Consolidated / Pneumatic Scale Machines


Consolidated / Pneumatic Scale Machines In Stock

Urschel Laboratories Inc Cutter, Slicer Chopper/Processor TG1631 Urschel Laboratories Inc Cutter, Slicer Chopper/Processor TG1631 Consolidated / Pneumatic Scale Capper 8 Head of More TG1631

Urschel Model RA, stainless steel dicer / slicer for a variety of food products. Volumes per hour dependant on materials, application and machine configuration. Size range: 1/16" to 3/8" Slicing Knife; 1/8" to 1" Circular Knife; 0.05" to 3" Crosscut Knife. Accepts products up to 3-1/2" in any dimension. Equipped with feed hopper, discharge chute and lift off safety guarding. Able to "strip cut" with removal of crosscut knife. Change parts required per application. Change parts required to accommodate size range.

OAD: 36" L x 44" W x 66" H

Get a Free Quote Call: 630-629-9900

Hamilton Kettle Double Motion D6F Hamilton Kettle Double Motion D6F Consolidated / Pneumatic Scale Capper 6 Head (Capper) D6F

Hamilton Model SA150, 150 gallon, 304 stainless steel, dual motion kettle, APV Model R4R PD pump, and A/B control package. Kettle dimensions: 41" ID x 32" in Depth. Equipped with, 5 Hp bridge mounted scrape surface agitation and 1.5 Hp secondary christmas tree mixer, dual flip top latch down covers, 1/2 jacket with MAWP of 125 psi @ 345 Deg F and (2) 2" OD threaded jacket in/outlets Dish bottom has 2-1/2" OD center bottom discharge with16" floor clearance and (3) legs mounted on 85" long x 51" wide metal skid and APV R4R PD rotary transfer pump with 5 Hp motor drive. Control panel has Allen Bradley controller with vari speed controls and heater, scrappers, pump on / off switches, with temperture controller. National Board # 5727 and UL rated.

OAD: 85" L x 51" W x 84" H

Get a Free Quote Call: 630-629-9900

Consolidated / Pneumatic Scale Capper Fitment Applicator HOF

Automatic snap capper capable of 20 to 200 containers per minute. Equipped with 3-1/4" conveyor, cap hopper, pin wheel sorter, air assist cap chute and star wheel container handling components.

OAD = 108" L x 40" W x 96" H

Get a Free Quote Call: 630-629-9900

A & B Process Systems Cleaner CIP/COP D4FA A & B Process Systems Cleaner CIP/COP D4FA Consolidated / Pneumatic Scale Capper Chuck D4FA

A & B Process Systems, stainless steel, CIP system with rates per hour – depending on materials and application. Equipped with (3) Sani-Fab 32" OD x 56" straight wall, 200 gallon stainless steel single wall tanks (1) for caustic, (1) for acid and (1) for rinse all have flat tops with man ways and flip up covers, top return ports and top mounted agitation. Slant side bottoms with end bottom discharges and 9" ID x 60" long single tube heat exchanger. System has all stainless steel piping and sanitary couplings, with flow rate and pressure control valves. Control Panel with A/B PLC, A/B touch pad controls with panel view, e-stop and status light. Mounted on (8) leg stainless steel base frame.

OAD: 168" L x 55" W x 101" H

Get a Free Quote Call: 630-629-9900

Adco Manufacturing Inc Case Set-Up, Tray Tray Glue 6HD Adco Manufacturing Inc Case Set-Up, Tray Tray Glue 6HD Consolidated / Pneumatic Scale Capper 6 Head (Capper) 6HD

Adco, Model AFCX-30-7-EC, automatic, dual head top load tray former with hot melt glue sealer, rated from 5 to 30 cycles per minute each head – depending on materials and application. Tray size range: 3" to 17" in Length; 3" to 16" in Width: ¾" to 4½" in Height – depending on blank format. Capable of handling flat blank sizes up to 20" in Length and 18" in Width. Equipped with dual 23" long blank tray magazine, dual vacuum suction cup recipicating pick-in-place’s, dual mechanical tray forming heads, no tray / no form photo eyes and Nordson hot melt glue system with interlock safety guarding. Control panel switch controls for carton pick, glue guns, jog / run and speed. Push button start, stop and e-stop. Mounted on heavy duty base frame with leveling legs.

Get a Free Quote Call: 630-629-9900

Consolidated / Pneumatic Scale Capper 6 Head (Capper) D6-F

Consolidated Model D6-F, automatic, 6 head rotary chuck capper rated from 24 to 180 containers per minute – depending on materials and application. Cap size: up to 100mm. Container Size: up to 5" in Diameter both with proper change parts. Equipped with 150" long x 3¼" wide container conveyor with 24" long worm screw to star wheel container indexing, cap hopper, disc cap sorter, feed chute, cap pick off, no container / no cap, 16" OD rotary turret with safety guarding, double container grippers and (6) torque open chucks set on 8" centers. Controller has start, stop, e-stop push buttons with elevator and cap auto, off, manual control switches, counter and statis light bar Mounted on heavy duty base frame.

