Seamer Machines

Used Seamer Equipment

Seamer equipment, also known as can seamers are machines designed to seal a lid to a metal or composite can. A seamer machine creates a continuous seam between the lid and the can, hence the name can seamer.

Seamer machines apply a lid to the can. (A semi-automatic seamer requires an operator to apply the lid to the can, but the seaming portion of the operation is similar to an automatic seamer.)

A rotary seaming head will then grip both the side of the can and the lid. As the seaming head rotates about the can and the lid, the tooling in the seaming head compresses both the lid material and the can material together to form a continuous seam around the can and the lid.

Seamers are tooled to handle a specific can size. The proper tooling needs to be installed to change the size can that will be seamed by a seamer. Output or speed is related to the number of heads on the seamer. The greater the number of heads, the greater the output or speed.

Contact Us

Seamer Equipment In Stock

Canco Seamer 1 Head 006VAC

  • Manufacturer: Canco
  • Model Number: 006VAC
  • Frain Number: 5E5297

Canco Model 006VAC, automatic, single head, vacuum can seamer. Rated from 10 to 45 cans per minute – depending on materials and application. Can size range: 202 to 404 in Diameter x 2-7/8" to 5-5/8" in Height, and special from 1-7/16" to 7" in Height with proper change parts. Equipped with (4) roll, double seam, single seaming head, can star wheel infeed, no-can / no-lid, embossed lid marker block type, vacuum regulator, central lubrication system, control box with start, e-stop buttons, 5 hp motor drive. Mounted on 34" x 34" cast iron common base frame with 34" high in feed, and discharge conveyors. Change parts required to accommodate size range. Currently set up for 211 diameter can.

OAD: 54′ L x 48" W x 76" H

Get a Free Quote Call: 630-629-9900

Canco Seamer 1 Head 006VAC

  • Manufacturer: Canco
  • Model Number: 006VAC
  • Frain Number: 5E5292

Canco Model 006VAC, automatic, single head, vacuum can seamer. Rated from 10 to 45 cans per minute – depending on materials and application. Can size range: 202 to 404 in Diameter x 2-7/8" to 5-5/8" in Height, and special from 1-7/16" to 7" in Height with proper change parts. Equipped with (4) roll, double seam, single seaming head, star wheel infeed, rotary can topper with (6) solid 5" dia topping disc’s on 6" centers, no-can / no-lid, embossed lid marker block type, vacuum regulator, central lubrication system, control box with start, e-stop buttons. Mounted on 34" x 34" cast iron common base frame with 34" high in feed and discharge conveyors. Change parts required to accommodate size range. Currently set up for 311 diameter can.

OAD: 54" L x 48" W x 78" H

Get a Free Quote Call: 630-629-9900

Continental Can Seamer 4 Head 334CRP4

Continental Can Model 334CRP4, automatic, 4 head, nitrogen flush can seamer rated from 100 to 250 containers per minute – depending on materials and application. Container size range: 202 to 404 in Diameter; 104 to 708 in Height, with proper change parts. Equipped with 12" long worm screw to 24" long lugged chain infeed conveyor set on 6" centers no-can / no-lid, 24" long lid magazine, (4) double roll seaming heads with 6 pocket star wheel discharge. Central lubrication system, nitrogen flush with Lexan enclosure. Change parts required to accommodate size range. Currently set up for 401 diameter can.

OAD: 82" L x 52" W x 80" H

Get a Free Quote Call: 630-629-9900

Panama Seamer 4 Head PDS-0

  • Manufacturer: Panama
  • Model Number: PDS-0
  • Frain Number: 5F5250

Panama Model PDS-0, automatic, four head, nitrogen flush can seamer rated from 10 to 40 containers per minute – depending on materials and application. Can size range: 202 to 603 in Diameter; 214 to 700 in Height, currently set for 401 in Diameter x 308 in Height. Equipped with worm screw to disc infeed, no-can / no-lid, 20" long lid magazine, 4 roll seaming head, discharge arm, central lubrication system, nitrogen flush, with lexxan enclosure. Mounted on (4) leg base frame.

OAD: 76" L x 56" W x 80" H

Get a Free Quote Call: 630-629-9900

Canco Seamer 1 Head 006

  • Manufacturer: Canco
  • Model Number: 006
  • Frain Number: 5F5109

Canco Model 006, Automatic, heavy duty, single head, can seamer. Rated from 20 to 60 containers per minute – depending on materials and application. Can size range: 202 to 401 in Diameter x 214 to 510 in Height and up to 900 in Height all with proper change parts. Equipped with (4) roll, double seam, single seaming head, with star wheel to lugged chain container in feed, hand crank adjustable height, no-container / no-lid, central lube system. Mounted on 32" x 34" cast iron common base frame with 34" in feed and discharge height. currently set up for 307 Diameter container.

Coder
AVAIALABLE AT ADDITIONAL COST

OAD: 60" L x 48" W x 77" H

Get a Free Quote Call: 630-629-9900

Angelus Seamer 4 Head 40P

  • Manufacturer: Angelus
  • Model Number: 40P
  • Frain Number: 5C7981

Angelus 40P, Automatic 4-head rotary disc-feed can seamer rated up to 275 cans per minute – depending on materials and application. Can size ranges: 202 – 404 in Diameter; 108 – 700 in Height (requires proper change parts). Last ran 301 x 601 composite cans in a food operation.
OAD: 84” L x 60” H x 84” H

Get a Free Quote Call: 630-629-9900
