Axon Capper Neck Bander EZ200

  Back to All Equipment
  • Manufacturer: Axon
  • Model: EZ200
  • Frain Number: R30232
  • Category: Capping
  • Subcategory: Neck Bander
  • Condition: Used, in excellent condition
  • Availability: In Stock

Axon, Model EZ-200 automatic, tamper evident shrink neck bander or sleeve label applicator with a Model EZ-24BR shrink tunnel. Rated from 25 to 70 containers per minute – depending on materials, application and machine configuration. Layflat: 50 mm to 112 mm. Band / sleeve height: 25mm to 200 mm. Film thickness 40 to 70 microns. Film specifications: up to 15" diameter roll on a 4(7/8)" core. Neck bander equipped with photo eyes for machine activation, static eliminator, vertical perf, knife film cut off, stepper drive film feed system, air blast band pusher and a touch pad controller with LED display. Shrink tunnel equipped with a 7" high x 7½" wide aperature, 24" long chamber, digital heat controls and pneumatic tunnel lift. System mounted above a stainless steel 4½" wide x 120" long stainless steel tabel top conveyor with variable speed control.

OAD: 120"L x 57"W x 84"H
