Jones Cartoner Semi Vertical Tuck IMV

• Manufacturer: Jones
• Model Number: IMV
• Frain Number: 5H8620

Jones, Model IMV 5, Semi-automatic, intermittent motion, vertical tuck cartoner. Rated from 10 to 45 cartons per minute – depending on materials, application, machine configuration and operator dexterity. Carton size range: 1" to 4" in Length; ¾" to 2¾" in Width; 2-1/8" to 7" in Depth. Equipped with (2) chains fixed, set on 5" centers, with 26" long blank carton magazine, reciprocating pic-n-place, 48" long operator load area each side, minor flap tuckers and major flap closers. Control panel has start / stop push button controls. Mounted on heavy duty frame with safety door guarding.

OAD: 136"L x 45"W x 65"H

Jones Cartoner Semi Vertical Tuck IMV5

• Manufacturer: Jones
• Model Number: IMV5
• Frain Number: R34560

Jones Model IMV 5, Semi-automatic, intermittent motion, vertical tuck cartoner rated from 10 to 45 cartons per minute – depending on materials, application, machine configuration and operator dexterity. Carton size range: 1" to 4" in Length; 3/4" to 2-3/4" in Width; 2-1/8" to 7" in Depth. Equipped with (2) chains fixed set on 5" centers, with 24" long blank carton magazine, reciprocating pic-n-place, 48" long operator load area each side, minor flap tuckers and major flap closers with self contained vacuum system. Control panel has relay logic controller, with run, jog and vacuum switches, start, stop and e-stop push button controls. Mounted on heavy duty frame with safety door guarding.

OAD: 132" L x 63" W x 61" H

Jones Cartoner Semi Vertical Tuck CMV5

• Manufacturer: Jones
• Model Number: CMV5
• Frain Number: 5H8130

Jones, Model CMV5, Semi automatic, continuous motion, vertical tuck cartoner rated from 25 to 120 cartons per minute – depending on materials, application and operator dexterity. Carton size range: 1" to 4-1/4" in Length x 1/2" to 4-1/4" in Width x 2-1/2" to 8" in Depth. Equipped with (3) chains adjustable set on 5" centers, blank carton magazine, reciprocating suction cup pick-n-place, 96" long hand load section each side of machine, major and minor flap closers and tuckers with discharge conveyor belt and Lincoln one shot lube system. Control panel has A/B PLC controller with control power and carton feed on and off switches, start and e-stop push buttons. Mounted on heavy duty frame with hinged lexan safety door guarding.

OAD: 263" L x 72" W x 62" H

Jones Cartoner Semi Vertical Tuck CMV5

• Manufacturer: Jones
• Model Number: CMV5
• Frain Number: 5H5844

Jones, Model CMV5, semi automatic, continuous motion, vertical, tuck cartoner. Capable of speeds from 40 to 120 cartons per minute – depending on materials and application. Equipped with (3) chains adjustable set on 5" centers. Carton size range: 1" to 4¼" in Length x ¾" to 4½" in Width x 2½" to 9" D in Depth Equipped with 29" long blank carton magazine with carton pusher, vibratory feeder, reciprocating single head suction cup pick-n-place, 64"L load area each side of machine, 36" long x 4½" wide discharge conveyor belt. Control panel with push button start / stop.

OAD: 171"L x 70"W x 75"H

Jones Cartoner Semi Vertical Tuck IMV5

• Manufacturer: Jones
• Model Number: IMV5
• Frain Number: R32370

Jones Model IMV5, semi-automatic, intermittent motion, vertical tuck cartoner rated from 10 to 60 cartons per minute – depending on materials, application, machine configuration and operator dexterity. Carton size range: 1" to 4" in Length; 3/4" to 2-3/4" in Width; 2-1/2" to 7" in Depth. Equipped with (2) chains set on 5" centers, with 24" long carton magazine, reciprocating pic-n-place, 48" long operator load area each side, minor flap tuckers, major flap closers and self contained vacuum system. Control panel has relay logic controls, hand held controller and foot pedal jog with statis lights. Mounted on heavy duty frame with leveling legs and safety guarding.

