Cherry Burrell Machines

Cherry Burrell Aerosol Filler FFH8

• Manufacturer: Cherry Burrell
• Model Number: FFH8
• Frain Number: 5D9454

Low capacity ingredient feeder capable of 80 to 900 gph of ice cream throughput. Has 3/4 cu.ft. stainless steel ingredient hopper with gentle mixing action, 3" dia x 12"H downstream product blender, 2 1/2" threaded O.D. inlet, 2 1/2" threaded I.D. outlet, spinning disc in hopper to meter ingredients into product stream, and rotary disc to mix product in product stream. Mounted on casters. Incorporates exact amounts of wet or dry ingredients into the finished ice cream.

OAD: 31"L x 24"W x 54"H

Cherry Burrell Tank SS Single Wall 2200 GAL

• Manufacturer: Cherry Burrell
• Model Number: 2200 GAL
• Frain Number: 5H0422

Cherry Burrell, 2,200 gallon, 304 stainless steel, single wall tank. Vessel Dimensions: 80" diameter x 96" straight wall. Equipped with dome top, 20" x 15" side bottom bolt down man way. Cone bottom with 8" diameter flanged style bottom discharge with 28" floor clearance. Mounted on (4) tube legs.

Top Access:
(1) 4" NPT
(1) 4" Flange
(1) 2" Flange
(1) 2"OD / 1½"ID Tri-clamp
(3) ¾" NPT

OAD: 90"L x 80"W x 180"H

Cherry Burrell Tank SS Single Wall 66 GAL

• Manufacturer: Cherry Burrell
• Model Number: 66 GAL
• Frain Number: 5C2364

Cherry Burrell, 316L Stainless steel tank with KYNAR (Polypropylene) Lining- 265 liter capacity, pressure rated to 15 psi / 300F. Minimum metal temperature rating -20F / 15 psi. Domed top with 16" man way and a total of 6 tri-clover ports of various size. Inside dimensions: 34" straight wall – 29" diameter. Dish bottom with 1 1/4" tri-clover center discharge and temperature probe port. National Board #3218. Locking caster base with side handles.

OAD = 40" x 42" x 68" H

Cherry Burrell Tank SS Single Wall 66 GAL

• Manufacturer: Cherry Burrell
• Model Number: 66 GAL
• Frain Number: 5C2363

Cherry Burrell, 316 Stainless Steel Solution Tank with KYNAR (Polypropylene) Lining- 265 liter capacity, pressure rated to 15 psi / 300F. Minimum metal temperature rating -20F / 15 psi. Domed top with 16" man way and a total of 6 tri-clover ports of various size. Inside dimensions: 30" straight wall – 30" diameter. Dish bottom with 1 1/4" tri-clover center discharge and temperature probe port. National Board #3219. Locking caster base with side handles.
OAD = 40" x 42" x 68" H

Cherry Burrell Tank SS Single Wall 6000GAL

• Manufacturer: Cherry Burrell
• Model Number: 6000GAL
• Frain Number: 5H0961

Cherry Burrell, 6000 Gallon, 304 stainless steel, insulated mixing tank. Vessel Dimensions: 110" diameter x 144" straight wall. Equipped with a dome top, dish bottom, 20" x 16" side manway with bolt down cover, Paddle agitation powered by a 2 hp drive, thermowell, CIP spray ball supplied by a 2"OD / 1½"ID Tri-Clamp fitting and 2½"OD / 2"ID Tri-clamp style bottom discharge with pneumatic ball valve and 28" ground clearance.

Top Access:
(1) 3½"OD / 3"ID Tri-Clamp
(3) 2½"OD / 2"ID Tri-Clamp
(1) 2" NPT

OAD: 120"L x 115"W x 230"H

Cherry Burrell Mixer Liquid Liquefier 100GAL

• Manufacturer: Cherry Burrell
• Model Number: 100GAL
• Frain Number: R28714

Cherry Burrell, 100 gallon 304 stainless steel liquefier. Chamber dimensions: 35" x 35" with 20" straight wall. Equipped with 24" OD top man way with flip up bolt down cover, bottom 6 hole / 3 wing general purpose impeller and 2½" OD / 2" ID sanitary side bottom discharge with 18" floor clearence, bottom side mounted 15 Hp motor drive. Mounted on stainless steel (4) leg tubular frame.

Top Access:
(2) 2½"OD / 2"ID Tri-Clamp
(1) 1"OD / ¾"ID Tri-Clamp
(1) 3" OD Open Vent

OAD: 60"L x 35"W x 60"H

Cherry Burrell Tank SS Single Wall FH

• Manufacturer: Cherry Burrell
• Model Number: FH
• Frain Number: 5G7988

Cherry Burrell, 2800 gallon, 304 stainless steel insulated horizontal tank. Vessel Dimensions: 84" diameter x120" straight wall with dish ends. Equipped with a 20" x 16" front end man way with flip open cover, 1½ Hp top mounted 21" wide paddle style mixer, (2) CIP spray balls, (1) thermowell, (1) diaphragm pressure sensor and a 2½" OD/2" ID Tri-clamp style butterfly valve discharge fitting with 10½" ground clearance. Mounted on (6) tubular legs.

