Groen Machines

Groen Kettle Double Motion TA-250-SP

• Manufacturer: Groen
• Model Number: TA-250-SP
• Frain Number: 5J6120

Groen, Model RA-250-SP, 304 stainless steel jacketed kettle. Vessel Dimensions: 52" diameter x 38" deep with a 14" straight wall. Equipped with bridge mounted scrape surface agitator, X-mas tree agitation and flip up covers. Dish bottom with 1½" NPT center bottom discharge with ball valve. Mounted on (4) tubular leg frame.

Jacket Fittings: (3) 1½" NPT

MAWP: 60 PSI @ 325° F
Nat’l Brd: 59720

OAD: 55"L x 55"w x 105"H

Groen Kettle Double Motion TDB-40C

• Manufacturer: Groen
• Model Number: TDB-40C
• Frain Number: R40370

Groen, Model TBD-40C, 10 gallon, 316 stainless steel, open top, half jacketed kettle with amount of product per hour – depending on materials and application. Vessel Dimensions: 16½" diameter x 14" deep with 9" straight wall. Equipped with tilt out scrape agitation, with secondary inverted Christmas tree agitator powered by a single ½ hp drive with variable speed control. Tilt out discharge with 21" ground clearance. Control panel with on/off switch and heat control dial.

Jacket Fittings:
(1) ½" NPT
(1) 1¼" NPT

MAWP: 50/FV PSI @ 300°F
MDMT: -20° F @ 50 PSI

Nat’l Brd: 105480

OAD: 45" L x 30" W x 54" H

Groen Heat Exch Scrape Surface DRC536

• Manufacturer: Groen
• Model Number: DRC536
• Frain Number: 5D9130

304 S/S, scrape surface heat exchanger with 7.8 sq. ft. of heat transfer area rated to 250psi @ 100F. Dual jacketed (jackets on both the inner and outer walls) design for cooling with direct expansion refrigerant, chilled water, or water / glycol mixture. Has 5/8" wide product annulus, 7" diameter x 40" high chamber, pump recirculated refrigeration system, Fischer actuator, insulated recirculation tubing, No. 4 sanitary finish on contact parts, automatic temperature controller, Moore valve service transducer, and variable speed rotor.

OAD: 44"L x 39"W x 95"H

Groen Heat Exch Scrape Surface DR4284

• Manufacturer: Groen
• Model Number: DR4284
• Frain Number: 5D0681

Atmospheric continuous scrape surface heat exchanger is constructed of stainless steel with a sanitary design. Unit can concentrate 4000 pounds of caramel syrup per hour with a heat transfer area of approximately 150 sq ft. The tubular sanitary design of the evaporator allows for high working pressures in both jackets allowing for more production in less time. Widely used for syrups, caramel, cereal coatings, candies, salad dressings and sauces. Jacket pressure rating: 120 psi. National Board: 138989

OAD: 84" (L) x 60" (W) x 120" (H)

Groen Kettle Single Motion 60-NSP

• Manufacturer: Groen
• Model Number: 60-NSP
• Frain Number: 5C6160

60 gallon, stainless steel, jacketed kettle. 31" diameter x 24" deep bowl, bridge mounted, flat bar shaped, sweep agitator, with flip top covers. Jacket, rated to 40psi @ 300°F, with (2) 1-1/2" jacket in/outlets. 3" center bottom discharge at 9" floor clearence. Mounted on (3) hip socket mild steel legs, with (2) 1-1/2" in/outlets National Board #28218.

OAD: 46" L x 46" W x 62" H

Groen Kettle Electric TDB-20CTA2

• Manufacturer: Groen
• Model Number: TDB-20CTA2
• Frain Number: R37701

Groen, Model TDB-20CTA2, 316 stainless steel, 20 quart, / 5 gallon capacity, self contained, table top, tilt, electric heated steam jacketed kettle. Equipped with 14" inside diameter x 10" in depth product mix bowl, has twin agitator shaft with scrape surface agitation and on / off switch, side hand lever product tilt discharge, 6KW, built in contactor, temperature control dial and gauge.

