Stokes / Compression Component Machines


Stokes / Compression Component Machines In Stock

Stokes / Compression Component Press Tablet Rotary DS3

Stokes, Model DS-3, 15 station rotary press. Rated from 180 to 335 tablets per minute – depending on materials, application, machine configeration and enivorment being run in. Compression: up to 5 tons. Maximum tablet diameter of 1(3/16)"; Maximum fill depth of 1(1/16)". Equipped with a 15" long x 11" wide x 20" deep hopper, 2" diameter dies, 2 Hp drive and a 2" wide discharge chute with 41" ground clearance. Customer to supply tooling.

OAD: 48"L x 30"W x 74"H

Get a Free Quote Call: 630-629-9900

Stokes / Compression Component Press Tablet Rotary B2

Fully Automatic, variable speed 16 Station Rotary Tablet Press Capable Of Speeds From 350 – 650 Tablets Per Minute. Operating Pressure: (Standard Spring) Of 1 1/2 To 4 Tons. Depth Of Fill (0 – 11/16"), Maximum Tablet Diameter (5/8") Maximum Tablet Thickness (11/32"). Equipped With Dust Suction Nozzle, And Overfill Device With Simultaneous Top/Bottm Compression.

Get a Free Quote Call: 630-629-9900

Stokes / Compression Component Press Tablet Rotary B2-512

Stokes Model B2, automatic,16 station rotary tablet press rated up to 1200 tablets per minute – depending on materials, application and machine configuration. "B" tooling, with operating pressure: 1-1/2 to 4 tons. Depth of fill: 0 to 11/16". Tablet diameter: to 5/8". Tablet thickness: to 11/32". Equipped with keyed upper turret. Mponted on platform style base. Customer to supply tooling.

OAD: 37" W x 27" L x 64" H

Get a Free Quote Call: 630-629-9900

Stokes / Compression Component Press Tablet Rotary 9005652

Hi-Speed Double Sided 65 Station Rotary Tablet Press Capable Of 3500 – 10,000 Tablets/Min. Maximum Pressure Is (Above & Below) 10 Tons. Fill Depth Range: 1/8"- 11/16". Max Tablet Diameter Of 7/16" And Die Dia Of 0.945". Equipped W/Dual Feed Hoppers, Central Lubrication Sys, Multi Nozzle Dust Collection, Barrier Guarding And Keyed Uppers. Can Be Converted For 2 Layer Tablet Prod W/Minor Modifications

Get a Free Quote Call: 630-629-9900

Stokes / Compression Component Press Tablet Rotary 512

Stokes, Model 512, 16 station rotary press. Rated from 350 to 650 tablets per minute – depending on materials, application, machine configeration and enivorment being run in. Compression: up to 4 tons. Maximum tablet diameter of (5/8)"; Maximum fill depth of (11/16)". Equipped with ¾" OD keyed upper punches, 1¼" OD dies and 1½ Hp motor to sproket drive. Mounted on 42" x 40" pedestal base frame. Customer to supply tooling.

OAD: 42"L x 40"W x 71"H

Get a Free Quote Call: 630-629-9900

Stokes / Compression Component Press Tablet Rotary

Automatic, 10 station rotary tablet press rated to 190 tablets per minute – depending on materials and application. Maximum operating pressure of 3 tons, and maximum tablet dia round of: 15/16" with maximum fill depth of: 13/16" with maximum fill depth of: 13/16" stainless steel product feed hopper and vari-speed belt drive, with push button start / stop controls. Customer to supply tooling.

Get a Free Quote Call: 630-629-9900

Stokes / Compression Component Press Tablet Rotary 9005181

16 station rotary tablet press rated up to 650 tablets per minute – depending on materials and application. Maximum operating pressure of 4 tons. Maximum tablet diameter round: 11/16", maximum tablet or capsule shaped length of 3/4". Equipped with stainless steel product hopper, brass feed frames, simultaneous top and bottom compression, automatic pressure release and mounted on 36 x 36 base frame. Customer to supply tooling.

OAD: 48" L x 36" W x 72" H

Get a Free Quote Call: 630-629-9900

Stokes / Compression Component Press Tablet Rotary 16 HD

16 station, rotary tablet press rated up to 1200 tablets per minute – depending on materials and application. Maximum operating pressure: 4 tons. Maximum tablet diameter round: 11/16". Maximum tablet diameter 5/8" and maximum capsule shaped length 3/4". Equipped with stainless steel simultaneous top and bottom compression, and automatic pressure release. Mounted on 36 x 36 base frame. Customer to supply tooling.

OAD: 54" L x 40" W x 64" H

Get a Free Quote Call: 630-629-9900

Stokes / Compression Component Press Tablet Rotary BB2-D53

33 station rotary tablet press rated up to 1700 tablets per minute – depending on materials and application. Maximum operating pressure of 4 tons. Maximum tablet diameter of 7/16", Maximum fill depth of 11/16". Die diameter: 0.945". Equipped with dual stainless steel product hoppers, keyed uppers, brass feed frames, simultaneous top and bottom compression, automatic pressure release, split discharge chute and mounted on a 33 x 33 base. Customer to supply tooling.

OAD: 51" L x 38" W x 80" H

Get a Free Quote Call: 630-629-9900

Stokes / Compression Component Press Tablet Rotary DD2-516-1

Stokes Model DD2, 31 station rotary tablet press rated from 100 to 975 tablets per minute – depending on material and applicaation. Maximum tablet diameter of 15/16”, maximum fill depth of 1 1/16” and 15 tons working pressure. Equipped with dual feed hoppers, non-keyed machine. Mounted on heavy duty base frame. Customer to supply tooling.

OAD: 84” L x 60” W x 90”H

Get a Free Quote Call: 630-629-9900

Stokes / Compression Component Press Tablet Rotary PACER-1

Stokes Model Pacer, automatic, 45 station, rotary tablet press rated up to 4200 tablets per minute – depending on materials and application. Maximum operating pressure of 4 tons. Maximum tablet diameter 7/16". Maximum fill depth adjustable 0" to 11/16", and upper punch entrance adjustable 1/8" to 3/8". Constructed of no pigmental finishes in product compacting zone, and equipped with transit level tunnel feeder, adjustable vertical hoppers, hand wheel controls, floating guide bans, tablet weight and lower cam adjusment, covered upper dwell camming, and CHORD-LOC die arrangement. Punch Length upper: 5-1/4" lower 5-1/4". Punch Diameter: upper 3/4" lower 3/4" Die Diam: .945" and Die Depth: 7/8". Mounted on heavy duty base frame. Customer to supply tooling.

OAD: 50" L x 50" W x 65" H
WT 2500#

Get a Free Quote Call: 630-629-9900

Stokes / Compression Component Press Tablet Single Action 521

Automatic, single station tablet press. Tablet Diameter: up to 1-1/4". Fill Depth: up to 1-1/4". Operating pressure: up to 4 tons. Equipped with a 240 inch³ stainless steel product hopper, two TQM-700 punch force monitors and brass powder feeder. Mounted on height adjustable legs with casters. Rated from 10 to 58 tablets per minute – depending on materials, application and machine configuration. Tooling required per application.

OAD: 54" L x 32" W x 65" H

Get a Free Quote Call: 630-629-9900
