Osgood, Model 6400, (6) lane, inline, stainless steel, single index, FOB, (fruit on bottom) tamper evident cup filler, heat sealer and over lid applicator rated from 24 to 240 cups per minute – depending on materials, application and machine configuration. All stainless steel construction. Equipped with (6) lane pick and place cup denster, (2) 24" x 24" stainless steel product hoppers, with dual (6) servo driven pistons one for the FOB (fruit on bottom) and the other for the product (yogart) with 3/4" OD positive cut off nozzels up to (3) flavor capacity. 24" long x 4" wide cup carriers with (6) 3" ID cup pockets set on 5" centers, roll stock film and heat sealing stations with knife cut off assemblies and 45" long (6) lane powered roller, lid magazine and snap on over lid application section. Control panel has touch screen HMI controls with start, stop, e-stop push button and statis light. Mounted on heavy duty stainless steel frame with safety door guarding. Change parts required to accommodate different size range.
OAD: 326" L x 70" W x 88" H
Osgood, Model 3600-E, 3 lane, in line, stainless steel, cup filler, heat sealer and over lid applicator rated from 30 to 120 cups per minute – depending on materials, application and machine configuration. Currently set for (3) up pattern with 4-1/4" OD cup pockets set on 5½” centers. Equipped with (3) lane cup denster, stainless steel product hopper, (3) servo driven piston filler with 4" ID x 6½" long pistons with positive cut off nozzels, roll stock film and heat sealing stations with knife assemblies, 48" long (3) lane powered roller lid magazine and snap on over lid section. Control panel has A/B CPU controller with touch screen HMI controls with start, stop, e-stop push button and statis light. Mounted on heavy duty stainless steel frame. Change parts required to accommodate size range.
OAD: 175"L x 45"W x 75"H
Osgood Syntegon, Model BEF-2X6800-S, Automatic, inline, 6 lane, 12 head, stainless steel, pre-made RTE (ready to eat) food tray filler, roll stock film applicator, heat sealer and cut-off station with number of trays per minute – depending on materials, application and machines configuration. Designed for a wide range of both dairy and food products from liquid, to viscous to pumpable into pre-made containers (with proper change parts). Equipped with 428" long tray conveyor and has 7" long x 47-1/4" wide carrier plates with (6) across 4-1/2" x 6" oval tray pockets set on 7" centers, (12) 48" long empty tray magazines, with denesters, (2) 50" long x 20" wide x 16" deep stainless steel agitated product hoppers and (2) sets of (6) filling heads set on 7" centers, no container / no fill, roll stock film applicator and heat sealer with (12) serrated blade cut-off station and automatic film rewind. Remote control panel has A/B controller with start, stop, reset and e-stops push buttons. Mounted on a heavy duty stainless steel frame with cage style safety door guarding and meets 3A sanitary standards.
OAD: 428" L x 80" W x 112" H
Osgood Model 4700E, automatic, inline, stainless steel, cup filler with number of cups per minute – depending on materials and application. Equipped with 29-1/4" long x 4-1/4" wide cup carriers, 20" OD x 30" long stainless steel product hopper, 6 filling heads positive cut off fill nozzels set on 5" centers. Remote touch pad controller with panelview and e-stops. Mounted on heavy duty stainless steel frame with safety door guarding. Capable of filling liquid, viscous and pumpable products into pre-made containers and meets 3A sanitary standards.
OAD: 201" L x 72" W x 76" H
Osgood Model 3600-E-L, 3 lane, inline, stainless steel, cup filler, heat sealer, lidder rated from 30 to 120 cups per minute – depending on materials, application and machine configuration. Currently set in (3) up pattern on 6” centers. Equipped with (3) lane cup denster, (filler as per application ), roll stock film with heat sealing stations and knife assemblies, 48" long (3) lane powered roller lid magazine with recipicating pic n place and snap on lid section. Control panel has A/B PLC and A/B touch pad controller with panel view and interlock safety doors. Mounted on heavy duty stainless steel base frame. Change parts required to accommodate size range.
OAD: 168" L x 64" W x 82" H
