Lee Kettle Double Motion 10D9MT

• Manufacturer: Lee
• Model Number: 10D9MT
• Frain Number: 5H7860

Lee, Model 10DPMT, 10 gallon, 316 stainless steel jacketed double motion kettle. Vessel Dimensions: 18" diameter x 13" deep. Equipped with tilt out scrape agitation, 1 hp drive and 2"OD / 1½"ID Tri-Clamp discharge with 216" ground clearance. Mounted on a stainless steel base with casters.

MAWP: FV / 60 psi @ 287°F (Vessel)
MAWP: 40 psi @ 287°F (Jacket)
Nat’l Brd: 3278

Jacket Ports:
(2) ¾" NPT

Top Access:
(1) 4½" OD / 4"ID Tri-Clamp
(3) 2"OD / 1½"ID Tri-Clamp

OAD: 54"L x 38"W x 66"H

Lee Kettle Double Motion D9MS

• Manufacturer: Lee
• Model Number: D9MS
• Frain Number: R31211

Lee Model 500D9MS, 500 gallon, atmosheric design, stainless steel, double motion, scrape surface, 1/2 jacketed kettle with pounds of product per hour – depending on materials and application. 316 stainless steel shell and agitator; 304 stainless steel jacket and channel support on rim, with # 4 finish inside and # 4 finish outside were applicable. Vessel dimensions: 62" ID x 51" in Depth. Equipped with bridge mounted scrape surface, double motion, tilt out agitation with dual flip top covers and has a maximum product visacosity of 100,000 cps. 1/2 jacket, with MAWP of 90 psi @ 332 Deg F and MDMT of -20 Deg F @ 90 psi with (2) 2" OD 1-1/2" ID side and bottom threaded jacket in / outlet ports. 3" OD center bottom discharge has flush-bottom ball valve outlet and sanitory tri-clamp with 16" floor clearence. Mounted on (3) stainless steel legs

OAD: 90" L x 70" W x 90" H

Feldmeier Kettle Double Motion 150GAL

• Manufacturer: Feldmeier
• Model Number: 150GAL
• Frain Number: R31842

Feldmeier Model 150-44-TMIX, Atmospheric, 150 gallon working capacity, 316 stainless steel contact and 304 stainless steel support materials, jacketed double motion kettle with number of gallons of product per hour – depending on materials and application. Vessel bowl dimensions: 44" ID x 39" deep with #4 polish finish inside and outside with all welds ground flush, polished and buffed for food grade application. Equipped with bridge mounted counter rotating 3 Hp side and bottom scrape surface agitator with nylon scraper blades, 3 Hp secondary turbine impeller (4) 3" OD top ports and CIP spray ball with dual flip top covers. Full jacket with MAWP of 150 psi @ 350 Deg F, MDMT -20 Deg F @ 150 psi with 1.5" NPT jacket in / outlets ports. Dish bttom has 3" ferrule center bottom discharge with 16" floor clearance and product not to exceed 100,000 Cps and is ASME coded. Mounted on (4) stainless steel pipe style hip socket legs with foot pads. NB # 10737

OAD: 57" L x 54" W x 98" H

Feldmeier Kettle Double Motion 150GAL

• Manufacturer: Feldmeier
• Model Number: 150GAL
• Frain Number: R31841

Feldmeier Model 150-44-TMIX, Atmospheric, 150 gallon working capacity, jacketed double motion kettle with number of gallons of product per hour – depending on materials and application. 316 stainless steel contact and 304 stainless steel support materials, Vessel bowl dimensions: 44" ID x 39" deep with #4 polish finish inside and outside with all welds ground flush, polished and buffed for food grade application. Equipped with bridge mounted counter rotating 3 Hp side and bottom scrape surface agitator with nylon scraper blades, 3 Hp secondary turbine impeller (4) 3" OD top ports and CIP spray ball with dual flip top covers. Full jacket with MAWP of 150 psi @ 350 Deg F, MDMT -20 Deg F @ 150 psi with 1.5" NPT jacket in / outlets ports. Dish bttom has 3" ferrule center bottom discharge with 16" floor clearance and product not to exceed 100,000 Cps and is ASME coded. Mounted on (4) stainless steel pipe style hip socket legs with foot pads N/B # 10736

