Photo of Feldmeier Kettle Double Motion 150GAL

Feldmeier Kettle Double Motion 150GAL

  Back to All Equipment

Feldmeier Model 150-44-TMIX, Atmospheric, 150 gallon working capacity, 316 stainless steel contact and 304 stainless steel support materials, jacketed double motion kettle with number of gallons of product per hour – depending on materials and application. Vessel bowl dimensions: 44" ID x 39" deep with #4 polish finish inside and outside with all welds ground flush, polished and buffed for food grade application. Equipped with bridge mounted counter rotating 3 Hp side and bottom scrape surface agitator with nylon scraper blades, 3 Hp secondary turbine impeller (4) 3" OD top ports and CIP spray ball with dual flip top covers. Full jacket with MAWP of 150 psi @ 350 Deg F, MDMT -20 Deg F @ 150 psi with 1.5" NPT jacket in / outlets ports. Dish bttom has 3" ferrule center bottom discharge with 16" floor clearance and product not to exceed 100,000 Cps and is ASME coded. Mounted on (4) stainless steel pipe style hip socket legs with foot pads. NB # 10737

OAD: 57" L x 54" W x 98" H
