Cherry Burrell Machines

Cherry Burrell Tank SS Single Wall 6 CHAMBER

• Manufacturer: Cherry Burrell
• Model Number: 6 CHAMBER
• Frain Number: 5H6090

Cherry Burrell, 3000 gallon total, 304 stainless steel (6) chamber flavor tank; (4) 600 gallon chambers and (2) 300 gallon chambers.

Each 600 gallon chamber has 75" long x 48" wide x 40" deep dimensions and is equipped with an 18" manway with clamp down cover, (2) 2½" OD / 2" ID tri-clamp top fittings, 32" diameter prop agitation powered by ¾ Hp drive and 2½" OD / 2" ID discharge with 21" ground clearance.

Each 300 gallon chamber has 75" long x 24" wide x 40" deep dimensions and is equipped with an 18" manway with clamp down cover, (2) 2½" OD / 2" ID tri-clamp top fittings, 18" diameter paddle agitation powered by a ¾ hp drive and 2½" OD / 2" ID discharge with 21" ground clearance.

OAD: 264"L x 86"W x 96"H

Cherry Burrell Tank SS Single Wall 2750GAL

• Manufacturer: Cherry Burrell
• Model Number: 2750GAL
• Frain Number: R29770

Cherry Burrell, 2,750 gallon capacity, 316 stainless steel insulated mixing tank. Vessel dimensions: 84" diameter x 115" straight wall with slant style bottom. Equipped with an 18" diameter lift up and clamp down man way, CIP spray balls supplied by a 2½"OD / 2"ID Tri-Clamp fitting, (3) thermowells, 3 Hp top mounted prop agitator and 2½" ID side discharge with 16" ground clearance.

Top Ports:
(3) 2½" OD / 2" ID Tri-Clamp

OAD: 108"L x 90"W x 166"H

Cherry Burrell Tank SS Single Wall 375 GAL

• Manufacturer: Cherry Burrell
• Model Number: 375 GAL
• Frain Number: 5D6813

375 total gallon 304 S/S tank (with 3 sections of 125 gallons). Each compartment equipped with agitation, 14" man way with lift-off cover, 1-1/2" ID sanitary inlet and 1-1/2" sanitary bottom side discharge.

OAD: 85" L x 41" W x 81" H

Cherry Burrell Aerosol Filler FFH8

• Manufacturer: Cherry Burrell
• Model Number: FFH8
• Frain Number: 5D9454

Low capacity ingredient feeder capable of 80 to 900 gph of ice cream throughput. Has 3/4 cu.ft. stainless steel ingredient hopper with gentle mixing action, 3" dia x 12"H downstream product blender, 2 1/2" threaded O.D. inlet, 2 1/2" threaded I.D. outlet, spinning disc in hopper to meter ingredients into product stream, and rotary disc to mix product in product stream. Mounted on casters. Incorporates exact amounts of wet or dry ingredients into the finished ice cream.

OAD: 31"L x 24"W x 54"H

Cherry Burrell Tank SS Single Wall 2200 GAL

• Manufacturer: Cherry Burrell
• Model Number: 2200 GAL
• Frain Number: 5H0422

Cherry Burrell, 2,200 gallon, 304 stainless steel, single wall tank. Vessel Dimensions: 80" diameter x 96" straight wall. Equipped with dome top, 20" x 15" side bottom bolt down man way. Cone bottom with 8" diameter flanged style bottom discharge with 28" floor clearance. Mounted on (4) tube legs.

Top Access:
(1) 4" NPT
(1) 4" Flange
(1) 2" Flange
(1) 2"OD / 1½"ID Tri-clamp
(3) ¾" NPT

OAD: 90"L x 80"W x 180"H

Cherry Burrell Tank SS Single Wall 66 GAL

• Manufacturer: Cherry Burrell
• Model Number: 66 GAL
• Frain Number: 5C2364

Cherry Burrell, 316L Stainless steel tank with KYNAR (Polypropylene) Lining- 265 liter capacity, pressure rated to 15 psi / 300F. Minimum metal temperature rating -20F / 15 psi. Domed top with 16" man way and a total of 6 tri-clover ports of various size. Inside dimensions: 34" straight wall – 29" diameter. Dish bottom with 1 1/4" tri-clover center discharge and temperature probe port. National Board #3218. Locking caster base with side handles.