OAD: 150" L x 40" W x 91" H

Get a Free Quote Call: 630-629-9900

Federal Filler Liquid Monoblock C4F Federal Filler Liquid Monoblock C4F Consolidated / Pneumatic Scale Capper Chuck C4F

Federal, automatic, stainless steel, monoblock system with 64 head rotary gravity filler and 32 head rotary press on capper. Rated from 100 – 500 containers per minute – depending on materials and application. Equipped with __" long x 4½ wide container conveyor has worm screw to star wheel in feed and discharge, 70" turrett with (64) 1" OD fill to level nozzles, set on 3¼" centers with 6" long x 3" wide container platforms and 70" OD product holding tank. 32 head rotary capper with (32) press on style cap heads set on 3¼" centers. Mounted on stainless steel base frame.

OAD: 154"L x 100"W x 95"H

Get a Free Quote Call: 630-629-9900

Feldmeier Tank SS JKT 8 HEAD Feldmeier Tank SS JKT 8 HEAD Consolidated / Pneumatic Scale Capper 8 Head of More 8 HEAD

Feldmeier, 300 gallon working capacity, 304 stainless steel jacketed and insulated tank. Vessel dimensions: 48" diameter x 52" deep with slant bottom. Equipped with a 24" x 16" manway with flip up cover, (2) level sensors, 44" x 2" sight glass and 3 Hp top mounted prop agitator. Unit mounted on (4) legs with a 3½" OD / 3" ID Tri-clamp style front discharge with 15" ground clearance.

Top Ports:
(2) 3½"OD / 3"ID Tri-clamp
(1) 2"OD / 1½" ID Tri-clamp
(1) 4½" Open Vent
(2) ¾" NPT

Jacket Ports:
(6) 1½" NPT

MAWP: 100PSI / FV @ 300°F
MDMT: -20°F @ 100PSI / FV
Nat’l Brd: 5005

OAD: 56"L x 51"W x 118"H

Get a Free Quote Call: 630-629-9900

Northland Stainless Inc Tank Processors C4F Northland Stainless Inc Tank Processors C4F Consolidated / Pneumatic Scale Capper 4 Head (Capper) C4F

Northland Stainless Steel Inc, 250 Liter, 66 gallon, 316 stainless steel, jacketed, internal pressure rated mixing kettle. Vessel dimensions: 19" ID x 56" deep Equipped with dome top, 12" ID bolt down man way has top flange mounted prop style mixer with 9" OD flange with (8) 3/4" bolt holes on 3-1/2" centers and (4) 2-1/2" OD and (1) 3" OD sanitary top ports. Full side and bottom jacket with pressure ratings of: MAWP 150 psi @ 365 Deg F. Full Internal pressure rating of: MAWP 50 psi @ 365 Deg F with (2) 1-1/2" ID, side and (1) 1-1/2" ID threaded bottom jacket in / outlets. Dish bottom has 3" OD staintary center bottom discharge with 16" floor clearance without and 10" floor clearence with valve and is mounted on (3) stainless steel legs.
National Board # 846

OAD: 40" L x 30" W x 75" High

Get a Free Quote Call: 630-629-9900

Consolidated / Pneumatic Scale Capper 4 Head (Capper) C4F

Consoilidated Model CF4, automatic, 4-head rotary, chuck capper, with cap sorter and feeder, rated from 40 to 120 containers per minute – depending on materials and application. Maximum cap size: 70mm, Maximum container height: 9". Equipped with integrated cap feeder and hopper, with disc unscrambler cap chute and button, 85" long x 2-1/2" wide belt conveyor with star wheel in feed and discharge, no container / no cap and (4) torque open chuck cap heads set on 9" centers with double grip container handling. Control panel has CPU controller with cap sorter, capper and turret speed controls, sorter and machine manual, on / off, automatic switch.

OAD: 90" L x 42" W x 82" H

Get a Free Quote Call: 630-629-9900

Consolidated / Pneumatic Scale Capper 6 Head (Capper) D6FA

Consolidated Model D6FA, automatic 6 head rotary chuck capper rated from 24 to 180 containers per minute – depending on materials and application. Cap size: up to 70mm and Container Size: up to 5" in Diameter (with proper change parts). Equipped with cap sorting feeding with feed chute, cap pick in place, 72" long container infeed conveyor with a 32" long timing screw, star wheel, container clamps, no container cap discharge chute, star wheel discharge, and a 36" long discharge conveyor.

OAD: 120" L x 52" W x 108" H

Get a Free Quote Call: 630-629-9900

Axon Capper Neck Bander TG-4-15 Axon Capper Neck Bander TG-4-15 Consolidated / Pneumatic Scale Capper 4 Head (Capper) TG-4-15

Axon Model EZ-300, automatic, tamper evident shrink neck bander or sleeve label applicator rated from 10 to 60 sleeves or 10 to 70 neck bands per minute – depending on materials and application. Layflat: 100 mm to 300 mm. Maximum container Diameter: 7.38". Film thickness: 50 to 70 microns. Equipped with vertical perforation, knife film cut off, touch pad controller with LED display on/off switch with e-stop, statis light bar and mounted on 46" x 40" stainless steel base frame. Film specifications: 15" in diameter on 3" OD core.

OAD: 46" L x 40" W x 86" H

Get a Free Quote Call: 630-629-9900
