Frain Industries can help you with your fold wrapper or bunch wrapper project no matter how big or small your wrapping needs. Fold wrapper or bunch wrapper equipment and machines fold or bunch the loose ends of the film packaging around the product.
Rasch, Model RUBESTZ, Semi automatic, intermittent motion, bottom fold, foil wrapping machine with number of wraps per minute – depending on materials, application and machine configuration. Equipped with 20¾" OD, 18 pocket hand loaded product disc, 8" wide dual foil film unwind rolls with foil cut-off section and has a product pusher bar thru the cut foil, 8 sets of rotary horizontal product grippers to intermittent motion bottom foil folding section and 32" long x 2" wide product discharge conveyor. Mounted on base frame with casters and leveling legs.
OAD: 71"L x 70"W x 62"H
Sapal Model BB, Automatic, 1 or 2 material, wrapper rated from 20 to 180 packages per minute on plain rectangular bar and 20 to 140 packages per minute on filled rectangular bars or bars with nuts – depending on materials and application. Package size range: 90mm (3.54") to 195mm (7.68") in Length; 30mm (1.18") to 95mm (3.74") in Width; 5mm (0.19") to 16mm (0.63") in Height. Equipped with 60" long Neoprene in feed product conveyor with adjustable guide rails, shuttle transfer section, inner wrapping reel, outer wrapping stack, folding section, hot melt glue system, vertical transfer and 2 chain lugged compression section with 24" long discharge with side wiper brushes. Control panel has Siemens controller with LED display and statis lights with safety guarding. Mounted on heavy duty forkable frame.
OAD: 111"L x 72"W x 68"H
Rose FICH, Fully automatic, high speed, forming / cutting / wrapping machine for double point end fold rated from 400 to 1000 pieces per minute – depending on materials and application. Product: length 25 – 45mm, width 12- 25mm, thickness 5 -15 mm. Features three forming wheels with selector switch adjustments, heat seal station, and dual lane walking beam heated outfeed. Equipped with Allen Bradley SLC 5/01 CPU controller, Reliance Electric AC drive controller, stand alone control panel, E-stop, status indicator light, cherry / orange / strawberry / lemon indicator, auto vbr drive control, photoeyes for product presence, wrapping film reel up to 3"W by up to 14" diameter, and controls for F1 paper (start / stop) and H1 paper (start / stop). Right angle machine with painted steel frame. Last running 21mm long x 21mm wide x 10mm thick Starburst candy in a 69mm (2 3/4") wide x 90mm (3.5") long wrapper.
OAD: 70"L x 62"W x 73"H
Sapal DP-3, Dual lane, intermittent motion, (2) lane, horizontal wrapper rated from 100 to 400 packages per minute – depending on materials, application and machine configuration. Product size range: 3/8" to 2" in Length; 3/8" to 1-3/4" in Width; up to 3/4" in Height. Equipped with (2) film unwind reels one per side, automatic film splicer, in feed conveyors and discharge conveyors with air reject and diverter gates. Remote control panel has A/B PLC with dataliner, film registration, status light bars, photo eye, film presence, end of roll and paper rip sensors, safety guarding with electrical interlock. Mounted on heavy duty frame with locking casters.
OAD: 112" L x 36" W x 85" H
Rasch Model RK, automatic, intermittent motion, foil wrapping machine with number of wraps per minute – depending on materials, application and machine configuration. Capable of handling pralines or bars and round flat shaped bottom folds, pralines or bars end twist and end folds of most sizes and shapes, also egg shape. Equipped with 60" long x 3-1/2" wide product in feed conveyor, automatic product loader into 18" OD, 26 pocket product disc, 8" wide dual foil film unwind rolls with foil cut-off section, with form and fold section with 84" long x 2" wide product discharge conveyor. Control panel has A/B controller with start, stop, jog, centering and vari-speed controls with e-stop, status light bar and interlock safety guarding. Mounted on epoxy coated base frame. Change parts required to accommodate size range.
OAD: 132" L x 70" W 64" H
Rasch Model RU, Semi-automatic, intermittent motion, bottom fold, foil wrapping machine with number of wraps per minute – depending on materials, application and machine configuration. Capable of handling pralines or bars and round flat shaped bottom folds, pralines or bars with end twist or end folds of most sizes and shapes, also egg shape. Equipped with 21" OD, 16 pocket hand loaded product disc, 8" wide dual foil film unwind rolls with foil cut-off section, product pusher bar thru cut foil, 8 sets of rotary horizontal product grippers to intermittent motion bottom foil folding section and 70" long x 5" wide product discharge conveyor with top product tamp Control panel has A/B controller with start, stop, jog, centering and vari-speed controls with e-stop, status light bar and interlock safety guarding. Mounted on epoxy coated base frame. Change parts required to accommodate size range.
