Circle Machines

Circle Form & Fill Towelette V12BUS5

• Manufacturer: Circle
• Model Number: V12BUS5
• Frain Number: 5D9542

Automatic, vertical, form / fill / seal capable of up to 70 cycles per minute (5 pouches per cycle). Pouches: 2 1/8"L minimum x 2"W minimum. Has 12 3/4"W horizontal sealing jaw, single roll film up to 25" wide, film registration, no-fold pad roll stock cut-off, five 3mL liquid injection pistons, quench seal jaws, air knife, 1-cup vacuum reciprocating pouch pick-off, E-stop, temperature controllers and barrier guarding. Last running 2 15/16"L x 2"W pouch with no-fold pad.

OAD: 81"L x 56"W x 95"H

Circle Form & Fill Towelette V6B2

• Manufacturer: Circle
• Model Number: V6B2
• Frain Number: 5H4261

Circle, Model V6B2, vertical, 2-up, form fill and seal machine. Rated from 10 to 60 cycles per minute – depending on materials and application. Pouch size range: 2¼" to Unlimited in Length; 1" to 7" in Width. Equipped with film slitter, registration, tension assist, film assist pull wheels, 2-up towelette inserter, liquid filling system, tear notch punch, (4) lobe horizontal cross seal arbors, side sealers, cross cut knife. Control panel with visual display. Film specifications: up to 16" in Width; up to 14" in diameter; 3" core. Mounted on height adjustable base frame.

OAD: 70"L x 60"W x 85"H

Circle Form & Fill Liquid/Paste V12

• Manufacturer: Circle
• Model Number: V12
• Frain Number: 5F0060

Circle Model V12, multi-lane, vertical, form / fill / seal machine, rated 10 to 60 cycles per minute – depending on material and application. Pouch size range: 1-1/4" to 12" in Width ; 2-1/8" to unlimited in Length. Equipped with product hopper, side film roll, film pull wheels, four lobe horizontal cross seal arbors, side sealers, slitters, static eliminator, and cut off knifes. Features control panel with PLC controller, 28" wide film roll. Last running in a 6-up configuration.

OAD: 60" L x 72" W x 84" H

Circle Form & Fill Towelette V10

• Manufacturer: Circle
• Model Number: V10
• Frain Number: 5C0721

Towelette pouch packager currently set for a 3 up 16 panel towelette. The towelette is based on 3 – 8" webs, fed thru a 4 fold plow, 9-1/2" cut-off & then fed thru double fold head for insertion into pouch. Final towelette is 2-1/4 x 2-1/2". Packager uses single roll stand for 8" max webs, registered, split & folded thru vertical heat seal section.Now set up for 3 x 3 1/2" wide x 3 1/2" long pouches. Equipped with 5 cc filamatic liquid dosage pumps for moistened towelette applications, UV Light box for towellette material steriliziation & 10" wide x 10′ long discharge conveyor. The complete towellete fan & cross folding plus package film roll stand is unitized on the towellete head.

OPTION: Emboss code in side seal, tear notch

Circle Form & Fill No Filling Head H18P15D

• Manufacturer: Circle
• Model Number: H18P15D
• Frain Number: 5H0063

Circle Packaging, Model H18P15D, servo driven horizontal form fill and seal machine. Rated from 10 to 60 cycles per minute – depending on materials, application and machine configuration. Film Specifications: up to 36" wide on a 3" core. Equipped with an 18" wide x 72" long transfer conveyor into sealing machine. Sealing head set with (15) lanes, (5/16") wide side seals, 18" wide (4) lobe end seal, tear notch station, slitters and knife cut off. Includes (2) stainless steel film roll carts. Control panel for the Circle has an AB controller and an AB PanelView 1000 touch screen display. Branson ultra sonic cutters have independant touch pad controls with display. Conveyor has push button start / stop controls.

OAD: 135"L x 93"W x 81"H

** Available for and additional cost**

24" wide x 60" long infeed conveyor with adjustable lanes and (2) Branson, Model 2000, Ultra Sonic cutting heads mounted on a walking beam.

Circle Form & Fill No Filling Head H6X2Y

• Manufacturer: Circle
• Model Number: H6X2Y
• Frain Number: 5B8086

Horizontal form/fill/seal machine. Unit has 6" wide sealing head and was last running (2) lanes. Adjustable infeed conveyor 8′ long 2 lane system, utilizing 2 chain per lane to lengthen or shorten flighted centers. Film specifications: 3" dia core, max roll diameter of 18". Last running in a pharmaceutical operation. O.A.D 82" L X 50" W X 75" H.

Circle Form & Fill Towelette V12BP4S

• Manufacturer: Circle
• Model Number: V12BP4S
• Frain Number: 5D4621

Vertical, Form, Fill & Seal capable of up to 60 cycles per minute- depending on product and materials. Equipped
with four incoming towel stock in feeds with fold mechanism, towel stock cutting mechanism, towel tucking mechanism, dose pump, four lobe 12"W horizontal seal, seal quench, 90"L x 12"W incline take-away conveyor. Equipped pad sensor and registration. Last running four 2 1/8"W x 3"L pre-swab towellets.

