Revolving Pan Machines

Used Revolving Pan Equipment

Revolving pans (coatings pans, coating drums) are used to coat product with different substances. The product is loaded into the revolving pan and the coating is either placed in the pan with the product or sprayed on using a spray bar which is positioned inside the revolving pan. (Picture your sugar coating on your morning cereal.) As the revolving pan rotates (revolves), it agitates the product and the coating substance in the revolving pan. The gentle agitation of the revolving pan equipment and its contents results in more coating being applied to the product. Some systems allow the coating substance to fall through perforations in the coating pan if the coating does not immediately adhere to the product. This method is one way to control the amount of coating that is applied to the product.

Contact Us

Related Categories

Revolving Pan Equipment In Stock

Pans, Revolving

  • Model Number:
  • Frain Number: 5E8025

Continuous, S/S, cylindrical drum for coating has a 36" ID x 102" L coating chamber, (4) 1"H baffles, 24" OD product infeed / discharge with 40" floor clearance, and a 1.5hp drive. Mounted on a common base frame.

OAD: 144" L x 40" W x 70" H

Get a Free Quote Call: 630-629-9900

Modern Flow Inc Pans, Revolving

Continuous, S/S, cylindrical drum fior coating has a 36" ID x 120" L coating chamber, (4) 1"H baffles, 24" ID product infeed / discharge with 36" floor clearance, and a 1.5hp drive. Mounted on a S/S frame.

OAD: 154" L x 40" W x 68" H

Get a Free Quote Call: 630-629-9900

Pans, Revolving

  • Model Number:
  • Frain Number: 5F7820

Stainless steel, continuous motion, cylindrical polishing drum. Drum dimensions: 42" in Diameter; 54" in Length. Equipped with a 24" x 24" hinged gate load area, three 1" high baffles, stainless steel discharge chute with 8" x 8" outlet, A/B variable speed controls, and interlocking Lexan safety guarding. Mounted on casters.

OAD: 72" L x 72" W x 78" H

Get a Free Quote Call: 630-629-9900

Thomas Pans, Revolving System 48" ACCELA-COTA Thomas Engineering 48" S/S Accellacota Tablet Coater And Drying Pan

  • Manufacturer: Thomas
  • Model Number: 48" ACCELA-COTA
  • Frain Number: 5D2667

Thomas Engineering 48" S/S Accellacota Tablet Coater And Drying Pan. Has Variable Speed 1-1/2 Hp Explosion Proof Drive Motor. Unit Comes With A 48" Perforated Coating/Drying Pan With Agitation Baffles Capable Of 400 Lbs. Per Batch Of Tablets. Has 12" Air Handling Ports. Air was steam heated. Last used in OTC pharmaceutical manufacturing.

OAD: 68" x 52" x 84"

Get a Free Quote Call: 630-629-9900

Allen / PPM Tech LLC Pans, Revolving

72" Long x 1-1/2" Diameter stainless steel auger system applicator, with rigid 1-7/8" Diameter stainless steel product tube with motor drive and mounted on bolt down base frame and was used in continous powder coating pan system.

OAD: 48" L x 42" W x 90" H

Get a Free Quote Call: 630-629-9900

CMS / Spray Dynamics Pans, Revolving WH4860CP

CMS model WH4860CP continuous, stainless steel, coating drum. Equipped with 72" long by 48" ID coating cylinder, (12) 5" tall ribs, two 60" x 60" external access doors on each side, 10" x 10" product inlet, 9" x 6" end bottom discharge, 2" sanitary inlet at 57" ground clearance, 2-1/2" side bottom drain and a 1-1/2 HP Baldor drive. Unit features a mechanical tilting mechanism allowing for up to 12" of downward tilt to facilitate product discharge. Mounted on S/S frame.

OAD: 160"L x 75"W x 115"H

Get a Free Quote Call: 630-629-9900

Pans, Revolving

  • Model Number:
  • Frain Number: 5E5302

Continuous, cylindrical drum coating system, has a 32" Dia x 102" L coating chamber, with product in-feed, and a 24" L x 9" W x 29" H product discharge chute with 54" discharge height, and is mounted on mild steel painted base frame.

OAD: 192" L x 60" W x 118" H

Get a Free Quote Call: 630-629-9900

Latini Pans, Revolving BCP24P

  • Manufacturer: Latini
  • Model Number: BCP24P
  • Frain Number: 5E4659

Fully automatic, horizontal coating / polishing belt system. Equipped with a 24" wide coating belt and 22" x 3/4" spray bar. Features include air ducting, exhaust system, waste collection drawer, Allen Bradley controls for: Chocolate (on/off), drive direction (reverse/forward), heater (on/off), light (on/off), scraper (on/off), and a temperature readout.

OAD: 63"L x 58"W x 82"H

Get a Free Quote Call: 630-629-9900
