Twin Shell Machines

Used Twin Shell Equipment

Twin shell powder mixers or twin shell blenders are designed to mix solids to solids, or solids to liquids. Twin shell blenders have two connected blending shells that are connected to form a V-shape. The V-shape of a twin shell blender results in more efficient blending. As the twin shell blender rotates and the V-shape is upside down, the product is divided into to equal or unequal volumes (depending on the design of the twin shell blender). As the twin shell blender rotates so that the V-shape is right side up, the product in both ends of the V accelerate towards the point of the V resulting in the impact of the two masses of product and increased product mixing due to the addition forces of the impact. V-shaped twin shell blenders can be outfitted with a rotating intensifier bar or liquids / solids bar. Intensifier bars are designed to break up clumps of solids while the product is separated in the two ends of the V (when the twin shell blender is upside down).

Contact Us

Twin Shell Equipment In Stock

Patterson Kelley Mixer Powder Twin Shell 1 FT³

Patterson Kelly, 1 ft³, stainless steel, twin shell mixer. Rated to 60 lbs per ft³ and Ibs per hour – depending on materials, application and machine configuration. Equipped with (2) 10" ID product ports with quick release pin covers, (2) 17" long side V-Walls and (2) 6" long inner V-Walls and liquid solids bar. Shell rotation powered by 1 hp motor drive and liquid solids bar powered by a 2 hp motor drive. 8½"OD / 6½"ID flanged discharge with 43" ground clearance. Requires 72" ceiling clearance with 15" swing radius / 30" swing diameter. Control panel, has start / e-stop and reset push buttons and run/jog control switch. Mounted on stainless steel base frame with casters and lexan guarding.

OAD: 53" L x 46" W x 68" H

Get a Free Quote Call: 630-629-9900

Patterson Kelley Mixer Powder Twin Shell 2 FT³

Patterson Kelly, 2 ft³, stainless steel twin shell mixer. Rated up to 60 lbs per ft³ – depending on materials and application. Equipped with (2) 11" ID product ports with bolt down covers, 22" long side V-Walls and 8" long inner V-Walls, 4"ID butterfly valve discharge with 21" ground clearance and powered by a 1 HP drive. Requires 61" ceiling clearance with a 20" swing radius / 40" swing diameter. Mounted on painted base frame.

OAD: 58"L x 20"W x 53"H

Get a Free Quote Call: 630-629-9900

Patterson Kelley Mixer Powder Twin Shell 1.6 CU

Patterson Kelly stainless steel twin shell mixer, with pounds of product per hour – depending on materials and application. 1.6 cu ft maximum working capacity; rated at 140 lbs per cu ft bulk product density. Blender dimensions 17" Long outer side walls, 7" Long top inner side walls, 24" across top end to end, stainless steel contact parts with stainless steel liquid solids bar and (2) 10" diameter product ports with covers. Has 15" floor clearance. Unit is enclosed inside safety cage guarding and mounted on (6) leg base frame.

OAD: 61"L x 40"W x 61"H

Get a Free Quote Call: 630-629-9900

Patterson Kelley Mixer Powder Twin Shell 20 CU FT

Patterson Kelly, 20 ft³ working capacity, twin shell, v-blender. Vessel dimensions: 30" in Diameter; 52" slant sections. Product density: 60 lbs/ ft³. Equipped with two 17" diameter top inlet ports, intensifier bar with 7.5 hp drive, and a 7" ID bottom discharge with butterfly valve and 5" of ground clearance. Swing Diameter: 88", maximum swing height: 93" .

OAD: 122" L x 41" W x 80" H

Get a Free Quote Call: 630-629-9900

Patterson Kelley Mixer Powder Twin Shell 8QT

Patterson Kelly, 8 Quart, stainless steel table top twin shell mixer. Bulk product density – 140 lbs/ft³. Blender dimensions: 14" long outer side walls, 7.5" diameter product ports with screw down covers, liquid solids bar, 9" swing radius and a 2" wide by 4" long oval shaped bottom discharge port with 8" table clearence.

OAD: 32" L x 27" W x 31" H

Get a Free Quote Call: 630-629-9900

Patterson Kelley Mixer Powder Twin Shell 1 CU FT

Patterson Kelly 1 cubic foot, stainless steel twin shell mixer with maximum product density rated to 60 lbs per cubic foot. Equipped with (2) 10″ charge ports with clamp down vented covers, 6″ diameter butterfly discharge with 41″ discharge height, intensifier bar, 18″ swing radius,stainless steel guard package with safety interlocks. Control panel with blend timer, intensifier timer, start/stop, and pre-intensifier timer. Mounted on stainless steel base frame with 8″ locking casters.

