Tisma Model TC50E, semi automatic vertical cartoner rated from 60 to 150 cartons per minute – speeds depending on materials and application. Machine is on 7-1/2" centers with carton size range of: (length) 1" – 6"; (width) 1/2" – 3"; (Depth) 2 1/2" to 8". Equipped with powder carton magazine, 2 head rotary feeder, graduated scale adjustments, 4′ 6" load area on each side of carousel, E- Stops, E-trac AC inverter, Piab vacuum system and interlocked guarding.
OAD: 150" (L) x 50" (H) x 52" (H)
Tisma, Model TC-50 DE, semi automatic, vertical hand load cartoner with hot melt glue sealer. Rated from up to 140 cartons per minute – depending on materials, application and operator dexterity. Single chain unit set on 5" centers. Carton specifications: 1" – 3½" (length) x ½" – 3" (width) x 2½" – 8" (depth) Equipped with a 48" long (2) chain powered blank carton magazine, (4) head rotary suction cup pick n place, fixed product pockets, 66" long hand load area on each side and Nordson hot melt glue system with pattern control. Control panel has an AB CPU, with PanelView 550 controller and digital read out with start / jog / reset / e-stop push button controls. Mounted on welded tubular base frame with interlock safety guarding.
Coder Available at Addition Cost
OAD: 187"L x 74"W x 96"H
Tisma, Model TC-50E, Semi-automatic, vertical, hand load cartoner rated from 25 to 150 cartons per minute – depending on materials, application and operator dexterity. Carton size range: per application. Equipped with (2) chain fixed, set on 5" centers, with 33" long (2) chain automatic blank carton magazine (2) head rotary pic-n-place, 48" long hand load area with operator e-stop each side. Control panel has start, jog and e-stop push buttons with statis light bar. Mounted on heavy duty frame with interlock safety guarding.
OAD: 168" L x 60" W x 85" H
Tisma Model TCH 600L, Automatic, continuous motion, horizontal, hot melt glue cartoner rated from 50 to 250 cartons per minute – depending on materials and application. Carton size range: 1-1/2" to 5" in Length x 1/2" to 3-3/4" in Width x 3" to 9" in Depth. Equipped with (4) chains adjustable set on 6" centers, with 1-1/2" wide x 1-1/2" high lugs, 32" long x 4" wide product feed conveyor to 120" long total and 95" long usable product hand load bucket in feed conveyor with 4-3/4" long x 1" wide x 11-1/2" deep fixed product buckets. 60" long (2) chain automatic blank carton magazine, (4) head rotary pic n place, top hold down squaring bar, no product / no carton and low blank sensors, automatic barrel cam product loader, Nordson hot melt glue system, with carton flap closers and dual 24" long x 1" high side belt compression / discharge conveyor. Control panel, has CPU controller and A/B panelview with readout, cycle start / stop, pusher cylinder on / off, jog / run, product hold down / up / down switches and e-stop controls. Mounted on multi-leg heavy duty frame with interlock safety doors and statis light.
OAD: 383" L x 89" W x 70" H Machine Only 181" W With End Conveyors
Tisma, Model TC600, Automatic, horizontal, continous motion, hot melt glue cartoner. Rated from 30 to 240 cartons per minute – depending on materials, application and machine configuration. Carton size range per application. Equipped with 156" long in feed conveyor with 6" long x 1-1/2" wide x 12-1/2" deep fixed product buckets, 40" long automatic (2) chain auto carton magazine, (4) head rotary vacuum pick n place, 3 chains set on 10" centers with 2-1/2" high x 1" wide lugs, barrel cam loader with no carton / no product, no product / no carton and rotary top hold down, Nordson hot melt glue system, with major and minor flap closers and 24" compression section, interlock safety guarding and statis light bar. Control panel has A/B CPU controller and PLS touchpad controls with pusher run / jog, product on / off, carton pick-up auto / manual controls and start, stop, e-stop push buttons with A/B Dataliner unit. Mounted on heavy duty frame.
OAD: 216" L x 84" W x 63" H Without In Feed 372" L With In Feed
Tisma Model compact, semi automatic, vertical, hot melt glue cartoner with number of cartons per minute – depending on materials, application and operator dexterity. Equipped with (1) chain fixed set on 10" centers with 3-1/8" long x 3-1/8" wide x 3/4" deep fixed buckets. Equipped with 36" long blank carton magazine, recipacating suction cup pick n place, 48" long load area, hot melt glue system, major and minor flap closers and compression discharge section. Control panel has air system and main power on / off forward / reverse, run / stop, switches and speed control dial with start, stop and e-stop push buttons controls. Mounted on base frame with casters and leveling legs.
