Net Weight Machines

Used Net Weight Equipment

Filler Liquid Scale is a machine, which fills a container with a certain amount of liquid using the weight of the liquid to fill the container to a set point. The scale liquid filler (net weight filler) weighs the container prior to fill and continuously weighs the container during the fill to reach the appropriate liquid weight for the fill.

Net Weight Equipment In Stock

Crandall Filler Liquid Scale FILL/LID

  • Manufacturer: Crandall
  • Model Number: FILL/LID
  • Frain Number: 5H2140

Crandall, combination, single head, pnuematic liquid filler and lid closer with number of pails per hour – depending on materials, application and operator dexterity. Fill range: 1 to 5 gallons with accuracy of 1 part in 10,000 to within 0.1% of target weight. for filling of non-foaming and semi liquid products which have no particles. Containers: Plastic, metal, glass and composite with proper change parts. Equipped with 132" long x 14-1/2" wide roller conveyor with 1"OD rollers on 1-1/2" centers and 1/2" gaps. Filling head and 14"OD lid ram compression arm with pressure guage and both are hand crank height adjustable. Control panel touch pad with read out and main power, manual off auto, jog, glycol on / off switches with empty and full pail, lid drop with e-stop and numatic package. Mounted on heavy duty painted base frame.

OAD: 132" L x 60" W x 68" H

Get a Free Quote Call: 630-629-9900

Serac Filler Liquid Scale RC8V41/720

  • Manufacturer: Serac
  • Model Number: RC8V41/720
  • Frain Number: 5C6942

Serac 8 valve rotary weigh filler designed for corrosive products with 4 head rotary capper which includes a bowl cap feed with cap elevator. Container size to: round bottle to 165mm (6.5" D) diameter; square bottle to 130mm diameter; rectangle bottle to 195mm long side; off set neck bottles to 145mm diameter. All corrosive resistant material product contact parts. Has AB SLC 5/03 PLC control system and AB adjustable frequency control drive. Work screw to star wheel container handling with quick release for fast changeover. Has screens in nozzles to help reduce air for foamy products.
OAD: 276"L x 72"W x 140"H

Get a Free Quote Call: 630-629-9900

Velcon Fillers / Intersystems Filler Liquid Scale CD4T55

  • Manufacturer: Velcon
  • Model Number: CD4T55
  • Frain Number: 5G6830

Velcon, Model CD4T55, net weight, palletized 55 gallon drum and tote open top non-foaming liquid filler with number of containers per hour – depending on materials, application and operator dexterity. 316 stainless steel wetted parts. Fill range: up to 55 gallon drums or 72" totes of non-foaming liquids. Equipped with 2" OD net weight, cut off filling lance, no drum / no fill and net weight over / under fill monitoring features, with 48" x 48" 5,000 lb capacity weigh scale base with DWM-IV microprocessor weigh meter control system.

OAD: 89" L x 60" W x 140" H

Get a Free Quote Call: 630-629-9900

Velcon Fillers / Intersystems Filler Liquid Scale CDT5

  • Manufacturer: Velcon
  • Model Number: CDT5
  • Frain Number: 5G6831

Velcon, Model CDT5, semi automatic, net weigh, 5 gallon pail, open top, non-foaming liquid filling system, with number of pails per hour – depending on materials, application and operator dexterity. 316 stainless steel wetted parts. Fill range: up to 5 gallons of non-foaming liquids. Equipped with 36" long x 2" OD positive cut off filling lance and drip pan, 18" x 18" 100 lb capacity weigh scale base with DWM-IV microprocessor dribble weigh meter control system and operator control box with start / stop switch and dribble regulator and gauge.

OAD: 38"L x 35"W x 86"H

Get a Free Quote Call: 630-629-9900

Crandall Filler Liquid Scale EF14X220FE

  • Manufacturer: Crandall
  • Model Number: EF14X220FE
  • Frain Number: 5H0681

Crandall Model EF14X220FE, electronic, sub surface, net weight, 55 gallon drum / tote filling system with number of containers per hour – depending on materials, application and operator dexterity. 316 stainless steel wetted parts. Fill range: 55 gallons metal or plastic containers with fill openings as small as 1-3/8 with proper change parts. (Currently has 2-1/4" OD x 42" stainless steel lance). Equipped with two stage, diving, cut off lance, NEMA 1 enclosure and scale indicator with NEMA4X stainless steel enclosure. Scale section 60" long x 50" wide with 5,000 lb capacity. One 5′ section of in feed and one 5" section of discharge conveyor. Change parts required to accommodate size range.

