Stainless Steel Single Wall Machines

Tank SS Single Wall 1000GAL

• Model Number: 1000GAL
• Frain Number: 5G7913

1000 gallon, 304 stainless steel single wall tank. 66" diameter x 72" high straight wall. Equipped with a lift off top with a 23" x 20" manway, dish bottom, (4) 6" wide baffles and 2" NPT style bottom discharge with 3" ground clearance.

Top Ports:
(1) 3½" NPT
(1) 2" NPT
(1) 6"OD / 2"ID 4-bolt flange

Side Ports:
(1) 3" NPT
(4) 1" NPT

OAD: 72"L x 72"W x 92"H

Tank SS Single Wall 160 GAL

• Model Number: 160 GAL
• Frain Number: 5F0261

160 gallon, 304 stainless steel, single wall tank. 38" ID x 33" straight wall, flat top lid with (1) 3” and (1) 2" sanitary inlets, slant bottom with 2" OD side bottom discharge, mounted on a stainless steel base with non-locking casters.

OAD: 62Lx50Wx50H

Tank SS Single Wall 220 GAL

• Model Number: 220 GAL
• Frain Number: 5C5488

220 Gallon 304 stainless steel storage tank with 36" diameter x 50" straight wall and handles. Domed top. Open top tank 16" ID. Two 2 1/2" tri clover inlets. Flat wall sides with (2) 3-1/2" x 38"L baffles, 1-1/4" side bottom discharge and dish bottom. Mounted on 4 casters.

OAD: 32"L x 32"W x 65"H

Cherry Burrell Tank SS Single Wall 6000GAL

• Manufacturer: Cherry Burrell
• Model Number: 6000GAL
• Frain Number: 5H0961

Cherry Burrell, 6000 Gallon, 304 stainless steel, insulated mixing tank. Vessel Dimensions: 110" diameter x 144" straight wall. Equipped with a dome top, dish bottom, 20" x 16" side manway with bolt down cover, Paddle agitation powered by a 2 hp drive, thermowell, CIP spray ball supplied by a 2"OD / 1½"ID Tri-Clamp fitting and 2½"OD / 2"ID Tri-clamp style bottom discharge with pneumatic ball valve and 28" ground clearance.

Top Access:
(1) 3½"OD / 3"ID Tri-Clamp
(3) 2½"OD / 2"ID Tri-Clamp
(1) 2" NPT

OAD: 120"L x 115"W x 230"H

Lee Tank SS Single Wall 300DBT

• Manufacturer: Lee
• Model Number: 300DBT
• Frain Number: R30126

Lee, Model 300DBT, 300 gallon capacity, 316 stainless steel single wall tank. Vessel dimensions: 44" diameter x 55" deep with dish style bottom. Equipped with flip up covers and 10 Hp bottom side mounted Dixie mixer agitator. Unit mounted on (4) legs with a 3½" OD / 3" ID tri-clamp style bottom discharge with 16" ground clearance.

Top Ports: (7) 2½" OD / 2" ID Tri-clamp

Side Ports: (2) 2½" OD / 2" ID Tri-clamp

OAD: 100"L x 47"W x 83"H

Lee Tank SS Single Wall 75SSDBT

• Manufacturer: Lee
• Model Number: 75SSDBT
• Frain Number: 5G9771

Lee, Model 75SSDBT, 75 gallon capacity, 316 stainless steel process tank. Vessel dimensions: 30" diameter x 24" straight wall. Equipped with bolt down dome top, (2) 3" diameter sight glasses, dish bottom, top mounted prop agitation powered by a 0.87 hp drive with variable speed control and bottom center 2" OD / 1½" ID Tri-clamp style discharge with ball valve and 15" ground clearance. Mounted on (4) tubular legs with locking casters.