OAD: 95" L x 80" W x 68" H
Tisma Model TC50DE, semi automatic, vertical hand load cartoner, rated from 60 to 150 cartons per minute – depending on materials, application and operator dexterity. Carton size range; 1" to 6" in Length, x 5/16" to 3" in Width x 2-1/2" to 8" in Depth currently set for straight tuck, but can run reverse tuck or glue cartons with proper change parts. Equipped with 1 chain, set on 5" centers with 2-1/2" long x 2-1/2" wide x 1-1/2" deep fixed product buckets, blank carton magazine, (2) head rotary pic n place, 36" long manual load area on each side and self contained lube and vacuum systems. Control panel has A/B CPU controller and Electro Cam 5000 PLUS controls, with paneview and start, stop, reset, e-stop push buttons. Mounted on heavy duty base frame with interlock safety guarding, casters and leveling legs.
OAD: 132" L x 72" W x 80" H
Tisma Model TC-50E, Semi automatic, vertical hand load, straight tuck cartoner, rated from 25 to 150 cartons per minute – depending on materials, application and operator dexterity. Carton size range: per application. Equipped with (1) chain set on 5" centers, with 48" long (2) chain automatic blank carton magazine, (2) head rotary pic-n-place, 36" long hand load area with operator emegency stop each side, major and minor flap closers. Control panel has A/B controller with A/B panel view controls and start, jog and e-stop push buttons with statis light bar. Mounted on heavy duty frame with interllock safety guarding.
OAD: 168" L x 58" W x 96" H
Tisma Model TC-50E, semi automatic, vertical hand load, straight tuck cartoner, rated from 25 to 150 cartons per minute – depending on materials, application and operator dexterity. Carton size range: per application. Equipped with 1 chain set on 5" centers, with 48" long (2) chain automatic blank carton magazine, (2) head rotary pic-n-place, 36" long hand load area with operator emegency stop each side. Control panel has A/B controller with A/B panel view controls and start, jog and e-stop push buttons with statis light bar. Mounted on heavy duty base frame with interllock safety guarding,
Tisma Model TC50E, semi automatic vertical hand load cartoner set for a glue closure rated from 30 to 150 cpm – speeds depending on materials and application. Cartons are feed with a 2 head rotary style feeder, from a 6′ long powered carton magazine. 7′ long load area on each side of carousel, interlocked guards, cluster lube system.
OAD: 190"L x 54"W x 82"H
Tisma Model TC 8, automatic, vertical, volumetric scale, hot melt glue, cartoner, rated from 100 to 300, cartons per minute – depending on materials and application. Equipped with a 48" long carton magazines, 4 head rotary vacuum pick and places, fixed bucket conveyor set on 2" centers, Syntron vibratory product feeders, 8 head rotary volumetric filler, excess product collection system, Nordson hot melt glue system, top compression carton closing section, air blast carton discharge with 12" chute. Additionally features PLC system, A/B digital readout, Powerflex touchpad controller, Omaron rotary positioner, and interlocking Lexan safety guarding. Mounted on stainless steel frame with height adjustable legs.
OAD: 148" L x 70" W x 76" H
Tisma Model JV, automatic, continuous motion horizontal, cartoner rated from 50 to 200 cartons per minute – depending on materials and application. Equipped with 3 chains adjustable set on 10" centers with 2" wide x 3" high lugs. Carton size range: 2" to 7" in Length; 1/2" to 3-3/4" in Width; 5" to 9" in Depth. 200" long fixed bucket in feed conveyor with 10" long x 6-1/2" wide x 2-3/4" high product buckets, 36" long 2 chain powered blank carton magazine, 2 head rotary carton pic-n-place, rotary barrel cam loader with top product confiner, no product / no carton, no carton / no product sensors. flap closers and 20" long belt compression section. Control panel has A/B controller with DL20 digital display, and start, stop, run, jog, auto, manual top hold down, barrel pusher controls with e-stop. Mounted on base frame with safety guarding casters and leveling legs.
OAD: 425" L x 90" W x 71" H