OAD:

Get a Free Quote Call: 630-629-9900

Crandall Filler Liquid Scale FDI220PLX

  • Manufacturer: Crandall
  • Model Number: FDI220PLX
  • Frain Number: R25770

Crandall Model FD122PLX, sub surface drum filler. Equipped with 28" x 27" scale roller platform, capacities up to 1000 lbs, 2" OD x 36" long single stainless steel filling lance, tare button and hand crank tare wheel over-under indicator. Operation: operator presses the tare button and turns the tare wheel until the over-under indicator shows balance then presses start button and the lance descends to the bottom of the container begins to fill, lance rises slowly to the safety stop, container approaches shut-off weight, flow rate reduces to maintain accuracy. when shut-off weight is reached, the lance withdraws from the container and operator removes and replaces. Speeds dependant on materials, application, machine configuration and operator dexterity.

OAD: 72" L x 36" W x 81" H

Get a Free Quote Call: 630-629-9900

Pneumatic Scale Filler Liquid Scale 1350

PART OF COMPLETE LINE

24 Head rotary, net weigh filler rated 50 to 200 containers per minute – depending on materials and application. Equipped with 24 fill stations on 54" diameter turret, set on 7" centers, maximum container size: 6-1/2" diameter x 14" high, with fill accuracies of +/-1g. All 316 stainless steel contact parts, 1/4" positive cut off nozzles, no bottle / no fill, CIP system, 35 gallon jacketed pressure supply tank and electrically interlocked lexan guarding, with touch screen interface. Available for additional cost; 8 head capper.

OAD: 98" L x 78" W x 102" H

Get a Free Quote Call: 630-629-9900

Serac Filler Liquid Scale R15/36 filling machine rotary scale

  • Manufacturer: Serac
  • Model Number: R15/36
  • Frain Number: 5D4182

S/S, 15-head rotary scale filler rated up to 150/min (last running 5 gallon viscous fills @ 28/min). Equipped with AB PLC, no-container no-fill and drip tray. Maximum container size: round: 11", Max scale weight capacity is 66 lbs. Capable of filling a variety of products from light to heavy viscosity at hot or cold temps for both abrasive and non abrasive products.

OAD: (L) 120" x (W) 84" x (H) 108"

Get a Free Quote Call: 630-629-9900

Serac Filler Liquid Scale R1216NW Filler 12 / 4 Capper head S/S Rotary Scale

  • Manufacturer: Serac
  • Model Number: R1216NW
  • Frain Number: 5D4181

12-head stainless steel rotary scale filler 20 to 120 cpm depending on material and application. Equipped with four head S/S rotary capper. 15.5 lbs max scale capacity. Variable speed drive and no container no fill. Equipped with gutter drain, set on 7-1/2" centers

Automatic S/S 4 head rotary chuck capper. Model V4/360 capable 20 of 120 cpm, depending on material and application. Equipped with a gutter drain and no container no cap with individual friction disc torque control and set on 11" centers.

Last running 1 gallon round syrups

Filler OAD: (L) 72" x (W) 58" x (H) 108"
Capper OAD: (L) 52" x (W) 58" x (H) 96"

Get a Free Quote Call: 630-629-9900

Pneumatic Scale Filler Liquid Scale 2030 40 VALVE used filler

  • Manufacturer: Pneumatic Scale
  • Model Number: 2030 40 VALVE
  • Frain Number: 5D0621

40 Valve net weight filler rated to 400 bpm. Container size range: Diameter: 1-1/2 to 6"; Height 2-1/2 to 14", Maximum rectangular: 5-1/8 by 3-9/16". 316 s/s laminar flow nozzles, no container – no fill. Rapid no tool changeover. Positive control neck guides, motorized neck cam adjustment with digital indicator. Load cell and platform assembly with quick change plug in feature. Nema 4 electronics with Nema 4X enclosures. Touch screen operator interface, AB PLC with AB variable speed drive. 35 gallon 316 ss pressure supply tank. Variable nozzle blow down capability, flush in place system with slid in trough. Product re-circulating system with sanitary pump & timer. Stainless steel clad base and lower turret with stainless steel access doors, guards and elevating columns. Kynor coated base and support castings. Corrosion resistant exterior finish.

Get a Free Quote Call: 630-629-9900
