Photo of Cornell Mixer Paste Horizontal D26

Cornell Mixer Paste Horizontal D26

  Back to All Equipment

Cornell Model D26 "Versator" rated from 5 to 125 gallons of product per minute – depending on materials and application. All stainless steel contact parts. Equipped with 26" ID product rotating disc, with (2) 2-1/2" OD / 2-1/4 ID side chamber in feed and discharge product ports, (1) 3-1/4" OD / 3" ID top vacuum port, with pressure gauge and 2" OD bottom drain. Swing open clamp down door has 7" OD, flanged front port with (6) 3/4" bolts on 3" centers and 3" OD sight port with 25 Hp belt to motor drive. Side mounted 40" High x 8"OD product tank with 14" x 14" x 24" conical product feed hopper system with independent motor drive. Control panel has main machine and vacuum on / off switches. System is mounted on 72" long x 70" wide platform style frame.
Operation: Product flows thru film forming ring out and then over the surface of rotating disc where the dispersion, deaeration or defoaming action occurs.

OAD: 72" L x 70" W x 76" H
