Feldmeier Tank SS Single Wall 75 GAL

  Back to All Equipment

Feldmeier, 75 gallon capacity, 316 stainless steel single wall tank. Vessel dimensions: 30" diameter x 28" deep with 24" straight wall. Equipped with dome top, 16" man way with flip up / clamp down cover, CIP spray ball supplied by a 2"OD / 1½"ID Tri-Clamp fitting, (1) level sensor port, (1) temp probe port and (1) flush mount sensor port. Slant bottom has 2½" OD / 2" ID Tri-Clamp style bottom discharge with 11" ground clearance. (Level Sensor, temperature probe and flush mount sensor not included)

Top Access:
(2) 2½"OD /2"ID Tri-Clamp
(1) 4" ID Open Vent

Side Access:
(1) 2"OD / 1½"ID Tri-Clamp

3-A Standard #: 32-02

OAD: 35"L x 32"W x 52"H
