Jacketed Machines

Walker Tank Jacketed MIX

• Manufacturer: Walker
• Model Number: MIX
• Frain Number: 5G5391

Walker, Model MIX, 24 gallon 304 stainless steel dimple jacketed mixing tank. Vessel Dimensions: 20" diameter with a 21" straight wall. Equipped with variable speed top mounted Lightnin mixer with (2) Hydrofoil impellers each with (3) 5" long blades, lift off covers, (2) 1¼" threaded jacket inlets, slant bottom, 2" OD / 1½" ID tri-clamp bottom side discharge with 24" ground clearance. Mounted on (3) tubular legs with casters.

MAWP: 125 PSIG @ 300° F
MDMT: -20°F @ 125 PSI
Nat’l Brd: 1763

OAD: 33" L x 32" W x 76" H

National Equipment/Union Stand Tank Jacketed 1000LBS

• Manufacturer: National Equipment/Union Stand
• Model Number: 1000LBS
• Frain Number: 5G4356

National Equipment, 1,000 lb capacity, mild steel chocolate melter. Vessel has a 38" I.D. and 23½" straight wall. Equipped with bottom entry full sweep scrape agitator. 2" flanged outlet with 4-bolt flanged to 2" MNPT adaptor and stainless steel ball valve, 20"high discharge ground clearance. Control panel with precision temperature controller. Stainless steel top cover with 1/3 flip up hinged door, 2" and 1-1/2" tri-clamp inlet ports. Chromalox screw plug immersion heater. 1" MNPT jacket inlet and 1-1/2" MNPT Jacket outlet. Unit mounted on 49"L x 40"W x 7"high diamond plate steel platform with (4) 17"high angle bar legs.

OAD: 60"L x 49"W x 61"H

National Equipment/Union Stand Tank Jacketed 1000LB

• Manufacturer: National Equipment/Union Stand
• Model Number: 1000LB
• Frain Number: 5G4357

110 Gallon,1,000 lb cap. Mild steel chocolate melter. 38" I.D. x 23-1/2"high. Equipped with bottom entry full sweep agitator. 2" flanged outlet with 4-bolt flanged to 2" MNPT adaptor and stainless steel ball valve, 20"high discharge ground clearance. Control panel with precision temperature controller. Stainless steel top cover with 1/3 flip up hinged door, 2" and 1-1/2" tri-clamp inlet ports. Screw plug immersion heater. 1" MNPT jacket inlet and 1-1/2" MNPT Jacket outlet. Mounted on 48"L x 40"W x 7"high stainless steel diamond plate platform with (5) 17"high stainless steel square tube legs.

OAD: 60"L x 49"W x 60"H

Apache Tank Jacketed V

• Manufacturer: Apache
• Model Number: V
• Frain Number: 5G4784

Apache, Model V-381, 30 gallon 316L stainless steel jacketed tank with a 6.8" diameter prop agitation powered by a ½HP drive. Jacket is rated for maximum of 100PSI/FV @ 370°F and a minimum of 100PSI/FV @ -20°F with (2) 5"OD/1¾"ID four-bolt flange fittings. Vessel maximum working pressure is 45psi/FV @ 370°F and a minimum of 45psi/FV @ -20°F. Vessel dimensions: 20" diameter x 30" straight wall. Capsul style closed top equipped with (1) 6½"OD/5¾"Id, (1) 4½"OD/3¾"ID, (1) 3½"OD/2¾"ID, (3) 2"OD/1¼"ID and (1) 1"OD/½"ID tri clamp style fittings. Side wall has (1) 1"OD/½"ID tri-clamp fitting and (1) ¾" threaded slot for a temperature probe. Hemispherical bottom has (1) 2"OD/1¼"ID Tri-clamp fitting with 30" ground clearance. Unit is mounted on (3) legs with locking casters.

Nat’l Brd: 303

OAD: 30" L x 30" W x 70" H

Apache Tank Jacketed V

• Manufacturer: Apache
• Model Number: V
• Frain Number: 5G4786

Apache, Model V-363, 200 liter 316 stainless steel jacketed tank. Jacket is rated for maximum of 100PSI/FV @ 300°F and a minimum of 100PSI/FV @ -20°F with (2) 5"OD/1½"ID four-bolt flange fittings. Vessel is rated for maximum of 45PSI/FV @ 300°F and a minimum of 45PSI/FV @ -20°F Vessel dimensions: 24" diameter x 30" straight wall. Capsul style closed top equipped with (1) 6½"OD/5½"ID, (2) 3½"OD/2¾"ID, (3) 2"OD/1¼"ID and (1) 2"OD/¾"ID tri clamp style fittings. Side wall has (1) ¾" threaded slot for a temperature probe. Bottom has (1) 2"OD/1¼"ID Tri-clamp fitting with 30" ground clearance. Unit is mounted on (6) legs with locking casters.

Nat’l Brd: 307

OAD: 40" L x 40" W x 73" H
