In need of sifter equipment for your next project? Let the Frain Group help you choose the right sifter equipment! Sifter equipment includes a variety of separation equipment for the removal of specific sizes of particles or material for classification to size.Sifter equipment can be used for a number of separation processes. A sifter can perform the separation of products by difference in physical size of the material (in dry mixtures), as well as the separation of solids in liquid suspensions. Sifter equipment can be either vertical, horizontal or a combination of both with the induction of air or other liquids to facilitate increased separation efficiency and productivity.
Gump, Model CP-43, 48" diameter, stainless steel, inline sifter / screener. Operating pressure: 13 psig. Equipped with (3) 10" top inlets, bolt down cover, pressure release valve and 24" long x 24" wide x 21" deep product feed funnel. (3) self cleaning screens and (2) 5" diameter side bottom discharges and 7½ Hp motor drive. Mounted on heavy duty base frame.
OAD: 65" L x 59" W x 83" H
Gump, Model CP-43, 48" diameter, stainless steel, inline sifter/ screener. Operating pressure: 13 psig. Equipped with a 6" top center inlet, bolt down cover, pressure release valve, (3) self cleaning screens and (2) 6" diameter side bottom discharges.
OAD: 70"L x 60"W x 55"H
KeK Gardner Model K300C, cantilever shaft design, centrifugal sifter rated from 3 to 5 tons of product per hour – depending on materials, application and screen size. Stainless steel contact parts. Equipped with 20" long x 9" ID chamber with screen (change part per application) 9" ID front swing open access door with interlock safety switch and 26" long x 3" OD removable screw. Top 12" long x 9" wide bolt down access door with interlock safety switch and 7" OD / 3-3/4" ID top flanged product port has (4) 1/2" bolt holes on 4" centers. 3-1/2" ID bottom oversize product discharge port with 25" floor clearence and 9" OD / 3-1/2" ID flanged fine dust powder discharge with (6) 1/2" bolts sent on 4" centers and 20" floor clearence. Motor drive and e-stop. Mounted on "H" style base frame with Locking casters. Ideal for de-agglomerating, scalping, classifying and conditioning of product down to a uniform size.
OAD: 44" L x 30" W x 45" H
Great Western, Model TB-611M/2, 36" diameter, in-line gyroscopic pressure sifter. Rated to 700 lbs / min – depending on materials, application and machine configuration. Equipped with (2) 24" Diameter stainless steel decks and (1) screen (change part per application). Each deck has a 4" diameter discharge port. Top cover has 4" diameter center product port. Mounted on heavy duty base frame with safety guarding.
OAD: 78"L x 55"W x 98"H
Azo Model DMZC-AL-150, continuous, portable, stainless steel, centrifugal sifter with pounds of product per hour – depending on materials and application. Equipped with 18" in Length x 8" OD sifting chamber with 11" OD, 6¾" ID top product hopper flange with (8) 1-7/8" bolt holes on 4½" centers, top and front hinged bolt down acces doors with interlock safety switches, bottom 6½" OD , 6" ID bolted flange for dust collection, 19" in Length x 4" OD removeable hygenic sifting screen and scrape paddle. End bottom 6" ID discharge chute with 27" ground clearance. Control panel has on / off switch with high frequecy controller with 1 Hp motor drive. Mounted on a 4 leg stand with casters.
OAD: 55" L x 48" W x 69" H
Great Western, Model TB-61/2, 36" diameter, in-line gyroscopic pressure sifter. Rated to 700 lbs / min – depending on materials, application and machine configuration. Equipped with (2) 24" Diameter stainless steel decks and (1) screen (change part per application). Each deck has a 4" diameter discharge port. Top cover has 4" diameter center product port. Mounted on heavy duty base frame with safety guarding.
Custom Advanced Model DM18-S-33WC 18" diameter vibratory screener has (2) Screen Decks with Top and bottom eccentric weights, for lead-angle and vertical amplitude adjustments(2) 18" Stainless mesh screens, 3" tall lower Table frame, 304 stainless steel with a 3" diameter discharge spout 3" tall middle Distributing frame, 304 stainless steel with a 3" diameter discharge spout 3" tall upper Spacing frame, 304 stainless steel with a 3" discharge spout 18" Dust Cover Kit with 304 stainless weldment, 3" INLET, (1) inspection opening, sealing gasket and clamp band
Custom Advanced Model DM18-S-33WC 18" diameter vibratory screener has (2) Screen Decks with Top and bottom eccentric weights, for lead-angle and vertical amplitude adjustments (2) 18" Stainless mesh screens, 3" tall lower Table frame, 304 stainless steel with a 3" diameter discharge spout 3" tall middle Distributing frame, 304 stainless steel with a 3" diameter discharge spout 3" tall upper Spacing frame, 304 stainless steel with a 3" discharge spout 18" Dust Cover Kit with 304 stainless weldment, 3" INLET, (1) inspection opening, sealing gasket and clamp band
Gump, Model CP-43, 48" diameter, stainless steel, inline sifter/ screener. Operating pressure: 13 psig. Equipped with a 6" top center inlet, bolt down cover, pressure release valve, (3) self cleaning screens and (2) 6" diameter side bottom discharges. Mounted on a 56" tall pedestal style base.
OAD: 70"L x 60"W x 111"H
Kason, Model MOB-SS, continuous, stainless steel, centrifugal sifter with pounds of product per hour – depending on materials and application. Equipped with 18" in Length x 7" ID sifting chamber with 11" OD / 6" ID flanged top product charge, top and front hinged bolt down access doors, 25" in Length x 10" OD removable screen, paddle and screw, bottom 3½" ID discharge for undersize product with 25" floor clearence and bottom 3½" ID discharge oversize product with 20" floor clearance. Powered by single 5 hp motor drive and has start, stop switch and e-stop button. Mounted on "H" style base frame. Ideal for scalping, de-agglomerating, classifying and conditioning of product down to a uniform size.
OAD: 63"L x 30"W x 98"H
