Stainless Steel Tank Machines

Used Stainless Steel Tank Equipment

stainless-steel-tankFrain Industries carries hundreds of used, stainless steel storage and processing tanks.   Tanks vary greatly in their shape, size, and application.  Frain stocks tanks ranging from 5 gallons to 10,000 gallons in many different configurations including: jacketed, single wall, vertical, horizontal, cone bottom, dish bottom, insulated, with or without agitation, CIP (clean in place), and many others.  Additionally tanks can be made of multiple grades of stainless steel (typically 304 or 316/316L) with different levels of corrosion resistance.

Types of agitation available include: prop agitation, high sheer agitation, sweep agitation, dual agitation, emulsification, turbines, impellers, cage beaters, anchor paddles, gate paddles, and many others.

Jacket types include: conventional jackets, high pressure jackets, half-pipe coil jackets, multiple zone jackets, dimple jackets, and plate coils.

The Frain Industries engineering team can place you into a storage or processing tank solution for your application.  If you are looking for a single tank or an integrated solution with automated fill and discharge options Frain has the equipment for your needs.

Frain Industries carries used tanks from many OEM’s including A&B Processing, Abec, Ace, Alfa Laval, Allegheny, American Process Systems, Apache, APV, APV Crepaco, B&G, CE Howard, Chem Tek, Cherry Burrell, Chester Jenson, Cream City, Crepaco, Dairy Craft, Damrow, DCI, Dover, Feldmeier, Groen, Highland, Howard, Langsenkamp, Lee, Letsch, Mueller, New Brunswick, Northland Stainless, Nova, Perma San, Perry, Pfaulder, Precision, Precision Stainless, Seitz Stainless, Walker, Willflow, and many others.

Contact Us

Stainless Steel Tank Equipment In Stock

Tank SS Single Wall 300 GAL

  • Model Number: 300 GAL
  • Frain Number: 5H4270

300 Gallon, (2) compartment, 304 stainless steel. Each compartment is 300 gallons with inner dimensions of 46" x 40" x 42" Deep. Equipped with flip up covers, top mounted spray balls and prop style mixers with ½ Hp motor drives and gauges. Slant bottom has 2½" OD / 2" ID sanitary side bottom discharge port with 15" ground clearance. Mounted on (6) stainless steel legs. Rectangle construction provides maximum capacity in small floor area.

OAD: 90" L x 50" W x 80" H

Get a Free Quote Call: 630-629-9900

Tank SS Single Wall 105 GAL

  • Model Number: 105 GAL
  • Frain Number: 5H3604

105 gallon, stainless steel, COP tank. Equipped with 96" long x 18" wide x 13" deep trough with 2" OD / 1½" ID NPT connection bottom drain. Mounted on (4) leg stainless steel base frame.

OAD: 99"L x 21"W x 36"H

Get a Free Quote Call: 630-629-9900

Tank SS JKT 250 GAL

  • Model Number: 250 GAL
  • Frain Number: 5H4100

Pro Flo Percision, ITT Industries, 250 gallon, 316L stainless steel jacketed storage tank. Vessel dimensions: 46 diameter x 46" deep with a 31" straight wall. Equipped with an 18" diameter flip top latch down cover and side transport handles. Dish bottom has 2½" OD / 2" ID center bottom discharge with 15" ground clearance Mounted on (4) stainless steel legs with casters.

Top Ports:
(2) 2" OD / 1½" ID Tri-Clamp

MAWP: 0 PSI @ 100°F
MDMT: -20°F @ 50 PSI

Nat’l Brd: 10970

OAD: 50" L x 45" W x 75" H

Get a Free Quote Call: 630-629-9900

Perma San Stapco Stainless Tank SS Single Wall 61 GALLON OVC

Perma San, Model OVC, 60 gallon, 304 stainless steel tank and pump system with gallons of product per hour – depending on materials and application. Vessel Dimensions: 24" diameter x 32" deep with 29" straight wall. Equipped with flip up lids, cone bottom has 3½"OD / 3"ID Tri-clamp style bottom discharge with 47" ground clearance. Waukesha, Model 2045, Stainless steel centrifugal pump. Rated from 20 to 190 gallons per minute with a head of 22 to 88 feet – depending on materials and application. Pump head equipped with a 2½"OD / 2"ID Tri-clamp style suction infeed and a 2"OD / 1½" ID Tri-clamp style delivery discharge with 42" ground clearance. 4½" diameter impeller is driven by a 5 hp motor. Mounted on a stainless steel base frame with casters.

