Impulse Machines

Used Impulse Equipment

Frain Industries can help you with your Impulse bag sealer project no matter how big or small your sealing needs. Sealer Bag Impulse is a bag sealer which uses impulse sealing jaws to seal a bag made of heat sealable material.

Impulse Equipment In Stock

Doboy Sealer Bag Impulse JSL

  • Manufacturer: Doboy
  • Model Number: JSL
  • Frain Number: R26010

Doboy Model JSL, semi auto, paper card header, label applicator and bag sealer rated from 5 to 30 bags per minute – depending on materials, application and operator dexterity. Header size range: 2-1/2" to 9-1/2" in Width; 1-1/4" to 6" in Height. Equipped with adjustable 12" long x 9" wide header magazine, with recipicating pic n place, 10" wide x 2-1/2" thick seal jaw with 1/2" diameter center top hole punch. Control panel with temperature heat controller, run / jog and heat on / off switches, with start and e-stop buttons and is mounted on hand crank height adjustable stand with casters. Designed to heat seal bags depending on material and apply header card labels to the top of a pre-made, pre-filled cello, coated cello, polyethylene, saran, and other heat seal material bags. Label widths and folds are adjustable to fit a wide range of bag packaging needs.

OAD: 42" L x 40" W x 60" H

Get a Free Quote Call: 630-629-9900

FMI Sealer Bag Impulse 40BARSEALER

  • Manufacturer: FMI
  • Model Number: 40BARSEALER
  • Frain Number: 5C3091

Semi automatic stainless steel 40 inch bar sealer produces seals up to 40 inches long in almost any thermoplastic film. The seals can be validated, since the temperature, dwell time and pressure are precisely controlled and monitored. Capable of sealing various films from three layer to 5ml thick, single layer to 5ml thick & tyvek films. Has a 40" long seal x 1/4" wide. Suitable for use in clean rooms and has nema 4 controls. Pressure is provided pnuematically and has a cycle time of 5 seconds or less. Allen Bradley micrologix 1000 controls, psi gauge, reject/alarm lite, foot pedal controls, casters. Last running in medical device operation. OAD: 5’4"l x 3’6"w x 6’4"h.

Get a Free Quote Call: 630-629-9900

FMI Sealer Bag Impulse 40BARSEALER

  • Manufacturer: FMI
  • Model Number: 40BARSEALER
  • Frain Number: 5C2651

Semi automatic stainless steel 40 inch bar sealer produces seals up to 40 inches long in almost any thermoplastic film. The seals can be validated, since the temperature, dwell time and pressure are precisely controlled and monitored. Capable of sealing various films with temperature up to 400′ F, with variable dwell time and pressures up to 40-50psi (engineered for 90-100psi).. Has a 40" long seal x 1/4" wide. Suitable for use in clean rooms and has nema 4 controls. Pressure is provided pnuematically and has a cycle time of 5 seconds or less. Allen Bradley micrologix 1000 controls, psi gauge, reject/alarm lite, foot pedal controls, casters. Last running in medical device operation.

OAD: 5’4"l x 3’6"w x 6’4"h

Get a Free Quote Call: 630-629-9900

Rennco Sealer Bag Impulse 201

  • Manufacturer: Rennco
  • Model Number: 201
  • Frain Number: 5E3621

Rennco Model 201, semi-automatic, "smoke free" vertical, L bar sealer rated from 5 to 30 pouches per minute – depending on materials, application and operater dexterity. Pouch size range; 2" to 8" in Length; 2" to 10" in Width; up to 4-1/2" jaw opening. Equipped with bucketed in feed conveyor 96" long x 4" wide with 5" long x 4" wide x 1-1/2" deep buckets with discharge height of 48". Control panel has impulse heat sealing jaws, pneumatic controls, temperature controls, trim wind up and auto cycle capabilities. Mounted on (4) leg frame with casters.
Capable of running most unsupported centerfold roll stock films

OAD: 42"L x 48"W x 58"H Sealer
OAD: 108"L x 32"W x 56"H Conveyor

Get a Free Quote Call: 630-629-9900

JMC Packaging Equipment Sealer Bag Impulse WSB0918

JMC Packaging Model WSB0918, automatic, pre-made, wicketted bag sealer rated from 3 to 20 bags per minute – depending on materials and application Bag size range: 9" to 18" in Width x up to 28" in Length and can handle regular, press to close, or slide zipper style bags made of both poly and laminated materials from 1 to 6 mils thick, and can be intrigated with scale systems, volumetric fillers, or bowl feeders. Equipped with top 7" long x 4-1/2" wide product chute, 12" long x 18" wide wickett bag magazine and 19" long horiz seal bar. A/B PLC with touch screen controller,with heat seal temperature and speed controls, low bag sensor, statis bar light, and saftey guarding. Mounted on apoxy coated (4) leg base frame.

