Kodiak Cartoners Machines


Kodiak Cartoners Machines In Stock

Kodiak Cartoners Cartoner Semi Horiz. Glue (Semi) 901 120

Kodiak Model 901-120, semi automatic, horizontal, continous motion, hot melt glue cartoner rated from 20 to 120 cartons per minute – depending on materials, application and operator dexterity. Carton size range per application. Equppied with (4) chains adjustable set on 12" centers with 2-1/4" wide x 2-1/4" high lugs, 24" long blank carton magazine, recpicating vacuum suction cup pick n place, 70" long product operator load area, Nordson (2) gun hot melt glue system with major and minor flap closers. Control panel has A/B vari-speed controller, with vacuum and glue on / off, run jog and speed control switches, with start, stop and-e-stop push buttons. Mounted on heavy duty base frame with safety door guarding and foot pedal jog.

Emboss Coder Available At Additional Cost

OAD: 216" L x 69" W x 68" H

Get a Free Quote Call: 630-629-9900

Kodiak Cartoners Cartoner Semi Horiz. Glue (Semi) 901-90

Kodiak Model 901-90, semi automatic, horizontal, stainless steel, continous motion, hot melt glue cartoner rated from 30 to 75 cartons per minute – depending on materials, application and operator dexterity. Carton size per application. 1 chain currently set with 11" long x 2" wide fixed carton carriers set on 9" centers. Equipped with 60" long (2) chain carton magazine, (2) head rotary pick n place, 194" long x 4" wide product in feed conveyor, 96" long product load area, (3) head rotary top squaring device, flap closers, (2) gun hot melt glue system and dual 36" long compression belt section. Control panel has A/B controller with touch pad controls and panel view. Mounted on heavy duty base frame with interlocked safety guarding and statis light bar.

OAD: 354" L x 50" W x 87" H

Get a Free Quote Call: 630-629-9900

Kodiak Cartoners Cartoner Semi Horiz. Glue (Semi) 901HD-120

Kodiak Model 901HD-120, semi-automatic, horizontal, hot melt glue cartoner. Rated from 25 to 120 cartons per minute – depending on materials, application, machine configuration and operator dexterity. Carton size range: up to 9-3/4" in Length; 6" in Width; 18" in Depth. Equipped with (4) chains adjustable set on 12" centers with 2¼" wide x 3-7/8" high lugs, 144" long product in feed conveyor, 40" long blank carton magazine with (2) head rotary suction cup pick n place, carton squaring device, 64" long hand load area, Nordson 2-gun hot melt glue system, major and minor flap plows and closers, 10" long compression section with Seko guages and foot pedal indexing. Control panel has push button start / stop, vacuum on / off switch, glue on / off switch, run / jog switch and variable speed. Mounted on stainless steel base frame with casters and leveling legs.

OAD: 216"L x 60"W x 80"H

Get a Free Quote Call: 630-629-9900

Kodiak Cartoners Cartoner Auto Horiz. Glue (Auto) 910SSC-120

Kodiak, Model 910SSC-120, automatic, continous motion, horizontal, hot melt cartoner. Rated from 10 to 120 cartons per minute – depending on materials and application. Carton size: 1" to 4½" length x ½" to 4" width x 3" to 6" depth. Equipped with 2 chain product system currently set with 6" long x 3½ wide fixed floating product carriers set on 6" centers, 2 head roatary pick and place leaflet feeder, 3" wide x 40" long product infeed conveyor, worm screw to star wheel bottle lay down loader, 36" long blank carton magazine, 2 head rotary carton pick n place, 3 chain adjustable carton holder on 6" centers, top squaring device, flap closers, Nordson glue system and dual 16" long compression belt section. Control panel has a Siemens controller with touch pad controls, interlocked safety guarding and status light bar.

OAD: 290"L x 68"W x 106"H

Get a Free Quote Call: 630-629-9900

Kodiak Cartoners Cartoner Semi Vertical Glue 601-120

Kodiak Model 601-120, semi automatic, stainless steel, continuous motion, hot melt glue cartoner rated from 40 to 120 cartons per minute – depending on materials and application. Single chain unit set on 9" centers. Carton size range: 2" to 7" in length; 1/2" to 3" in width; 2" to 7" in depth (with proper change parts). Equipped with 72" long automatic (2) chain blank carton magazine, (2) head rotary pic in place, 48" hand load area each side, minor and major flap closers, Nordson Pro Blue H/M (2) gun glue system. Control panel has A/B controller with saftey guarding and foot pedal jog. Mounted on heavy duty base frame.

OAD: 166" L x 99" W x 66" H
.

Get a Free Quote Call: 630-629-9900

Kodiak Cartoners Cartoner Semi Vertical Glue 601-120

Kodiak Model 601-120, semi automatic, stainless steel, continuous motion, hot melt glue cartoner rated from 40 to 120 cartons per minute – depending on materials and application. Single chain unit set on 9" centers. Carton size range: 2" to 7" in length; 1/2" to 3" in width; 2" to 7" in depth (with proper change parts). Equipped with 4" long x 2" wide x 2" deep fixed plastic carton grippers. 72" long automatic 2 chain blank carton magazine, 2 head rotary pic in place, 48" hand load area each side, minor and major flap closers, Nordson Pro Blue H/M (2) gun glue system. Control panel has A/B controller with saftey guarding and foot pedal jog. Mounted on heavy duty base frame.

OAD: 166" L x 99" W x 66" H

Get a Free Quote Call: 630-629-9900

Kodiak Cartoners Case Set-Up, Tray Tray Tuck 8-11

Kodiak Model 8-11, automatic, 3 head, tuck style, tray former rated from 30 to 150 tray per minute – depending on materials and application. Equipped with (3) 14" wide x 31" long blank tray magazines with (2) suction cup recipicating pic-n-place’s each, (3) diving tray forming heads and 132" long x 8" wide (2) chain lugged tray conveyor, set on 18" centers with 6" high guide rails, Cutler Hammer CPU has on / off, run, jog, jam, vacuum switches with e-stop and safety guarding.

OAD: 144" L x 72" W x 87" H

Get a Free Quote Call: 630-629-9900

Kodiak Cartoners Cartoner Auto Wrap Around 510-80

Kodiak model 510-80 automatic, wrap around, hot melt glue, cartoner with number of cartons per minute – depending on materials and application. Equipped with 66" long x 24" wide product magazine with (4) feed belts, (4) head rotary pick and place, (2) 216" long product in feed conveyors with (2) 36" long single side worm screws, (2) 102" bottom lugged chain product conveyors, (2) 35" long bottom lugged over product chain conveyors, Nordson hot melt glue system, rotary flap closers, 125" long x 4.5" wide overhead Delrin conveyor, (2) 36" long lugged chain side conveyors, 12" long x 7" wide skate conveyor, 24" long x 4" wide belt discharge conveyor. Control panel has PLC controller. Mounted on heavy duty base frame with Interlocking Lexan safety guarding.

OAD: 228" L x 60" W x 72" H

Get a Free Quote Call: 630-629-9900

Kodiak Cartoners Cartoner Auto Horiz. Glue (Auto) 510-9-SS

Kodiak Model 510-9-SS, automatic wraparound glue cartoner, rated from 40 to 120 cartons per minute – depending on materials and application.. Equipped with cup inverter, cup stacker, lugged collation system, powered carton magazine, two head rotary carton pick and place, Nordson hot melt system, Lexan guarding and A/B PLC with Panel View. Capable of doing a double or triple stack.

OAD: 358"L x 54"W x 74"H
