Frain Industries has hundreds of used industrial liquid mixers in stock and ready to set up for your application. Frain offers a complete line of industrial liquid mixers and blenders ranging from laboratory to production scale with batch, in-line, or powder induction solutions. See also:  Powder Mixers
Frain carries mixers for use in the candy, food, chemical, pharmaceutical, nutraceutical, home use, and personal care industries. Additionally our mixers cover numerous process stages such as mixing, agglomeration, classification and metering.
Frain Industries used industrial liquid mixers can be used for many applications including: blending, emulsifying, homogenizing, hydrating, dissolving, powder/liquid mixing, deagglomerating, reclamation, particle size reduction, agitation, refining edible oils as well as many others. This type of universal product line, coupled with the largest on sight inventory allows us to give the closest match for the perfect equipment paring.
Contact a Frain engineer to discuss your liquid mixing application and requirements.
Frain Industries carries liquid mixers from many respected OEMs, including: APV, ARDE, Baldor, Barinco, Bematek, Breddo, Cherry Burrell, Lee, Leeson, Lightning, Myers, Norman, Reynolds, Ross, Silverson, Tri Clover as well as others. We are constantly receiving used liquid mixers in a variety of models and capacities. If you don’t see the mixer you are looking for, call one of our representatives and we will find it for you. With well over 8000 machines in stock and 100+ liquid mixers in stock we usually have what you need on hand, it’s what you come to expect Frain Services to be.
Frain Industries carries mixers for many applications including:
Food industry: Aloe, bee pollen, pineapple, sesame, flavor syrups, fruit tea, ice cream, butter, jam, juice, soybean, bean sauce, sweetened bean paste, peanut milk, protein milk, soybean milk, salad dressing, sauces, dairy products, malted milk, flavoring essence, flavor emulsions, beverages, emulsified chick bone paste, emulsified pig skins and other animal skins, mayonnaise, syrups, yeast and many others.
Pharmacy:Â Â Antacids, antibiotics syrup, nutrition liquid, Chinese traditional patent medicine, cream medicine, biological products, cod-liver oil, injectables, pollen, royal jelly, vaccines, various ointments, various oral liquid, injection, vein liquid extract, pancreatin agent, emulsion, animal medicine, mineral oil emulsions, vitamins, and many others.
Cosmetic: Cold creams, hair gel, liquid make-up, lotions, shampoo, shaving cream, deodorants, essential oils, eye make-up, ointments and many others.
Daily chemicals:Â Aerosols, antiperspirants, toothpaste, detergent, shampoo, shoe polish, cosmetics, bath concentrate, soap, fragrance grease, pigments, wax emulsions and many others.
Chemical industry: Paint, color dispersions, pigment, dye, coating, fertilizers, fluxes, herbicides, insecticides, lubricant, lubricating grease, diesel, petroleum catalyst, printing Inks, emulsified asphalt, adhesive, detergent, plastic, explosive, glass fiber reinforced plastic, leather, emulsion explosive and many others.
Other industries: Textile industry, paper making industry, plastic industry and bio-chemical
Breddo, Model LDT, 50 gallon 304 stainless steel single wall liquefier. Chamber dimensions: 24" x 24" with a 22" straight wall. Equipped with an 18" diameter top man way with flip up bolt down cover, bottom 6 hole / 3 wing general purpose impeller and 3" OD / 2½"ID Tri-Clamp side bottom discharge with 29" floor clearence with bottom 10 Hp motor drive. Mounted on stainless steel (4) leg tubular frame.
OAD: 34"L x 26"W x 82"H
Walker Model Liqui-Mixer, 750 gallon, 316L stainless steel construction high shear, jacketed liquefier with number of gallons of product per hour – depending on materials and application. Chamber dimensions: 63" in Length; 63" in Width; 47" straight wall; 27" sloped cone bottom. Equipped with 18" ID manway with flip top bolt down cover and 62" wide flip top cover. Cone bottom with 12" OD high shear 6 hole / 3 wing impeller and 3½" OD sanitary center bottom discharge port with 36" floor clearence and control box with start / stop push bottons. Mounted on stainless steel tubular base frame.
