Berlie Falco Tank Reactor SS 6400 Berlie Falco Tank Reactor SS 6400 Osgood Filler Cup Inline 6400

  Back to All Equipment

Falco Stainless Steel Equipment Co, 200 gallon, stainless steel jacketed process reactor tank. 316L exterior with # 7 finish and 316L electro polished finish. Vessel dimensions: 55" OD x 66" deep with 36" straight wall and 26" slant bottom. Equipped with dome top and has 16" OD manway with flip up, bolt down cover, top mounted 5 Hp motor drive for scrape surface and prop agitators with full side and bottom 3 zone jacket. Slant bottom with 3" OD flush bottom center bottom discharge valve with 16" ground clearance. Mounted on stainless steel (3) leg frame.

Top Ports:
(2) 1-1/2"
(2) 2"

Jacket Ports:
(6) 1-1/2"

Vessel:
MAWP: 100 psi @ 300°F
MDMT: -32 °F @ 100 psi

Jacket:
MAWP: 150 psi @ 300°F
MDMT: 32°F @ 150 psi

OAD: 55" L x 53" W x 87" H
