World Cup Filler Cup Rotary 12-32

  Back to All Equipment

World Cup Model 12-32, automatic, stainless steel, 12 pocket rotary cup filler, die-cut applicator, sealer and over lidder with number on cups per minute – depending om materials and application. Fill range: 1oz to 32 oz. Container size range: up to 4-3/4" in Diameter. Equipped with 12 pocket, 30" rotary turn table, with filler per application, roll stock film heat sealing station, 36" long roller lid magazine, lid applicator and sweep arm reject. Control panel has A/B PLC controller with dropper, heater, filler, bottom up fill, dropper, sealer, lidder and speed on / off switches and digital temperature controller, with variable speed controls and e-stop. Mounted on stainless steel base frame.
Speed dependant on materials, application and machine configuration.
Change charts required to accommodate size ranges.

OAD: 70" L x 70" W x 64" H