Markem Smart Date 5 Coder Available at Additional Cost
OAD: 188" L x 96" W x 83" H
Sapal SC-3-1, Automatic horizontal, foil, and over wrapper rated from 80 to 300 packages per minute – depending on materials, application and machine configuration. Maximum product range: 7-1/2" in Length x 4-3/4" in Width x 1/2" in Height. Equipped with (2) foil, and over wrap film unwinds, (2) foil, and over wrap splice station, registration, knife cutoff for foil and over wrap, (6) dual-rope in feed timing conveyors, lug chain product conveyor 4" centers with 1/2"H lugs. hot melt glue system, 45" Long x 4 1/4" Wide product discharge conveyor with air reject. Remote control panel has Allen Bradley controller with panel view and swing controls with. low film indicator light, overhead arm panel and servomotor drive barrier guarding and statis lights. Mounted on heavy duty frame with height adjustable legs.
OAD: 192" L x 61" W x 81" H
Sapal SC-3-1, Automatic horizontal, foil, and over wrapper rated from 80 to 300 packages per minute – depending on materials, application and machine configuration. Maximum product range: 7-1/2" in Length x 4-3/4" in Width x 1/2" in Height. Equipped with (2) foil, and over wrap film unwinds, (2) foil, and over wrap splice station, registration, knife cutoff for foil and over wrap, (6) dual-rope in feed timing conveyors, lug chain product conveyor 4" centers with 1/2"H lugs. hot melt glue system, 45" Long x 4 1/4" Wide product discharge conveyor with air reject. Remote control panel has Allen Bradley controller with panel view and swing controls with. low film indicator light, overhead arm panel and servomotor drive barrier guarding and statis lights. Mounted on hheavy duty frame with height adjustable legs.
OAD: 115"L x 48"W x 73"H
Rose OH, Fully automatic, high speed, forming / cutting / wrapping machine for double point end fold capable of 400 to 1000 pieces per minute – depending on materials and application. Product: length 25 – 45mm, width 12- 25mm, thickness 5 -15 mm. Features three forming wheels with selector switch adjustments, heat seal station, and dual lane walking beam heated outfeed. Equipped with Allen Bradley SLC 5/01 CPU controller, Reliance Electric AC drive controller, stand alone control panel, E-stop, status indicator light, photoeyes for product presence, wrapping film reel up to 3"W by up to 14" diameter, and controls for F1 paper (start / stop) and H1 paper (start / stop). Right angle machine with painted steel frame. Last running 21mm long x 21mm wide x 10mm thick Starburst candy in a 69mm (2 3/4") wide x 90mm (3.5") long wrapper.
Rose OH.F.SCH, Fully automatic, high speed, forming / cutting / wrapping machine for double point end fold capable of 400 to 1000 pieces per minute – depending on materials and application. Product: length 25 – 45mm, width 12- 25mm, thickness 5 -15 mm. Features three forming wheels with selector switch adjustments, heat seal station, and dual lane walking beam heated outfeed. Equipped with Allen Bradley SLC 5/01 CPU controller, Reliance Electric AC drive controller, stand alone control panel, E-stop, status indicator light, cherry / orange / strawberry / lemon indicator, auto vbr drive control, photoeyes for product presence, wrapping film reel up to 3"W by up to 14" diameter, and controls for F1 paper (start / stop) and H1 paper (start / stop). Right angle machine with painted steel frame. Last running 21mm long x 21mm wide x 10mm thick Starburst candy in a 69mm (2 3/4") wide x 90mm (3.5") long wrapper.
Rose F.SCHM, Fully automatic, high speed, forming / cutting / wrapping machine for double point end fold capable of 400 to 1000 pieces per minute – depending on materials and application. Product: length 25 – 45mm, width 12- 25mm, thickness 5 -15 mm. Features three forming wheels with selector switch adjustments, heat seal station, and dual lane walking beam heated outfeed. Equipped with E-stop, photoeyes for product presence, wrapping film reel up to 3"W by up to 14" diameter, and controls for F1 paper (start / stop) and H1 paper (start / stop). Right angle machine with painted steel frame. Last running 21mm long x 21mm wide x 10mm thick Starburst candy in a 69mm (2 3/4") wide x 90mm (3.5") long wrapper.
