameter plate and has 42" floor clearance. Powered by 15 Hp motor with start, stop and e-stop push button controls. Mounted on (4) leg base frame.Capable of doing fresh or pre-broken frozen product.Rate dependent on raw material, material temperature, machine configuration and reduction size.
OAD: 75"L x 38"W x 64"H
Weiler Model 1109, heavy duty, grinder capable of grinding from 1000 to 72,000 lbs of product per hour – depending on materials and application. Equipped with 32" in Length; 24" in Width; 30" in Depth product hopper with 42" Long x 9" OD grinding screw and 10" OD self sharping cut off blades with 11" OD, 10" ID threaded product discharge port with screen holder trolley and 36" floor clearence, 50 Hp motor drive with start, stop and e-stop push button controls. Mounted on (4) leg base frame. Used for coarse and finish grind, pre-broken and frozen blocks, fresh and rendering processes for most meat / meat bone, seafood, fruit, cheese and fats.
OAD: 80" L x 45" W x 85" H
Weiler Model 1102, heavy duty, grinder capable of grinding from 500 to 4,000 lbs of product per hour – depending on materials and application. Equipped with 60" in Length; 60" in Width; 36" in Depth product hopper with 48" Long x 7" OD grinding screw and 10" OD self sharping cut off blades with 11" OD, 10" ID threaded product discharge port screen holder trolley and 48" floor clearence, 50 Hp motor drive with start, stop, and e-stop push button controls. Mounted on (4) leg base frame. Used for coarse grind as well a fresh and rendering processes for most meat bones and fat.
OAD: 84" L x 60" W x 90" H
Weiler Model 1102, heavy duty, grinder capable of grinding from 500 to 4,000 lbs of product per hour – depending on materials and application. Equipped with 60" in Length; 60" in Width; 36" in Depth product hopper with 48" Long x 7" OD grinding screw and 10" OD self sharping cut off blades with 11" OD, 10" ID threaded product discharge port with screen holder trolley and 48" floor clearence, 50 Hp motor drive with start, stop and e-stop push button controls. Mounted on (4) leg base frame.Used for coarse grind as well a fresh and rendering processes for most meat bones and fat.
Rietz Model RE24K7E333, Stainless steel extructor, designed for grinding frozen, partially frozen, or fully thawed 40 lb pound blocks of product rated from 40 to 30,000 lbs per hour – depending on materials and application. Equipped with 30" long x 27" wide x 34" ID stainless steel crevice free product hopper with (6) 10" long x 7" high hammer blades on 8" OD shaft and (6) 5" long x 8 high stationary anvils (no knives / no sharpening, low maintenance), 24" ID rotary product reduction port, with swing open, bolt down cover, reduction screen (change part per application) with 47" floor clearance, chain to sprocket 30 Hp motor drive with safety guarding. Mounted on (4) leg base frame.Reduction screen is change part per application.
OAD: 95" L x 45" W x 111" H
Weiler, Model 1167, heavy duty, stainless steel grinder rated from 500 to 18,000 lbs of product per hour – depending on materials and application. Equipped with 22" long x 17" wide x 20" deep product hopper, 42" long x 7" OD grinding screw with 10" OD self sharping cut off blades and 11" 0D, 10" ID threaded product discharge port with reduction screen holder and 48" floor clearence. Start, stop, and e-stop push button controls, 40 Hp drive with GE 100 amp disconnect switch. Mounted on stainless steel (4) leg platform. Used for coarse grind as well as fresh and rendering processes for most meat, bones and fat.
OAD: 104" L x 74" W x 88" H
Rietz Model RE24K7E333, Stainless steel extructor designed for grinding frozen, partially frozen, or fully thawed 40 lb pound blocks of product rated from 40 to 30,000 lbs per hour – depending on materials and application. Equipped with 30" long x 27" wide x 34" ID stainless steel crevice free product hopper and has (6) 10" long x 7" high hammer blades on 8" OD shaft, (6) 5" long x 8 high stationary anvils 24" ID rotary product reduction port with swing open bolt down cover, reduction screen (change part per application), 23" diameter x 35" long discharge chute with 39" floor clearance, chain to sprocket 30 Hp motor drive with safety guarding. Mounted on (4) leg base frame.Reduction screen is change part per application.
OAD: 120" L x 55" W x 92" H
Rietz Model RE24K7E333, Stainless steel extructor designed for grinding frozen, partially frozen, or fully thawed 40 lb pound blocks of product and is rated from 40 to 30,000 lbs per hour – depending on materials and application. Equipped with 30" long x 27" wide x 34" ID stainless steel crevice free product hopper with (6) 10" long x 7" high hammer blades on 8" OD shaft and (6) 5" long x 8 high stationary anvils (no knives / no sharpening, low maintenance), 24" ID rotary product reduction port, with swing open, bolt down cover, reduction screen (change part per application), chain to sprocket 40 Hp motor drive with safety guarding. Mounted on (4) leg base frame. Reduction screen required per application.
OAD: 97" L x 50" W x 135" H
Rietz Model RE24K7E333, stainless steel extructor, designed for grinding frozen, partially frozen, or fully thawed 40 lb pound blocks of product and is rated from 40 to 30,000 lbs per hour – depending on materials and application. Equipped with 30" long x 27" wide x 34" ID stainless steel crevice free product hopper with (6) 10" long x 7" high hammer blades on 8" OD shaft and (6) 5" long x 8 high stationary anvils (no knives / no sharpening, low maintenance), 24" ID rotary product reduction port, with swing open, bolt down cover, reduction screen (change part per application). Chain to sprocket with 30 Hp motor drive with safety guarding. Mounted on (4) leg base frame.Reduction screen is change part per application.
OAD: 87" L x 50" W x 126" H
