Checkweigher Machines

Used Checkweigher Equipment

Inline CheckweigherA Checkweigher is a machine that checks the weight of a package, product, or carton that travels across the load cell of the machine. Checkweighers are outfitted with different kinds of product reject devices to prevent underweight and overweight packages from proceeding down line.   Checkweighers determine overweight and underweight based on parameter inputs.   Checkweighers are also used to automatically space filled packages, weight them to check the accuracy of the gross weight, segregate the underweight packages, produce feed-back information for controlling the filling operation and perform a number of other control and record keeping operations. As a general rule, the length of the load cell or weigh cell on the checkweigher should be approximately 1.5 times the length of the package to be weighed. (Technically speaking, the package need only be on the load cell by itself for a fraction of a second, so that a checkweigher with a smaller load cell is suitable for a slower moving line.) Different types of checkweighers are designed for different types of products. Some checkweighers can accurately weigh small tablets in a pharmaceutical house and others may weigh large items that weigh several pounds.

Contact Us

Checkweigher Equipment In Stock

Ishida Checkweigher Belt DACS-GS-015-23/SS

  • Manufacturer: Ishida
  • Model Number: DACS-GS-015-23/SS
  • Frain Number: R25480

Ishida DACS, automatic, three zone, stainless steel checkweigher rated up to 300 feet per minute – depending on materials and application. Load cell: 14" in Length; 9.5" in Width. Weight range: 6 to 600 grams or 15 to 1,500 grams. Accuracy: up to +/-0.1grams or +/- 0.2 grams respectively. Equipped with a 14" long by 9.5" wide neoprene infeed conveyor, stainless steel guide rails, 14" long by 9.5" wide neoprene weighing conveyor, two air blast rejects ( one over / one under), 18" long by 9.5" wide neoprene discharge conveyor and touch pad operator interface with visual display. Mounted on a stainless steel frame with height adjustable legs.

OAD: 49" L x 32" W x 57" H

Get a Free Quote Call: 630-629-9900

All Fill Checkweigher Belt EW8

  • Manufacturer: All Fill
  • Model Number: EW8
  • Frain Number: R25090

All Fill Alpha ,Model EW8, inline, stainless steel, 3 zone checkweigher rated from 20 to 100 packages per minute – depending on materials, application and machine configuration. Digital strain gage load cell, can handle packages to 12" in Length; 8" in Width, up to 5 lbs per package with accuracy up to +/- 1.35 grams. Equipped with over, under and on weight load cell with 19" L x 8" W belt conveyor and 13" long x 8" wide in feed and discharge belt conveyors with air ram reject. Control panel with touch pad controls and LED display, direct feedback capability and up to 25 program storage. Mounted on tubular steel frame with height adjustable legs.

OAD: 46" L x 38" W x 37" H

Get a Free Quote Call: 630-629-9900

Ishida Checkweigher Belt DACS-GS-015-23/SS

  • Manufacturer: Ishida
  • Model Number: DACS-GS-015-23/SS
  • Frain Number: R25080

Ishida DACS, automatic, three zone, stainless steel checkweigher rated up to 300 feet per minute – depending on materials and application. Load cell: 14" in Length; 9.5" in Width. Weight range: 6 to 600 grams or 15 to 1,500 grams. Accuracy: up to +/-0.1grams or +/- 0.2 grams respectively. Equipped with a 14" long by 9.5" wide neoprene infeed conveyor, stainless steel guide rails, 14" long by 9.5" wide neoprene weighing conveyor, two air blast rejects ( one over / one under), 18" long by 9.5" wide neoprene discharge conveyor and touch pad operator interface with visual display. Mounted on a stainless steel frame with height adjustable legs.

OAD: 46" L x 32" W x 56" H

Get a Free Quote Call: 630-629-9900

Loma Checkweigher Full case LCW

  • Manufacturer: Loma
  • Model Number: LCW
  • Frain Number: R24750

Loma Model LCW automatic, full case, heavy weight, stainless steel, checkweigher speeds – depending on materials and application. Maximum weight capacity: up to 99 lb. Accuracy: 0.2 oz (6g) Product length: up to 27.5" Product width: up to 20". Equipped with strain gauge load cell and a 24" wide x 29" long case platform with 22" wide white introlx belt. Allen Bradly controls has touch screen controller with up to 240 product memory capacity and statis light bar. Mounted on a stainless steel base frame with height adjustable leveling legs.

