Axon Capper Neck Bander EZ200Back to All Equipment
Axon, Model EZ-200 automatic, tamper evident shrink neck bander or sleeve label applicator with a Model EZ-24BR shrink tunnel. Rated from 25 to 100 containers per minute – depending on materials, application and machine configuration. Layflat: 50 mm to 112 mm. Band / sleeve height: 25mm to 200 mm. Film thickness 40 to 70 microns. Film specs: up to 15" OD roll on 4-7/8" OD core. Neck bander equipped with photo eyes for machine activation, static eliminator, vertical perf, knife film cut off, stepper drive film feed system, air blast band pusher and a touch pad controller with LED display.
Shrink tunnel has 7" high x 7½" wide aperature x 24" long chamber, digital heat controls and pneumatic tunnel lift. System mounted above 4½" wide x 120" long stainless steel tabel top belt conveyor with variable speed controls.
OAD: 120"L x 57"W x 84"H
