OrangeWorks Candy Chocolate Melter 20,000 LBS
Back to All EquipmentOrangeWorks, 20,000 lbs, 292 ft³, 304 stainless, horizontal, jacketed, chocolate melting and mixing tank, with pounds of product per hour – depending on materials and application. Inner chamber dimensions: 68" diameter x 139" long. Equipped with 24" boltdown manway, 4" diameter center shaft powered by a 10 hp drive, (4) 33" long x 6" wide paddles, front mounted 4" Tri-clamp discharge with butterfly valve and 14" ground clearance, rear mounted 4" Tri-clamp discharge with butterfly valve and 12" ground clearance, 1" ID / 4¼" OD flange with sample valve and drip tray, flush mounted sensor.
Top Ports:
(4) 4½" ID / 9" OD Flange
(1) 4" Tri-clamp
(5) 2" Tri-clamp
Jacket Ports:
(1) 1" ID / 4¼" OD Flange
(3) ¾" ID 4" OD Flange
MAWP: 149 PSI
OAD: 175" L x 75" W x 90" H