2/3 Jackets
MAWP: 50 psi @ 300°F
MDMT: -20° @ 50 psi

Jacket Port:
(1) 1" NPT

Nat’l Brd: 106908

OAD: 30" L x 36" W x 37" H

Groen Kettle Electric TDB-20CTA2

• Manufacturer: Groen
• Model Number: TDB-20CTA2
• Frain Number: R37700

Groen, Model TDB-20CTA2, 316 stainless steel, 20 quart, / 5 gallon capacity, self contained, table top, tilt, electric heated steam jacketed kettle. Equipped with 14" inside diameter x 10" in depth product mix bowl, has twin agitator shaft with scrape surface agitation and on / off switch, side hand lever product tilt discharge, 6KW, built in contactor, temperature control dial and gauge. Mounted on a 28" wide x 31" long x 30" high stainless steel table.

MAWP: 50 psi @ 300°F
MDMT: -20° @ 50 psi

Jacket Port:
(1) 1" NPT

Nat’l Brd: 106912

OAD: 32" L x 30" W x 64" H

Groen Kettle Single Motion 40 GAL RA SP

• Manufacturer: Groen
• Model Number: 40 GAL RA SP
• Frain Number: 5G9659

Groen, 40 gallon capacity, Copper Interior , 304 stainless steel jacketed kettle. Vessel dimensions: 26" diameter x 25" deep with a 12" straight wall. Equipped with lift off covers, bridge mounted sweep agitator, 6" wide stationary baffle and 4" diameter bottom discharge with slide gate valve at 21" ground clearance.

Jacket Ports:
(3) ¾" NPT

MAWP: 125 PSI @ 353°F

OAD: 30"L x 30"W x 67"H

Groen Kettle Electric EE100

• Manufacturer: Groen
• Model Number: EE100
• Frain Number: R31391

Groen, 100 gallon capacity, 316 stainless steel electric kettle. Vessel dimensions: 32" with 32" straight wall. Equipped with a lift up cover, 36 Kw heating system and 2" OD / 1¾" ID bottom side discharge with 12" ground clearance.

MAWP: 30 PSI @ 300°F
MDMT: -20°F @ 30 psi

OAD: 48"L x 48"W x 56"H

Groen Kettle Electric AE180

• Manufacturer: Groen
• Model Number: AE180
• Frain Number: 5J1261

Groen, 80 gallon capacity, 304 stainless steel, self contained, electric jacketed kettle. Has kettle dimensions of: 32" diameter x 28" deep. Equipped with lift up cover, 18 Kw heating system and 3" ID bottom side discharge with 12" ground clearance.

Nat’l Bd: 74259
MAWP: 30 PSI @ 300°F

OAD: 50"L x 48"W x 50"H

Groen Kettle Electric EE100

• Manufacturer: Groen
• Model Number: EE100
• Frain Number: R31390

Groen, 100 gallon capacity, 316 stainless steel electric kettle. Vessel dimensions: 32" with 32" straight wall. Equipped with a lift up cover, 36 Kw heating system and 2" OD / 1¾" ID bottom side discharge with 12" ground clearance.

MAWP: 30 PSI @ 300°F
MDMT: -20°F @ 30 psi

OAD: 48"L x 48"W x 56"H

Groen Kettle Electric EE100

• Manufacturer: Groen
• Model Number: EE100
• Frain Number: R30760

Groen, Model EE-100, 316 stainless steel, 100 gallon self contained electric, steam jacketed kettle. with gallons of product per hour – depending on materials and application. Equipped with one piece hinged flip top cover, full steam jacket MAWP rated to 30 psi @ 300 Deg F. and MDMT rated to -20 Deg F @ 30 psi, (2) 1" OD threaded jacket in / outlets with pressure relief valve. Interior slant bottom with 2"OD / 1½"ID NPT to Tri-Clamp side bottom discharge with 17" floor clearence Control panel has thermostat heat controller and pressure gauge. Mounted (3) height adjustable legs.

OAD: 48"L x 48"W x 56"H