OAD: 100"L x 78"W x 105"H

Emboss date coder and tear notch assembly available at an additional cost.

Circle Form & Fill No Filling Head H12X2D

• Manufacturer: Circle
• Model Number: H12X2D
• Frain Number: 5E9767

Automatic, horizontal, right to left, f/f/s, 4-sided seal, front to back film registration, machine capable of doing up to 40 cycles, and 160 packages per minute (depending on application). Package size range of: (3" – 12"L) x (1" – 4 1/2"W) x (up to 2"H). Has a (84" L x 12" W) "K" style, product infeed conveyor with, slider bed, and (1 1/4" W x 1/4" H) pusher lugs. (2) 12" Wide x 3/4" Thick (3) lobe, cross, and quench sealing bars, side sealers, puller wheels, slitters, and knife cut-off.18" outside diameter film roll, with 3" inside diameter film core, single web centercontrol panel with cross and heater seal, quench, knife, and registration controls, stop / start, with e-stops, and (4) Ogden top / bottom side, and cross heat seal digital readout controllers. Currently set-up on 3 lanes, and was last running in a pharmaceutical operation.

OAD: 168" L x 84" W x 84" H

Circle Form & Fill No Filling Head H12MX4S-11A

• Manufacturer: Circle
• Model Number: H12MX4S-11A
• Frain Number: 5D7692

Fully automatic, left to right, 4-sided seal, continuous rotary motion, horizontal form / fill & seal machine capable of up to 160 packages per minute (40 cycles per minute, four at a time). Packages: (4" – 12")L x (1" – 4 1/2")W x up to 2"H. Features 120"L four lane "K" infeed conveyor with stainless steel slider bed and 3/8"W x 1"H pusher lugs on 11" centers, catch trays below infeed conveyor, two cross seals (first is straight, second is chevron style), 21 1/2"L x 12 1/2"W product outfeed conveyor, UV light above product outfeed. Equipped with Electrocam programable limit switch controller, E-stops, motor speed control, production counter, and controls for conveyor speed, conveyor time delay, outfeed conveyor speed (for shingling), first cross seal heaters (on / off), second cross seal heaters (on / off), first side seal heaters (on / off), and second cross seal heaters (on / off). Mounted on height adjustable feet. Designed for items as diverse as ballpoint pens, cigarette lighters, hardware, coupons, lottery tickets, travelers checks, and medial and operating room devices in sterilizable pouches. Last running 6 1/2"L and 8"L packages , registration

OPTION: Drum roll film printer with 13"W print drum

OAD: 203"L x 51"W x 85"H

Circle Form & Fill Towelette V18VD4C

• Manufacturer: Circle
• Model Number: V18VD4C
• Frain Number: 5E8550

Circle V18VD4C, Vertical, 6-up, servo driven form fill and seal rated 10 to 60 cycles per minute – depending on materials and application. Pouch size range: 2-1/8" to Unlimited in Length; 1-1/2" to 18" in Width. Equipped with powered film unwind, film slitter, registration, tension assist, film assist pull wheels, liquid filling system with six Filamatic pistons, three lobe horizontal cross seal arbors, side sealers, cross cut knife, and a swing arm touch pad controller with visual display. Film specifications: up to 36" in Width; up to 14" in diameter; 3" core. Mounted on height adjustable legs.

Videojet Dataflex inkjet coders available at added cost

OAD: 110" L x 60" W x 100" H

Circle Form & Fill Liquid/Paste V16HS

• Manufacturer: Circle
• Model Number: V16HS
• Frain Number: 5E7164

Multi-lane vertical f/f/s rated 10 to 60 cycles @ minute, number of pouches dependent on application. Pouch size range of: 1 1/4" – 16" W x 2 1/8" – unlimited L. has pull wheels, three lobe horizontal cross, and quench seal arbors, side sealers, cut off knifes, slitters. PLS touch pad PLC controller, single film roll, film registration, and tear notch, design allows a wide range of package sizes to be made with a single set of tooling. Circle’s multi-lane, continuous motion design provides high productive output with controllable filling rates.

OAD: 72" L x 64" W x 88" H

Circle Form & Fill Liquid/Paste V16HS

• Manufacturer: Circle
• Model Number: V16HS
• Frain Number: 5E7163

Circle Model V16HS, multi-lane vertical form, fill, seal machine rated up to 60 cycles @ minute, number of pouches dependent on application. Pouch size range of: 1 1/4" – 16" W x 2 1/8" – unlimited L, has pull wheels, three lobe horizontal cross, and quench seal arbors, side sealers, cut off knifes, slitters,PLS touch pad PLC controller, (4) Omeron right / left side and cross seal controllers, single film roll, film registration. Machines design allows for a wide range of package sizes to be made with a single set of tooling, circle’s multi-lane, continuous motion design provides high productive output with controllable filling rates.

OAD: 72" L x 60" W x 80" H
