Liquid can fillers are similar to liquid gravity fillers in that gravity can fillers utilize the pressure of gravity on a liquid product to fill the product into the can. Gravity can fillers plunge a nozzle into the can that has a gasket that forms a seal with the top of the can. The nozzle on the liquid can filler then opens to allow product to flow from the product hold tank.
Once the liquid reaches a level above the filling ports in the nozzle, the head pressure above the liquid in the can is equal to the pressure above the liquid in the product hold tank. Once this occurs, the liquid stops flowing into the can. As the nozzle is raised out of the can, the nozzle closes to prevent more product from entering the can.
MRM Model RPF8, Automatic 8 head rotary piston filler capable of speeds from 20 to 120 container per minute – depending on product and fill volume. Maximum container size: 5" diameter x 12" height. Currently set up with 16 oz pistons. Equipped with 14 gallon, heated hopper and has level detector, mechanical container height and piston adjustment, no container / no fill, 4-1/2" x 6′ conveyor track, stainless steel contact parts and Lexan guarding.Air requirements: 60 psi at 1 CFM.Maximum fill volume per application (with proper pistons)Left to right product flow.
OAD: 120" L x 48" W x 80" H
Elmar, Model RPE-514I LH, Automatic, 14 head rotary piston filler rated from 50 to 300 containers per minute – depending on materials and application Stainless steel contact parts. Equipped with 4½" wide x 64" long infeed conveyor, worm screw to star wheel indexing, 14 filling heads set on 6¼" centers, 2¾" diameter x 6" long pistons, and ½" OD filling nozzles maximum fills of 20 fluid onces. Container size range 2" to 4¼" OD and 19" diameter x 25" deep filler bowl with maximum capacity of 25 gallons. Can handle plastic, glass, composite and tin containers with proper change parts. Mounted on (4) leg frame.
OAD: 80"L x 60"W x 83"H
Elmar, Model RPE-514G Automatic, 14 head rotary piston filler with number of containers per minute and hour – depending on materials and application. Equipped with 6" wide in feed conveyor, worm screw to star wheel indexing, 14 filling heads set on 10¼" centers, (14) 6½" OD x 10" long pistons, fills from 32 onces to 170 onces. Mounted on (4) leg base frame with safety cage guarding.
OAD: 96"L x 80"W x 98"H
Fully automatic 10 head rotary piston filler capable of speeds from 50 to 250 cpm (depending on can size & fill). Has container size range: 202 – 404 dia x 101 – 700 Height, with proper change parts. Equipped w/10 gal (38 liter) 15 1/8" dia hopper, 41" L x 3 1/4" W conveyor, worm screw/starwheel infeed & spaces container 6.25" apart. Has 3" piston with min/max stroke of 1/2" – 5 1/4" for 21 oz max capacity .
Rotary motion , 18 head piston filler with all s/s contact parts. 3" dia pistons for filling up to 20 oz at speeds 100 to 540 cpm depending on material and application. Counter-clock wise rotation w/worm to star infeed. Will accept 202 – 303 dia, containers with proper change parts. 4.189" valve centers. S/S bowl holds 16 – 21.3 gallons product. Valves are controlled by magnetic monitor to eliminate jamming & no can/no fill. Line shaft driven. Last filling 211 diam. containers.O.A.D 87 in. H x 60 in. W x 54 in. L
Rotary motion , 22 head piston filler with all s/s contact parts. 3" dia pistons for filling to 20 oz fills at speeds up to 660 cpm. Worm to star infeed. Will accept 202 – 303 dia, containers with proper change parts. 4.189" valve centers. S/S bowl holds 16 – 21.3 gallons product. Valves are controlled by magnetic monitor to eliminate jamming & no can/no fill. Line shaft driven. Last filling 202 diam non-round containers.O.A.D 72 in. H x 76 in. W x 76 in. L
.
Fully automatic 10 head rotary piston filler capable of speeds up to 150 cpm. Has a can diameter range: 202 – 404. Filler bowl has a 9 gallon product capacity, pistons measure 3-3/4" inside diameter x 16-1/2" length (42.5oz max. capacity) , no container no fill, starwheel infeed to starwheel discharge. Currently set up with 4 5/8" O.D. / 3 3/4" I.D. pistons. All stainless steel contact parts. Last ran in a juice operation.
OAD: 48"l x 42"w x 72"h.
Pfaudler 14 head rotary piston filler with four station Continental can seamer type 336-cr-ir. 14 head filler has 2-3/4"dia cylinders with 5/8"dia tapered nozzles. Filler has worm screw infeed and no container, no fill. Continental Can seamer is a model 336-cr-1r. Can seamer size range: (Diameter) 202 to 404, (Height) 104 to 600. Filler and can seamer has a 6’l lugged conveyor on 7" centers transporting cans from the filler to the seamer. Mounted on common frame w/casters. Last ran a 211 diameter 16oz can at speeds of 150 cpm. OAD: 11’l x 6’w x 7’6"h.
Fully automatic 10 head rotary piston filler capable of speeds up to 300 cpm. Has a can diameter range: 202 – 404. Filler bowl has a 9 gallon product capacity, pistons measure 3-3/4" inside diameter x 19-1/2 " length (52oz capacity), no container no fill, starwheel infeed to starwheel discharge. Currently set up with 4 5/8" O.D. / 3 3/4" I.D. pistons. All stainless steel contact parts. Last ran in a juice operation.
Rotary, 14 head, piston filler rated to 400 cpm with a fill range to 52 oz. and a container size range from 202 – 404 diameter by 700 high. No container /no fill, 25 gl capacity hopper, pistons measure 4" inside diameter x 19" length and has screw to starwheel infeed. 316 Stainless steel contact parts. Filling speeds depend on product, temperature and container size. Right to left machine. Last used on 48 oz soup into a 404 x 700 can. OAD= 56"L x 52"W x 86"H
Automatic, 12 head rotary, piston filler capable of speeds from 80 – 300 cpm depending on size container and fill. Can handle containers from 202 – 404 Dia x 101 – 700 H and fill range from 3.85 – 50.11 fluid oz. Has (12) 4 1/8" pistons, set on 8" centers, with min / max piston stroke of 1/2" – 6 3/4" 1 3/4" OD and 1/2" ID filling nozzles, and a 24 gallon working capacity product bowl. 38" L x 4 1/2" W plastic delron product infeed conveyor with worm screw to star wheel container handling, no container / no-fill, and control panel with start / stop buttons and e-stop.
OAD: 78" L x 56" W x 72" H
Votator Pfuadler 18 head rotary, piston filler capable of speeds from 18 to 180 containers per minute – depending on materials and application. Can handle containers from 404 to 610 in Diameter including #10 cans and "F" style plastic containers. Fill range from 40 to 160 fluid oz. Equipped with (18) 7" ID x 9" long pistons, set on 11" centers, with 2" OD and 1-1/2" ID filling nozzles, and 208 gallon working capacity product bowl. 96" long x 4-1/2" wide stainless steel delron product in feed conveyor with 30" long worm screw to star wheel container handling, no container / no-fill, 108" long x 4-1/2" wide stainlesssteel delron conveyor from machine to 122" long x 4-1/2" wide plastic delron discharge conveyor. Control panel with start / stop buttons and e-stop.
OAD: 104" L x 230" W x 87" H