Top Ports:
(4) 2"OD / 1½"ID – Tri-clamp

MAWP: 50 PSI @ 300°F (Vessel)
Nat’l Brd: 4453

OAD: 43"L x 43"W x 85"H

Lee Tank SS Single Wall 500LDBT

• Manufacturer: Lee
• Model Number: 500LDBT
• Frain Number: 5H4572

Lee 130 gallon (500 Liter) portable 316 stainless steel mixing vessel. Vessel Dimensions: 34"ID x 30"high straight wall, Vessel Pressure Rating: Max. Design Internal FV/35 psi @ 281°F. Equipped with dome top/dish bottom, 18"diameter manway with clampdown cover, 3"ID tri-clamp port, (8) 1-1/2"ID sanitary tri-clamp connection inlet ports, inclined/offset mixer with 4" prop agitation, 1-1/2"ID center bottom tri-clamp outlet, 3" ground clearance. Tank mounted on (4) heavy duty casters, two swivel with brakes.

National Board: 3998

OAD: 40"L x 36"W x 52"H

Tank SS Single Wall 250 GAL

• Model Number: 250 GAL
• Frain Number: 5H3081

250 gallon, 304 stainless steel, slant bottom tank. Vessel Dimensions: 38" diameter x 60" deep. Equipped with a 16" manway, vented top, 3" diameter overflow and (2) 3"OD / 2½"ID Tri-clamp style bottom discharges with 24" ground clearance. Mounted on (4) legs.

Top Access:
(1) 3"OD / 2½"ID Tri-clamp
(1) 2½"OD / 2"ID Tri-clamp

Side Access:
(1) 2½"OD / 2"ID Tri-clamp

OAD: 40"L x 40"W x 88"H

Tank SS Single Wall 300 GAL

• Model Number: 300 GAL
• Frain Number: 5H4270

300 Gallon, (2) compartment, 304 stainless steel. Each compartment is 300 gallons with inner dimensions of 46" x 40" x 42" Deep. Equipped with flip up covers, top mounted spray balls and prop style mixers with ½ Hp motor drives and gauges. Slant bottom has 2½" OD / 2" ID sanitary side bottom discharge port with 15" ground clearance. Mounted on (6) stainless steel legs. Rectangle construction provides maximum capacity in small floor area.

OAD: 90" L x 50" W x 80" H

Tank SS Single Wall 105 GAL

• Model Number: 105 GAL
• Frain Number: 5H3604

105 gallon, stainless steel, COP tank. Equipped with 96" long x 18" wide x 13" deep trough with 2" OD / 1½" ID NPT connection bottom drain. Mounted on (4) leg stainless steel base frame.

OAD: 99"L x 21"W x 36"H

Pure Flo Tank SS Single Wall 250 GAL

• Manufacturer: Pure Flo
• Model Number: 250 GAL
• Frain Number: 5H4100

Pure-Flo Precision, ITT Industries, 250 gallon, 316L stainless steel vacuum vessel. Vessel dimensions: 46 diameter x 46" deep with a 31" straight wall. Equipped with an 18" diameter flip top latch down cover and side transport handles. Dish bottom has 2½" OD / 2" ID center bottom discharge with 15" ground clearance Mounted on (4) stainless steel legs with casters.

Top Ports:
(2) 2" OD / 1½" ID Tri-Clamp

MAWP: 50 PSI @ 100°F
MDMT: -20°F @ 50 PSI

250 Gallon Tank Designed For 15 PSI Vacuum

Nat’l Brd: 10970

OAD: 50" L x 45" W x 75" H

Perma San Stapco Stainless Tank SS Single Wall 61 GALLON OVC

• Manufacturer: Perma San Stapco Stainless
• Model Number: 61 GALLON OVC
• Frain Number: 5H1308

Perma San, Model OVC, 60 gallon, 304 stainless steel tank and pump system with gallons of product per hour – depending on materials and application. Vessel Dimensions: 24" diameter x 32" deep with 29" straight wall. Equipped with flip up lids, cone bottom has 3½"OD / 3"ID Tri-clamp style bottom discharge with 47" ground clearance. Waukesha, Model 2045, Stainless steel centrifugal pump. Rated from 20 to 190 gallons per minute with a head of 22 to 88 feet – depending on materials and application. Pump head equipped with a 2½"OD / 2"ID Tri-clamp style suction infeed and a 2"OD / 1½" ID Tri-clamp style delivery discharge with 42" ground clearance. 4½" diameter impeller is driven by a 5 hp motor. Mounted on a stainless steel base frame with casters.

OAD: 54"L x 32"W x 84"H