OAD: 54"L x 32"W x 84"H

Get a Free Quote Call: 630-629-9900

Feldmeier Tank Processors 5200L

  • Manufacturer: Feldmeier
  • Model Number: 5200L
  • Frain Number: R29336

Feldmeier, 1350 gallon capacity, 316 stainless steel 3-zone jacketed process tank. Vessel dimensions: 76" ID x 72" deep with 60" straight wall. Equipped with a dome top, slant bottom, (1) 20" diameter top entry hinged man way, (2) thermowells, 3 Hp top mounted 27" diameter prop agitator and 2½" OD / 2" ID tri-clamp style bottom center discharge with 12" ground clearance.

Top Ports:
(3) 3½"OD / 3"ID Tri-Clamp
(2) 2½"OD / 2"ID Tri-Clamp
(5) 2"OD / 1½"ID Tri-Clamp

Side Ports:
(1) 3½"OD / 3"ID Tri-Clamp

Jacket Ports:
(8) ¾" NPT

Vessel:
MAWP: 25 PSI @ 176°F
MDMT: -22 °F @ 25 PSI

Jacket:
MAWP: 50 PSI/FV @ 176°F
MDMT: -22°F @ 50 PSI/FV

Nat’l Brd: 2688

OAD: 88"L x 82"W x 120"H

Get a Free Quote Call: 630-629-9900

Walker Tank Processors MT-102

  • Manufacturer: Walker
  • Model Number: MT-102
  • Frain Number: R29402

Walker, 150 gallon capacity, 316L stainless steel jacketed / insulated process tank, with gallons of product per hour – depending on materials and application. Vessel dimensions: 46" diameter x 32" deep with 24" straight wall. Equipped with 18" diameter bolt down man way, 2 Hp top mounted scrape agitator, Thermowell, 6" wide fixed baffle and 3" OD / 2.5" ID Tri-clamp style bottom discharge with 24" ground clearance. Mounted on (4) stainless steel legs.

Top Ports:
(1) 2½"OD / 2"ID Tri-clamp
(1) 3"OD / 2½ID Tri-clamp
(1) 3½"OD / 3"ID Tri-clamp
Jacket Ports:
(4) 2"OD / 1½"ID Tri-clamp

MAWP: 150 PSI @ 338°F
MDMT: -20°F @ 150 PSI
Nat’l Brd: 6579

OAD: 51"L x 49"W x 87"H

Get a Free Quote Call: 630-629-9900

Feldmeier Tank Processors 5200L

  • Manufacturer: Feldmeier
  • Model Number: 5200L
  • Frain Number: R29334

Feldmeier, 1350 gallon capacity, 316 stainless steel 3-zone jacketed process tank. Vessel dimensions: 76" ID x 72" deep with 60" straight wall. Equipped with a dome top, slant bottom, (1) 20" diameter top entry hinged man way, (2) thermowells, 3 Hp top mounted 27" diameter prop agitator and 2½" OD / 2" ID tri-clamp style bottom center discharge with a 12" ground clearance.

Top Ports:
(3) 3½"OD / 3"ID Tri-Clamp
(2) 2½"OD / 2"ID Tri-Clamp
(5) 2"OD / 1½"ID Tri-Clamp

Side Ports:
(1) 3½"OD / 3"ID Tri-Clamp

Jacket Ports:
(8) ¾" NPT

Vessel:
MAWP: 25 PSI @ 176°F
MDMT: -22 °F @ 25 PSI

Jacket:
MAWP: 50 PSI/FV @ 176°F
MDMT: -22°F @ 50 PSI/FV

Nat’l Brd: 2684

OAD: 88"L x 82"W x 120"H

Get a Free Quote Call: 630-629-9900

Feldmeier Tank Processors 5200L

  • Manufacturer: Feldmeier
  • Model Number: 5200L
  • Frain Number: R29335

Feldmeier, 1350 gallon capacity, 316 stainless steel 3-zone jacketed process tank. Vessel dimensions: 76" ID x 72" deep with 60" straight wall. Equipped with a dome top, slant bottom, (1) 20" diameter top entry hinged man way, (2) thermowells, 3 Hp top mounted 27" diameter prop agitator and 2½" OD / 2" ID tri-clamp style bottom center discharge with 12" ground clearance.