OAD: 57" L x 54" W x 98" H

Feldmeier Kettle Double Motion 150GAL

• Manufacturer: Feldmeier
• Model Number: 150GAL
• Frain Number: R31840

Feldmeier Model 150-44-TMIX, Atmospheric, 150 gallon working capacity, 316 stainless steel contact and 304 stainless steel support materials, jacketed double motion kettle with number of gallons of product per hour – depending on materials and application. Vessel bowl dimensions: 44" ID x 39" deep with #4 polish finish inside and outside with all welds ground flush, polished and buffed for food grade application. Equipped with bridge mounted counter rotating 3 Hp side and bottom scrape surface agitator with nylon scraper blades, 3 Hp secondary turbine impeller (4) 3" OD top ports and CIP spray ball with dual flip top covers. Full jacket with MAWP of 150 psi @ 350 Deg F, MDMT -20 Deg F @ 150 psi with 1.5" NPT jacket in / outlets ports. Dish bttom has 3" ferrule center bottom discharge with 16" floor clearance and product not to exceed 100,000 Cps and is ASME coded. Mounted on (4) stainless steel pipe style hip socket legs with foot pads. N/B # 10735

OAD: 57" L x 54" W x 98" H

Lee Kettle Double Motion D9MS

• Manufacturer: Lee
• Model Number: D9MS
• Frain Number: R31210

Lee Model 500D9MS, 500 gallon, atmosheric design, stainless steel, double motion, scrape surface, 1/2 jacketed kettle with pounds of product per hour – depending on materials and application. 316 stainless steel shell and agitator; 304 stainless steel jacket and channel support on rim, with # 4 finish inside and # 4 finish outside were applicable. Vessel dimensions: 62" ID x 51" in Depth. Equipped with bridge mounted scrape surface, double motion, tilt out agitation with dual flip top covers and has a maximum product visacosity of 100,000 cps. 1/2 jacket, with MAWP of 90 psi @ 332 Deg F and MDMT of -20 Deg F @ 90 psi with (2) 2" OD 1-1/2" ID side and bottom threaded jacket in / outlet ports. 3" OD center bottom discharge has flush-bottom ball valve outlet and sanitory tri-clamp with 16" floor clearence. Mounted on (3) stainless steel legs

OAD: 90" L x 70" W x 90" H

Lee Kettle Double Motion 500D9MS 500 Gallon, 316 S/S

• Manufacturer: Lee
• Model Number: 500D9MS
• Frain Number: 5H6840

Lee Model 500D9MS, 500 gallon, 316 stainless steel interior, 304 stainless steel external, double motion, scrape surface, jacketed kettle with pounds of product per hour – depending on materials and application. Vessel dimensions: 62" ID x 51" in Depth. Equipped with bridge mounted scrape surface & conter rotation tilt out agitation, dual flip top covers, 2" OD sanitary center bottom discharge with flush-bottom ball valve. Jacket, with MAWP of 90 psi @ 322 Deg F and MDMT of -20 Deg F @ 90 psi with (2) 2" OD 1-1/2" ID side and bottom threaded jacket in / outlet ports. Mounted on (3) stainless steel legs. National Board #6013.