Top Ports:
(1) 2"OD / 1½"ID Tri-clamp
(1) ½" NPT

Front Ports:
(1) 2½"OD/2"ID Tri-clamp
(1) 2"OD/1½"ID Tri-clamp
(1) 1" NPT

OAD: 170"L x 90"W x 123"H

Cherry Burrell Tank Processors 2400 GAL

• Manufacturer: Cherry Burrell
• Model Number: 2400 GAL
• Frain Number: 5E5520

Cherry Burrell, 2400 gallon total, 600 gallon each, (4) chamber, 304 S/S, insulated mix / blend tank. Each chamber has dimensions of: 56" L x 61" W x 57" Deep, 18" OD man way, flip-up bolt down cover, top mounted twin blade agitator, with 3/4 Hp motor drive, CIP spray ball, product measuring stick, (1) 2 1/2" and (1) 4" sanitary top ports, with side wall product temperature gauge. Slant bottom has 3 1/2" OD sanitary side bottom discharge with 7" floor clearance, rectangle construction for maximum capacity in small floor area and is mounted on (10) S/S legs.

OAD: 217" L x 65" W x 79" H

Cherry Burrell Tank SS Single Wall CV

• Manufacturer: Cherry Burrell
• Model Number: CV
• Frain Number: 5H0011

Cherry Burrell, Model CV, 1000 gallon, 304 stainless steel, single wall tank. Vessel Dimensions: 65" diameter x 80" deep with a 64" straight wall. Equipped with dome top, 20" x 16" side entry bolt down man way and bottom side mounted 16" diameter prop agitation powered by a 1½ hp drive. Dish bottom with 2½" OD / 2"ID seated bevel style bottom discharge with 11" floor clearance. Mounted on (4) tube legs.

Top Access:
(2) 2½"OD / 2"ID Seated Bevel
(2) 2"OD / 1½"ID Seated Bevel
(1) 3" Open Vent

Side Access:
(1) 2"OD / 1½"ID Tri-clamp

OAD: 80"L x 75"W x 100"H

Cherry Burrell Tank SS Single Wall 4000GAL

• Manufacturer: Cherry Burrell
• Model Number: 4000GAL
• Frain Number: 5H0965

Cherry Burrell, 4000 Gallon, 304 stainless steel, single wall mixing tank. Vessel Dimensions: 84" diameter x 170" straight wall. Equipped with a dome top, dish bottom, 20" x 16" side manway with bolt down cover, 19" diameter top manway with bolt down cover, (3) Paddle agitation powered by a 2.4/4.5 hp drive, CIP spray ball supplied by a 2"OD / 1½"ID Tri-Clamp fitting and 3½"OD / 3"ID seated bevel style bottom discharge with 20" ground clearance.

Side Access:
(1) 6"OD / 2"ID Flange
(1) 1" NPT

Top Access:
(2) 3½"OD / 3"ID Tri-Clamp
(3) 3½"OD / 3"ID Seated Bevel
(1) 3"OD Open Vent

OAD: 94"L x 84"W x 240"H

Cherry Burrell Tank SS Single Wall 6000GAL

• Manufacturer: Cherry Burrell
• Model Number: 6000GAL
• Frain Number: 5H0962

Cherry Burrell, 6000 Gallon, 304 stainless steel, single wall mixing tank. Vessel Dimensions: 110" diameter x 144" straight wall. Equipped with a dome top, dish bottom, 20" x 16" side manway with bolt down cover, Paddle agitation powered by a 2 hp drive, thermowell, pressure sensor, CIP spray ball supplied by a 2"OD / 1½"ID Tri-Clamp fitting and 4½"OD / 4"ID Tri-clamp style bottom discharge with 28" ground clearance.

Top Access:
(1) 3½"OD / 3"ID Tri-Clamp
(2) 2½"OD / 2"ID Tri-Clamp
(2) 2"OD / 1½"ID Tri-Clamp

OAD: 120"L x 115"W x 230"H

Cherry Burrell Tank SS Single Wall 6000GAL

• Manufacturer: Cherry Burrell
• Model Number: 6000GAL
• Frain Number: 5H0960

Cherry Burrell, 6000 Gallon, 304 stainless steel, insulated mixing tank. Vessel Dimensions: 110" diameter x 144" straight wall. Equipped with a dome top, dish bottom, 20" x 16" side manway with bolt down cover, Paddle agitation powered by a 2 hp drive, thermowell, CIP spray ball supplied by a 2"OD / 1½"ID Tri-Clamp fitting and 2½"OD / 2"ID Tri-clamp style bottom discharge with pneumatic ball valve and 28" ground clearance.

Top Access:
(1) 3½"OD / 3"ID Tri-Clamp
(3) 2½"OD / 2"ID Tri-Clamp
(1) 2" NPT

OAD: 120"L x 115"W x 230"H