Top Ports:(3) 3½" OD / 3" ID Tri-clamp(3) 2½" OD / 2" ID Tri-clamp(2) 2" OD / 1½" ID Tri-clamp(1) 3" OD open vent
Jacket Access:(2) 2" NPT
MAWP: 40 PSI @ 250°F MDMT: -20°F @ 40 PSI
OAD: 99" L x 72" W x 106" H
Walker, Model MT-101, 100 gallon 316L stainless steel insulated liquefier with amount of product per hour – depending on materials and application. Chamber dimensions: 46" diameter x 32" deep with 19" straight wall. Equipped with 21" OD top man way with flip up bolt down cover, scrape agitation powered by 2 Hp motor drive, 6½" adjustable baffle, Thermowell, CIP spray balls, side and bottom jacketed, with 10" OD bottom 6 hole / 3 wing general purpose impeller powered by 20 Hp motor drive and 3" OD / 2½" ID Tri-clamp side bottom discharge with 24" floor clearence. Mounted on stainless steel (4) leg tubular frame.
Top Access:(1) 3½"OD / 3"ID Tri-clamp(1) 2½"OD / 2"ID Tri-clamp(1) 2"OD / 1½"ID Tri-clamp
Jacket Access:(4) 2"OD / 1½"ID Tri-clamp
Nat’l Brd:6571MAWP:150 PSI @ 338°FMDMT:-20°F @ 150 PSI
OAD: 56"L x 55"W x 86"L
Cherry Burrell, 75 gallon 304 stainless steel, single wall liquefier. Chamber dimensions: 35" x 35" with 20" straight wall. Equipped with 24" OD top man way with flip up bolt down cover, bottom 6 hole / 3 wing general purpose impeller and 2½" OD / 2" ID sanitary side bottom discharge with 18" floor clearence, bottom side mounted 15 Hp motor drive. Mounted on stainless steel (4) leg tubular frame.
Top Access:(2) 2½"OD / 2"ID Tri-Clamp(1) 1"OD / ¾"ID Tri-Clamp(1) 3" OD Open Vent
OAD: 60"L x 35"W x 60"H
Breddo Model LOR, 100 gallon, stainless steel, jacketed, high shear liquefier with amount of product per hour – depending on materials and application. Equipped with 42" ID x 21" straight wall with 22" OD man way with flip top bolt down cover, (2) 2-1/4" OD threaded top sanitary ports. Full side and bottom jacket rated to 125 psi and has a temp rating up to 350 Deg F with (3) 2-1/2" OD threaded jacket ports. Bottom 10" OD 6 hole / 3 wing impeller with inside baffle and side mounted 50 Hp motor belt drive with bottom belt guarding and latch handles. Cone bottom has 2-1/2" OD / 2" ID side bottom butterfly discharge valve with 23" ground clearence. Control panel has a A/B Powerflex vari freqency controller with touchpad and temperature controls, start and e-stop push buttons. Mounted on stainless steel tubular style frame with casters.
OAD: 77" L x 60" W x 66" H
Burdosa, Model GR80, inline, continuous, dynamic loop mixer. Rated from 60 to 92 gallons per minute – depending on materials, application and machine configutation. Equipped with an 8" OD x 16" long mixing chamber with a low pressure jacket, 3"OD / 2"ID seated bevel style primary charge port, 5½"OD / 1½"ID circular flange style secondary charge port and 3"OD / 2"ID seated bevel style discharge port. Mixer rotor powered by a 5.3 hp drive with variable speed controls.