OAD: 96" L x 68" W x 93" H

Lee Kettle Double Motion 500D9MT 500 gl, 316 S/S

• Manufacturer: Lee
• Model Number: 500D9MT
• Frain Number: 5H6850

Lee Model 500D9MS, 500 gallon, 316 stainless steel interior, 304 stainless steel external, double motion, scrape surface, jacketed kettle with gallons of product per hour – depending on materials and application. Vessel dimensions: 62" ID x 51" in Depth. Equipped with bridge mounted, scrape surface, counter rotating tilt out agitation, with dual flip top covers. Half Jacket, with MAWP of 90 psi @ 322 Deg F and MDMT of -20 Deg F @ 90 psi with (2) 2" OD 1-1/2" ID side and bottom threaded jacket in / outlet ports. Dish bottom has 2" OD sanitary center bottom discharge with 16" floor clearence. Mounted on (3) stainless steel legs. National Board # 9940.

OAD: 96" L x 68" W x 93" H

Lee Kettle Double Motion 80D9MT

• Manufacturer: Lee
• Model Number: 80D9MT
• Frain Number: 5H6260

Lee Model 80D9MT, 80 gallon, 316 stainless steel, double motion, ½ jacketed kettle with pounds of product per hour – depending on materials and application. Vessel Dimensions: 36" ID x 24" Deep with 7" straight wall. Equipped with flush mount sensor, tilt out bridge mounted scrape agitator powered by a single drive and 3½" OD / 3" ID tri-clamp style discharge with ball valve and 18" ground clearance. Mounted on (3) tubular leg frame.

Jacket Fittings: (2) 1" NPT

MAWP: 90PSI @ 332° F
MDMT: -20°F @ 90 PSI

National Board # 9588

OAD: 60"L x 40"W x 62"H

Lee Kettle Double Motion 250 GAL

• Manufacturer: Lee
• Model Number: 250 GAL
• Frain Number: 5H5400

Lee, 250 Gallon, 316 stainless steel jacketed kettle. Vessel Dimensions: 52" diameter x 38" deep with a 16" straight wall. Equipped with a bridge mounted scrape agitator. Dish bottom with pneumatic ball valve and 3½" OD / 3"ID tri-clamp style center bottom discharge with 18" ground clearance. Mounted on (3) tubular leg frame.

Jacket Fittings:
(2) 1½" NPT

Nat’l Brd: 8233
MAWP: 90 PSI @ 332°F
MDMT: -20°F @ 90 PSI

OAD: 70"L x 58"W x 80"H

Lee Kettle Double Motion 500-D9MT

• Manufacturer: Lee
• Model Number: 500-D9MT
• Frain Number: R30780

Lee Model 500D9MT, 500 gallon, 316 stainless steel interior, 304 stainless steel external, double motion, scrape surface, 1/2 jacketed kettle with pounds of product per hour – depending on materials and application. Vessel dimensions: 61" ID x 51" in Depth. Equipped with bridge mounted scrape surface tilt out agitation with dual flip top covers. 1/2 jacket, with MAWP of 90 psi @ 322 Deg F and MDMT of -20 Deg F @ 90 psi with (2) 2" OD 1-1/2" ID side and bottom threaded jacket in / outlet ports. 3" OD center bottom discharge has flush-bottom ball valve and 16" floor clearence. Mounted on (3) stainless steel legs

OAD: 96" L x 70" W x 92" H

Lee Kettle Double Motion 500-D9MT

• Manufacturer: Lee
• Model Number: 500-D9MT
• Frain Number: R30781

Lee Model 500D9MT, 500 gallon, 316 stainless steel interior, 304 stainless steel external, double motion, scrape surface, 1/2 jacketed kettle with pounds of product per hour – depending on materials and application. Vessel dimensions: 61" ID x 51" in Depth. Equipped with bridge mounted scrape surface tilt out agitation with dual flip top covers. 1/2 jacket, with MAWP of 90 psi @ 322 Deg F and MDMT of -20 Deg F @ 90 psi with (2) 2" OD 1-1/2" ID side and bottom threaded jacket in / outlet ports. 3" OD center bottom discharge has flush-bottom ball valve and 16" floor clearence. Mounted on (3) stainless steel legs

OAD: 96" L x 70" W x 92" H