OAD: 58″L x 48″W x 77″H

Get a Free Quote Call: 630-629-9900

Patterson Mixer Powder Twin Shell .5 / 1 QT

  • Manufacturer: Patterson
  • Model Number: .5 / 1 QT
  • Frain Number: R26100

Patterson Kelly, .5QT / 1QT, stainless steel, table top dual twin shell mixer. Max bulk product density is 500 lbs/ft³. Blender dimensions: (1) 8" long outer side walls, 3" inner side wall, 3.75" diameter product ports with screw down covers. (1) 6" long outer side walls, 2" inner side wall, 2.5" diameter product ports with screw down covers. Unit has a 10" swing radius and is powered by a 1/4hp drive.

OAD: 31" L x 24" W x 19" H

Get a Free Quote Call: 630-629-9900

Patterson Kelley Mixer Powder Twin Shell 8 QUART

Patterson Kelly, 8 Quart, stainless steel, table top twin shell mixer, bulk product density – 340 lbs/ft³. Blender dimensions: 12" long outer side walls, 7-1/2" diameter product ports with screw down covers, 8" swing radius, 1-3/4" wide by 4" long oval shaped bottom discharge port with 8" table clearence.

OAD: 31" L x 21" W x 26" H

Get a Free Quote Call: 630-629-9900

Patterson Mixer Powder Twin Shell 10 CU FT

  • Manufacturer: Patterson
  • Model Number: 10 CU FT
  • Frain Number: R26105

Patterson Kelly, 10 ft³, stainless steel, twin shell powder mixer. Blender dimensions: 24" diameter x 36" straight wall. Bulk density rating: 90 lbs/ft³. Equipped with two 18" diameter inlets with bolt down covers, push button control panel, automatic motor break and an 8" diameter center bottom butterfly valve discharge with 39" of ground clearance. Mounted on a two leg frame with a 99" maximum swing height and a 36" swing radius / 72" swing diameter.

OAD: 100"L x 45"W x 95"H

Get a Free Quote Call: 630-629-9900

Ability Fabricators Inc Mixer Powder Twin Shell 30 CU FT.

Ability Fabricators 30 cubic foot, 304 stainless steel twin shell mixer with maximum product density rated to 55 lbs per cubic foot. Equipped with (2) 18" charge ports with removable vented covers, 16" diameter butterfly discharge with 51" discharge height, liquids/solids bar, 35" swing radius. Mounted on stainless steel base frame.

Bar driven by 7.5HP motor, 575V, 3Ph, 60Hz with Stearns brake
Shell driven by 5.3HP geardrive, 330/575V, 3ph, 60Hz

OAD: 165"L x 74"W x 125"H

Get a Free Quote Call: 630-629-9900

Patterson Kelley Mixer Powder Twin Shell LSB

Patterson Kelly, 8 Quart, stainless steel, table top twin shell mixer, bulk product density – depending on materials and application. Blender dimensions: 14" long outer side walls, 6" long top inner side walls, 14" across top center and (2) 7-1/2" diameter product ports with screw down covers, 3" x 1-1/2" OD bottom discharge port with 8" table clearence.

OAD: 30" L x 19" W x 25" H

Get a Free Quote Call: 630-629-9900

Ohara Mixer Powder Twin Shell VB5

  • Manufacturer: Ohara
  • Model Number: VB5
  • Frain Number: R25410

Ohara, Model V65, 5 cu ft, stainless steel, twin shell mixer, rated up to 50 lbs per cu ft bulk or 245 lbs total product density with number of pounds of product per hour – depending on materials and application. Blender dimensions: 36" long outer side walls, 11" long top inner side walls, 30" across top center and (2) 24" diameter product ports with bolt down covers, can be fitted with intensifier bar 12" OD flangled, with (8) 5/8" bolt holes on 4" centers with 6" OD manual butterfly valve with 40" floor clearance. Control panel has start / stop push button controls for intensifer and bowl with timer, e-stop and lexan safety guarding. Mounted on (4) leg stainless steel base frame with casters.

OAD: 72" L x 60" W x 82" H

Get a Free Quote Call: 630-629-9900