OAD: 32" L x 41" W x 59" H

Get a Free Quote Call: 630-629-9900

Ishida Checkweigher Belt DACS-WN

  • Manufacturer: Ishida
  • Model Number: DACS-WN
  • Frain Number: R24560

Ishida, Model DACS-WN-012-SB/PB-I, Automatic, 3-zone, stainless steel, checkweigher rated up to 210 feet per minute – depending on materials and application. Weight range: 10g to 1,200g. Accuracy: +/-0.2g. Equipped with a 13-3/4" long x 8-3/4" wide infeed conveyor, 17-3/4" long x 8-3/4" Wide weigh plate, Lexan safety guarding, 17-3/4" long x 8-3/4" wide discharge conveyor, dual air blast rejects, and a touch pad controller with LED display. Mounted on a height adjustable frame.

OAD: 50"L x 30"W x 63"H

Get a Free Quote Call: 630-629-9900

Ishida Checkweigher Belt DACS-WN

  • Manufacturer: Ishida
  • Model Number: DACS-WN
  • Frain Number: R24032

Ishida, Model DACS-WN-030-SB/PB, Stainless steel checkweigher with dual arm mechanical reject. Load cell: 11-3/4" Long x 8-3/4" Wide Rated from 30 to 3000 grams. Accuracy: up to +/- 0.5g, depending on materials and application. Speed: up to 312 feet per minute Equipped with 11-3/4"L x 8 3/4"W in feed conveyor and 29-1/2"L x 8 3/4"W discharge conveyor, push button operator interface with LED display and reject direction setting. Mounted on height adjustable legs.

OAD: 56" L x 34" W x 64" H

Get a Free Quote Call: 630-629-9900

Loma Checkweigher Full case BCW10962

  • Manufacturer: Loma
  • Model Number: BCW10962
  • Frain Number: R23081

Full case checkweigher capable of up to 38 cases per minute – depending on materials and application. Weight capacity: up to 100 lb. Equipped with 24" wide x 28" long weigh platform with a 20" wide belt. Height adjustable legs.

OAD: 44"(L) x 31"(W) x 80"(H)

Get a Free Quote Call: 630-629-9900

CEIA / Heat & Control Checkweigher Metal Detector Combo THS/SL/G1000-02

  • Manufacturer: CEIA USA Ltd
  • Model Number: THS/SL/G1000-02
  • Frain Number: 5G3723

Combination CEIA Model THS/SL metal detector / Delford Model G1000-02 Sortaweigh checkweigher with number of product per minute – depending on materials and application. Equipped with (3) white neoprene conveyor belts, 34-1/2" long x 6-3/4" wide, in feed 17" long x 7-3/4" wide weigh belt with accuracies to 0.5gram and 33" long x 7-3/4" wide discharge conveyor. Control panel has touchpad controller with readout. Mounted on (4) leg base frame. Metal detector with 9" wide x 4-1/4" high useable aperture, product guide rails, dual pneumatic reject arms and product reject bin. ferrous, non-ferrus and stainless steel sensesity detection depending on materials application and enviroment being run in. Control panel has touchpad controls with read out and e-stop. Both have adjustable in feed / discharge heights. Mounted on (4) leg stainless steel frames.

OAD: 86"L x 40"W x 66"H

Get a Free Quote Call: 630-629-9900

Filtec Checkweigher Level Sensing FILTEC JR FT-50

  • Manufacturer: Filtec
  • Model Number: FILTEC JR FT-50
  • Frain Number: 5E8197

Filtec Model JR FT-50 system was used for profiling of candy bars, at 325 ppm in conjuction with a horizontal wrapper and automatic cartoner. Has a Filtec off registration, or open product detector system with a 5" W x 8" H apature, and uses a small gama isotope to insures proper detection wrapper is running bars on registration, and not with open ends, microprocessor electrontics with operator interface touch pad controller, LED readout, S/S enclosure, mounting bracket, statis and alarm lights with bad product air reject system.

OAD: 19" L x 4" W x 28" H

Get a Free Quote Call: 630-629-9900

Hi-Speed Checkweigher Belt XE

  • Manufacturer: Hi-Speed
  • Model Number: XE
  • Frain Number: 5F6110

Mettler Toledo XE, five zone. Product weight range: up to 5.5 kg. Accuracy: +/- 200 mg. Equipped with a 13" long x 8" wide Neoprene infeed conveyor, 13" long x 9.5" wide load cell with 13" long x 8" wide neoprene conveyor, ram reject, 48" long x 16" wide Flexlink discharge conveyor with adjustable guide rails, 33.5" discharge height and a touch screen controller with visual display. Mounted on casters.

OAD: 78" L x 36" W

Get a Free Quote Call: 630-629-9900