Top Ports:
(3) 3½"OD / 3"ID Tri-Clamp
(2) 2½"OD / 2"ID Tri-Clamp
(5) 2"OD / 1½"ID Tri-Clamp

Side Ports:
(1) 3½"OD / 3"ID Tri-Clamp

Jacket Ports:
(8) ¾" NPT

Vessel:
MAWP: 25 PSI @ 176°F
MDMT: -22 °F @ 25 PSI

Jacket:
MAWP: 50 PSI/FV @ 176°F
MDMT: -22°F @ 50 PSI/FV

Nat’l Brd: 2687

OAD: 88"L x 82"W x 120"H

Get a Free Quote Call: 630-629-9900

Pfaudler Tank Reactor GL 200 GAL

  • Manufacturer: Pfaudler
  • Model Number: 200 GAL
  • Frain Number: 5B1401

Glasteel Glass Lined/Carbon Steel Shell Reactor Has 200 Gal. Working Capacity. Internal Rating 105 Psi At 650 Deg.F, Jacket Rating 70 Psi At 350 Deg.F, And A Jacket Pressure W/Internal Rating Of 70 Psi Has A Straight Wall Measurement Of 32" And A 12" x 16′ (oval) Manway W/Glass-Lined Clamp Style Cover And 2 4" Top Outlets With Clamp Style Top Pressure Plates. (3) 2 1/4" Side Jacket In/Outlets & Bottom Center Discharge With 8" Floor Clearance. National Board# is E174-1196

Get a Free Quote Call: 630-629-9900

Todd Street Inc Tank SS Single Wall 150 GAL

TSI, 150 gallon, 304 stainless steel skid mounted portable recovery / recirculation tank. Vessel Dimensions: 32″ diameter x 60″ deep with a 56″ straight wall. Equipped with a lift off cover, (3) component level sensor, 3½”OD / 3″ID Tri-clamp style bottom drain with 15″ ground clearance and 3″ID / 2½”ID bottom side discharge to a Fristam, Model FPX, centrifugal pump with a 7″ diameter impeller powered by a 10 HP motor. System mounted on heavy duty stainless steel base with casters.

Side Access:
(1) 6½”OD / 5½”ID Tri-Clamp
(1) 2″OD / 1½” ID Tri-Clamp
(9) 2″OD / ¾”ID Tri-Clamp

OAD: 58″L x 36″W x 76″H

Get a Free Quote Call: 630-629-9900

Walker Tank Processors MT-202

  • Manufacturer: Walker
  • Model Number: MT-202
  • Frain Number: R29403

Walker, 150 gallon capacity, 316L stainless steel jacketed / insulated process tank, with gallons of product per hour – depending on materials and application. Vessel dimensions: 46" diameter x 32" deep with 24" straight wall. Equipped with 18" diameter bolt down man way, 2 Hp top mounted scrape agitator, Thermowell, 6" wide fixed baffle and 3" OD / 2.5" ID Tri-clamp style bottom discharge with 24" ground clearance. Mounted on (4) stainless steel legs.

Top Ports:
(1) 3½"OD / 3"ID Tri-clamp
(1) 3"OD / 2½"ID Tri-clamp
(1) 2½"OD / 2"ID Tri-clamp

Jacket Ports:
(4) 2"OD / 1½"ID Tri-clamp

MAWP: 150 PSI @ 338°F
MDMT: -20°F @ 150 PSI
Nat’l Brd: 6578

OAD: 51"L x 49"W x 87"H

Get a Free Quote Call: 630-629-9900

Nova Tank SS Single Wall 10 GAL

  • Manufacturer: Nova
  • Model Number: 10 GAL
  • Frain Number: 5F4514

Nova, 10 Gallon, 316 stainless steel single wall, internal pressure rated mixing vessel. 16" ID x 18" straight wall, flat top with flip up, bolt down cover and top mounted prop style mixer (needs Drive). (1) 3-1/2" OD sanitary top port with sight glass, (3) 2-1/2" sanitory top ports one with piston acctuator valve and (1) 2" OD sanitary top port with filter. Internal pressure rated: MAWP of 15psi @ 250 Deg F and MDMTof 30psi @ -20 Def F. (2) 2-1/2" OD and (5) 2" OD side sanitary ports. Dish bottom, 2" OD sanitary center bottom discharge has 17" floor clearance with (3) stainless steel legs mounted on stainless steel 24" x 24" base with casters.

OAD: 36" L x 29" W x 65" H

Get a Free Quote Call: 630-629-9900