OAD: 96" L x 40" W x 76" H

Get a Free Quote Call: 630-629-9900

Rennco Sealer Bag Impulse 101SF

  • Manufacturer: Rennco
  • Model Number: 101SF
  • Frain Number: 5G3091

Rennco Model 101SF, semi-automatic, "smoke free" vertical, L bar sealer rated from 5 to 30 pouches per minute – depending on materials, application and operater dexterity. Package size range: 2" to 14" Vertical seal; 2" to 20" Horizontal seal; and up to 5" Thick. Equipped with PLC controller, vertical and horizontal seal jaw temperature controllers, cycle counter and E-stop. Film specifications: up to 22" in width with a max roll diameter of 12". Mounted on (4) leg frame.
Capable of running most unsupported centerfold roll stock films

OAD: 42" L x 40" W x 62" H

Get a Free Quote Call: 630-629-9900

Rennco Sealer Bag Impulse 101SF

  • Manufacturer: Rennco
  • Model Number: 101SF
  • Frain Number: 5G3094

Rennco Model 101SF, semi-automatic, "smoke free" vertical, L bar sealer rated from 5 to 30 pouches per minute – depending on materials, application and operater dexterity. Package size range: 2" to 14" Vertical seal; 2" to 20" Horizontal seal; and up to 5" Thick. Equipped with PLC controller, hole punch, vertical and horizontal seal jaw temperature controllers, cycle counter and E-stop. Film specifications: up to 22" in width with a max roll diameter of 12". Mounted on (4) leg frame.
Capable of running most unsupported centerfold roll stock films

OAD: 42"L x 40"W x 62"H

Get a Free Quote Call: 630-629-9900

Automated Packaging Systems Sealer Bag Impulse H100D

Semi-automatic, roll fed, bag sealer capable of up to 45 packages per minute. Bag size range: 3" to 22" in Lenght; 3" to 10 1/2" in Width; 0.0015" to 0.0040" in Thickness. Has 11 1/2"W seal jaw with serated knife cut, slide chute for product discharge, film up to 12"W, 4" max pass-through area, hot stamp foil imprinter, E-stop, seal temperature set point controller, quantity set point, and barrier guarding with electrical interlock.

OAD: 57"L x 29"W x 54"H

Get a Free Quote Call: 630-629-9900

Rennco Sealer Bag Impulse 201PP

  • Manufacturer: Rennco
  • Model Number: 201PP
  • Frain Number: 5E7980

Rennco Model 201, semi-automatic, "smoke free" vertical, L bar sealer rated from 5 to 30 pouches per minute – depending on materials, application and operater dexterity. Pouch size range; 2" to 8" in Length; 2" to 10" in Width; up to 4-1/2" jaw opening. Control panel has PLC, controller with Panel/View, variable heat and speed controls. Center fold polyethylene, pvc and shrink film. Up to12" in diameter on 3" core. Mounted on base frame with adjustable leveling legs.
Capable of running most unsupported centerfold roll stock films

OAD: 32" L x 32" W x 56" H

Get a Free Quote Call: 630-629-9900

Rennco Sealer Bag Impulse 501-52

  • Manufacturer: Rennco
  • Model Number: 501-52
  • Frain Number: 5E6950

Rennco Model 501, semi-automatic, "smoke free" vertical, L bar sealer rated from 5 to 30 pouches per minute – depending on materials, application and operater dexterity. Size range: 2" to 14" in Length; 2" to 52" in Width; up to 7" Thick. Equipped with 64" long film roll with 12" OD maximum web width and 3" OD core. Control panels has PLC controller with touch pad controls, Watlow vertical and horizontal seal jaw digital temperature controllers, pneumatic hole punch, sliding lexon safety door guarding. Mounted on (4) leg frame with casters.
Capable of running most unsupported centerfold roll stock films

OAD: 90" L x 48" W x 77" H

Get a Free Quote Call: 630-629-9900

Automated Packaging Systems Sealer Bag Impulse FAS1000S

Automatic, stainless steel, bagging system for loading and sealing poly bags from rollstock at up to 25 bags per minute. Utilizes preformed polyethylene bags perforated at break, and fan folded in box . Bag size range: 8" – 24" L x 7" – 13" W. Equipped with 15" W seal jaw, open bag detection prior to loading. High integrity seals reduce chance of product loss. Product is loaded thru top mounted funnel , fabricated per apllication. Automated fillers can be mounted or can manual fill. Equipped with imprinter for data coding and NEMA 4X enclosures.

OAD: 68"L x 50"W x 50"H

Get a Free Quote Call: 630-629-9900

Jaguar Packaging Inc Sealer Bag Impulse M3000

Single Head, automatic bag sealer for pre-made wicketted bags speeds up to 25 bpm, per head (depending application). Can handle bag widths from (3" to 8") and can be intrigated with net weigh, combination scale, augers, counters, rotary fillers, liquid fillers, or hand load operations. Incorporates the "positive claw" mechanism the bag is opened, and injected with twin air jets, and a diving chute enters top bag section protecting the seal area as the bag fills. Filled bags are transported to the seal section, and impulse sealed.

(OAD: 36" L x 36" W x 65" H)