OAD = 40" x 42" x 68" H

Cherry Burrell Tank SS Single Wall 66 GAL

• Manufacturer: Cherry Burrell
• Model Number: 66 GAL
• Frain Number: 5C2363

Cherry Burrell, 316 Stainless Steel Solution Tank with KYNAR (Polypropylene) Lining- 265 liter capacity, pressure rated to 15 psi / 300F. Minimum metal temperature rating -20F / 15 psi. Domed top with 16" man way and a total of 6 tri-clover ports of various size. Inside dimensions: 30" straight wall – 30" diameter. Dish bottom with 1 1/4" tri-clover center discharge and temperature probe port. National Board #3219. Locking caster base with side handles.
OAD = 40" x 42" x 68" H

Cherry Burrell Tank SS Single Wall 6000GAL

• Manufacturer: Cherry Burrell
• Model Number: 6000GAL
• Frain Number: 5H0961

Cherry Burrell, 6000 Gallon, 304 stainless steel, insulated mixing tank. Vessel Dimensions: 110" diameter x 144" straight wall. Equipped with a dome top, dish bottom, 20" x 16" side manway with bolt down cover, Paddle agitation powered by a 2 hp drive, thermowell, CIP spray ball supplied by a 2"OD / 1½"ID Tri-Clamp fitting and 2½"OD / 2"ID Tri-clamp style bottom discharge with pneumatic ball valve and 28" ground clearance.

Top Access:
(1) 3½"OD / 3"ID Tri-Clamp
(3) 2½"OD / 2"ID Tri-Clamp
(1) 2" NPT

OAD: 120"L x 115"W x 230"H

Cherry Burrell Mixer Liquid Liquefier 100GAL

• Manufacturer: Cherry Burrell
• Model Number: 100GAL
• Frain Number: R28714

Cherry Burrell, 100 gallon 304 stainless steel liquefier. Chamber dimensions: 35" x 35" with 20" straight wall. Equipped with 24" OD top man way with flip up bolt down cover, bottom 6 hole / 3 wing general purpose impeller and 2½" OD / 2" ID sanitary side bottom discharge with 18" floor clearence, bottom side mounted 15 Hp motor drive. Mounted on stainless steel (4) leg tubular frame.

Top Access:
(2) 2½"OD / 2"ID Tri-Clamp
(1) 1"OD / ¾"ID Tri-Clamp
(1) 3" OD Open Vent

OAD: 60"L x 35"W x 60"H

Cherry Burrell Tank SS Single Wall FH

• Manufacturer: Cherry Burrell
• Model Number: FH
• Frain Number: 5G7988

Cherry Burrell, 2800 gallon, 304 stainless steel insulated horizontal tank. Vessel Dimensions: 84" diameter x120" straight wall with dish ends. Equipped with a 20" x 16" front end man way with flip open cover, 1½ Hp top mounted 21" wide paddle style mixer, (2) CIP spray balls, (1) thermowell, (1) diaphragm pressure sensor and a 2½" OD/2" ID Tri-clamp style butterfly valve discharge fitting with 10½" ground clearance. Mounted on (6) tubular legs.

Top Ports:
(1) 2"OD / 1½"ID Tri-clamp
(1) ½" NPT

Front Ports:
(1) 2½"OD/2"ID Tri-clamp
(1) 2"OD/1½"ID Tri-clamp
(1) 1" NPT

OAD: 170"L x 90"W x 123"H

Cherry Burrell Tank Processors 2400 GAL

• Manufacturer: Cherry Burrell
• Model Number: 2400 GAL
• Frain Number: 5E5520

Cherry Burrell, 2400 gallon total, 600 gallon each, (4) chamber, 304 S/S, insulated mix / blend tank. Each chamber has dimensions of: 56" L x 61" W x 57" Deep, 18" OD man way, flip-up bolt down cover, top mounted twin blade agitator, with 3/4 Hp motor drive, CIP spray ball, product measuring stick, (1) 2 1/2" and (1) 4" sanitary top ports, with side wall product temperature gauge. Slant bottom has 3 1/2" OD sanitary side bottom discharge with 7" floor clearance, rectangle construction for maximum capacity in small floor area and is mounted on (10) S/S legs.

OAD: 217" L x 65" W x 79" H

Cherry Burrell Tank SS Single Wall CV

• Manufacturer: Cherry Burrell
• Model Number: CV
• Frain Number: 5H0011

Cherry Burrell, Model CV, 1000 gallon, 304 stainless steel, single wall tank. Vessel Dimensions: 65" diameter x 80" deep with a 64" straight wall. Equipped with dome top, 20" x 16" side entry bolt down man way and bottom side mounted 16" diameter prop agitation powered by a 1½ hp drive. Dish bottom with 2½" OD / 2"ID seated bevel style bottom discharge with 11" floor clearance. Mounted on (4) tube legs.

Top Access:
(2) 2½"OD / 2"ID Seated Bevel
(2) 2"OD / 1½"ID Seated Bevel
(1) 3" Open Vent

Side Access:
(1) 2"OD / 1½"ID Tri-clamp

OAD: 80"L x 75"W x 100"H
