Bliss case erectors or bliss box case erectors are designed to erect bliss boxes or bliss cases. Bliss boxes are made from a solid bottom piece that is folded to form two sides, and two additional pieces, which are inserted into the box and attached to the solid bottom piece to form the other two sides. The addition two pieces to form the additional sides of the bliss box are glued into the inside of the solid bottom piece using hot melt glue. Because of the solid bottom piece, bliss box erectors create a case that only has top flats to close and seal once the case has been filled.
SWF, Model 1D5A Bliss-Matic, Automatic, 3-piece bliss case former, hot melt glue sealer, rated from 12 to 35 cases per minute – depending on material and application. Bliss box size range: 9¼" to 31-7/8" in Length; 8" to 20" in Width; 4" to16" in Height. Equipped with 18" long blank case magazine, (3) suction cup vacuum pic n place, single friction feed wheel, internal flange closer, Nordson hot melt glue system with pattern controller and integrated vacuum system. Control panel has run / jog, manual / auto and vacuum on / off switches with start / e-stop buttons. Mounted on heavy duty frame with cage style safety guarding.
OAD: 96"L x 70"W x 107"H
W E Plemens Model Bliss, automatic, bliss box former, hot melt glue sealer rated from 10 to 35 boxes per minute – depending on material and application. Case size range: 9-1/4" to 31-7/8" in Length; 8" to 20" in Width; 4" to16" in Height. Equipped with 36" long top blank case magazine, 4 vacuum suction cup recipercating pick n place, center guide roller, (2) 48" long side blank feed magazine, forming mandrel (2) gun hot melt glue system. Control panel has hand, auto, run, jog, auto, off on / off switches with start / stop push buttons and statis light bar. Mounted on heavy duty base frame with safety guarding.
OAD: 76" L x 94" W x 100" H
SWF Model BF 400VK, Automatic, 3-piece bliss case former and hot melt glue sealer. Rated from 12 to 35 cases per minute – depending on material, application and machine configuration. Bliss case size range: 9¼" to 32½" in Length; 9" to 18" in Width; 4" to 16" in Height. Equipped with 146" long powered top blank magazine and (2) 46" long side blank magazines, (4) suction cup vacuum pic n place, single friction feed wheel, Nordson hot melt glue unit with pattern control and vacuum system. Control panel has A/B controller with run / jog, manual / auto and vacuum on / off switches, start / e-stop buttons and cage style safety guarding with statis light bars. Mounted on heavy duty base frame.
OAD: 167" L x 73" W x 140" H
SWF Model BF400V, 3-piece hot melt glue, bliss case former and sealer rated from 12 to 35 cases per minute – depending on materials and application Case Size Range: 9-1/4" to 35-7/8" in Length; 8" to 20" in Width; 4" to 16" in Height. Equipped with 24" top blank case magazine and (2) 48" long side blank case magazines, (6) suction cup vacuum pic n place, single friction feed wheel, Nordson hot melt glue unit with pattern controller and vacuum system. Control panel has A/B controller with touch pad controls and panel view, vari speed controllers, with run / jog, manual / auto and vacuum on / off switches, start / e-stop push buttons and cage style safety guarding with status light. Mounted on heavy duty frame.
OAD: 108" L x 76" W x 115" H
SWF Model BF 400VK, Automatic, 3-piece bliss case former and hot melt glue sealer. Rated from 12 to 35 cases per minute – depending on material, application and machine configuration. Bliss case size range: 9¼" to 32½" in Length; 9" to 18" in Width; 4" to 16" in Height. Equipped with 146" long powered top blank magazine and (2) 46" long side blank magazines, (4) suction cup vacuum pic n place, single friction feed wheel, Nordson hot melt glue unit with pattern control and vacuum system. Control panel has A/B controller with run / jog, manual / auto and vacuum on / off switches, start / e-stop buttons and cage style safety guarding with statis light bars. Mounted on heavy duty frame.
SWF, Model 1D5AK, Automatic, 3-piece, bliss case former, hot melt glue sealer, rated from 12 to 35 cases per minute – depending on material and application. Bliss box size range: 9¼" to 31-(7/8)" in Length; 8" to 20" in Width; 4" to16" in Height. Equipped with 18" long top blank case magazine, (2) adjustable 45" long side bliss end magazines, (6) suction cup vacuum pic n place, single friction feed wheel, internal flange closer, Nordson hot melt glue system with pattern controller and integrated vacuum system. Control panel has run / jog, manual / auto and vacuum on / off switches with start / e-stop buttons. Mounted on heavy duty frame with cage style safety guarding.
OAD: 80" L x 114" W x 140" H
Moen Model PF106HLV, automatic, vertical, "H" style bliss former rated from 10 to 23 cases per minute – depending on material and application. Can run in conjunction with standard "RSC" case or "H" style bliss box formers. Case size range: 9" to 25" in Length; 8" to 25" in Width; 4" to 16" in Depth. Equipped with 48" long x 24" wide blank body wrap magazine with (6) suction cup pic n place, 72" long x 24" wide blank insert magazine, with (3) wheel feed system, die compression section, (4) sided forming station, pneumatic single ram arm, Nordson hot melt glue system with 42" long case discharge conveyor. Control panel has A/B controller and touch pad controls with start, stop, e-stop, safety guarding and statis light bar.
OAD: 180" L x 60" W x 102" H
W E Plemens, Model Bliss. automatic, bliss box former, hot melt glue sealer rated from 10 to 35 cases per minute – depending on material and application. Case size range: 9-1/4" to 31-7/8" in Length; 8" to 20" in Width; 4" to16"in Height. Equipped with blank case magazine, 6-cup vacuum pick n place, center guide roller, (2) side blank feed magazine, forming mandrel (2) glue hot pots with temperature controllers vacuum system, start and e-stops controls.
OAD: 71"L x 60"W x 94"H
Wexxar Model ABH, Automatic, hot melt glue, "bliss" style tray former rated up to 35 trays per minute – depending on materials and application. Tray size range: 11" to 24" L x 8" to 20.5 " W x 4" to 12" H, has top 54" L x 19" W and (2) side 48" L x 11" W blank tray magazines, with vacuum pick – n -place, center guide rollers, forming mandrel, and a Nordson glue system. with 21" tray discharge height. Control panel and mechanical drive with start / stop, glue, magazine, jog, cycle, on /off control switches, with e-stop. Mounted on heavy duty frame with casters and leveling legs.
OAD: 103" L x 60" W x 100" H
Wexxar Model ABH, Automatic, hot melt glue, "bliss" style tray former rated from 10 to 35 trays per minute – depending on material and application. Tray size range: 11" to 24" L x 8" to 20.5" W x 4" to 12" H, has top 54" L x 19" W, and (2) side 48" L x 11" W blank tray section magazines, with vacuum pick – n -place, center guide rollers, forming mandrel, has 21" tray discharge height, with Nordson hot melt glue system. Control panel with mechanical drive, start / stop, glue, magazine, jog, cycle, on / off control switches and e-stop. Mounted on heavy duty frame with leveling legs.