OAD: 40"L x 32"W x 80"H
Breddo, Model LDT, 200 gallon 304 stainless steel liquefier. Chamber dimensions: 40" x 40" with 33" straight wall. Equipped with 24" OD top man way with flip up bolt down cover, (1) CIP spray ball supplied by a 2"OD / 1½"ID Tri-clamp fitting, bottom 6 hole / 3 wing general purpose impeller and 3" OD / 2½" ID sanitary side bottom discharge with 24" floor clearence, bottom 25 Hp motor drive. Mounted on stainless steel (4) leg tubular frame.
Top Access:(5) 2½"OD / 2"ID Tri-Clamp
OAD: 40"L x 40"W x 75"H
Tri-Clover, Model F1114LMDG-MBV-B60-S, stainless steel tri-blender with production rates of 45 gallons and 50 lbs of product per minute – depending on materials and application. Equipped with 16" OD x 22" deep funnel style stainless steel product hopper with a 1.5" diameter product charge, 1 Hp centrifugal liquid supply pump, 5 Hp bottom mixer motor drive and 1 HP auxiliary / transfer pump. Control panel push button start / stop and mounted on stainless steel push cart.
OAD: 52"L x 36"W x 66"H
Tri-Clover, Model F2116EXPSYS, stainless steel tri-blender with production rates of 45 gallons and 50 lbs of product per minute – depending on materials and application. Equipped with 12" OD x 13" deep funnel style stainless steel product hopper with 2" diameter product charge, 1 Hp centrifugal liquid supply pump has 2" OD / 1½" ID tri-clover fitting and 3 Hp bottom mixer motor drive. Control panel has start / stop push buttons. Mounted on stainless steel push cart.
OAD: 40"L x 32"W x 53"H
Breddo, Model LDDW, 250 gallon 304 stainless steel jacketed and insulated liquefier. Chamber dimensions: 45" x 45" with a 32" straight wall. Equipped with a 23" x 23" top man way with flip up cover, CIP spray ball supplied by a 2"OD / 1¼"ID Tri-clamp fitting, bottom 6 hole / 3 wing general purpose impeller, 2½" OD/2"ID Tri-Clamp side bottom discharge with 34" floor clearance and bottom two speed 25/12 Hp motor drive. Mounted on stainless steel (4) leg tubular frame.
Top Access:(1) 2½"OD / 2"ID – Tri-clamp(2) 2"OD / 1¼"ID – Tri-clamp
Jacket Rating:90 PSI @ 350 F
Jacket Access:(2) 1½" NPT
OAD: 59"L x 52"W x 90"H
Breddo, Model LDD, 250 gallon 304 stainless steel single wall liquefier. Chamber dimensions: 43" x 43" with 34" straight wall. Equipped with 18" diameter top man way with flip up bolt down cover, (3) 2½" OD / 2" ID and (1) 3½" OD / 3" ID tri-clamp style top inlet ports, (1) CIP spray ball, bottom 6 hole / 3 wing general purpose impeller and 3" OD / 2½" ID sanitary side bottom discharge with 20" floor clearence, bottom 25 Hp motor drive. Mounted on stainless steel (4) leg tubular frame.
OAD: 45" L x 45" W x 73" H
Breddo Model LORW, 50 gallon, 316L stainless steel, high shear, jacketed liquefier with amount of product per hour – depending on materials and application. Equipped with 32" ID x 20" straight wall with 13" sloped bottom, 18" ID man way with flip top bolt down cover, (2) 2-1/2" OD / 2" ID and (1) 2"OD / 1-1/2" ID top sanitary ports. 90 psi jacket with (2) 2" OD / 1-1/2" ID threaded jacket ports and side temperature gauge with 10" OD bottom 6 hole / 3 wing impeller and side mounted belt motor drive. Cone bottom has 3" OD / 2-1/2" ID side bottom discharge with 25" ground clearance. Control panel has speed pot dial, mixer start, stop and e-stop push buttons. Mounted on tubular style base frame.
OAD: 48" L x 36" W x 64" H