Optional item: Emboss Coder

OAD: 135" L x 74" W x 66" H

Jones Cartoner Semi Vertical Tuck CMV5

• Manufacturer: Jones
• Model Number: CMV5
• Frain Number: 5H7171

Jones, Model CMV5, semi automatic, continuous motion, vertical, tuck cartoner, rated from 40 to 120 cartons per minute – depending on materials and application. Equipped with (3) chains adjustable set on 5" centers. Carton size range: 1" to 4¼" in Length x ¾" to 4½" in Width x 2½" to 9" in Depth. Equipped with 29" long blank carton magazine with vibratory feeder and carton pusher, reciprocating single head suction cup pick-n-place, 96" long load area each side of machine,with major / minor flap closers and tuckers and 96" long x 4" wide discharge conveyor belt. Control panel has PLS controller with control power and carton feed on / off switches, start, stop push buttons with e-stop. Mounted on heavy duty frame with safety guarding and statis light.

OAD: 211" L x 58" W x 79" H

Jones Cartoner Auto Horiz. Glue (Auto) CRITERION II

• Manufacturer: Jones
• Model Number: CRITERION II
• Frain Number: 5H7070

Jones Model Criterion II, automatic, horizontal, high speed, servo driven, continuous motion, hot melt glue cartoner, with number of cartons per minute – depending on materials and application. Equipped with (3) chains adjustable set on 15" centers with 5-1/2" high x 1" wide lugs. Carton size range: 2-1/2" to 14" in Length; 3/4" to 4" in Width; 6" to 12" in Depth. Has 142" long total, (3) smart belt product in feed conveying system, with automatic (2) belt blank carton magazine, (2) head rotary carton pic n place, with camera verification system, no product / no carton, barrel cam product loader, with rotary top confiner section, Nordson ProBlue hot melt glue system, major and minor flap closers with Seko gauges and compression section. Control panel has A/B controller and A/B panelview with multiple start, stop, jog, reset and e-stop push buttons sections. Mounted on heavy duty frame with interlock safety door guarding and leveling legs.

OAD: 567" L x 108" W x 85" H

Jones Cartoner Semi Vertical Tuck IMV5 5" Centers, Intermittent, to 60 Cartons Per Minute

• Manufacturer: Jones
• Model Number: IMV5
• Frain Number: 5E0190

Jones IMV5, Semi-automatic, vertical, tuck, cartoner capable of speeds from 30 to 60 cartoners per minute – speeds depending on materials and application. Cartons: (1" – 4")L x (3/4" – 2 3/4")W x (1 3/4" – 7")D. Has 2-chain drive with 5" centers, 3 1/2 " long lugs, 27"L vibratory blank magazine, 1-cup reciprocating vacuum blank pick-off, two 14" long load stations, cam driven right angle carton discharge, E-stop, Electro Cam PLS, programmable controller, drive controller, status indicator lights, changeover size guages, and barrier guarding with electrical interlock. Mounted on casters and set down feet. Leaflet feeder available at additional cost.

OAD: 138"L x 60"W x 76"H

Jones Cartoner Semi Vertical Tuck IMV5 Semi automatic intermittent motion vertical cartoner capable of speeds from 25 to 60 cartons per minute

• Manufacturer: Jones
• Model Number: IMV5
• Frain Number: 5D2864

Jones IMV5, Semi automatic intermittent motion vertical cartoner capable of speeds from 30 to 60 cartons per minute – speeds depending on materials and application. Carton size range: 1"- 4"(L) x 3/4"- 2 3/4"(W) x 2 1/8"- 7"(Depth). Machine is currently set for reverse tuck cartons on 5” centers. Equipped with a PLC, reciprocating pick and place carton feeder & 5′ product load area.

Optional robotic pick and place bottle loader which is available for additional cost.

Optional prefolded leaflet feeder and coder are available for additional cost.

OAD: 148”(L) x 60”(W) x 64”(H)

Jones Cartoner Semi Vertical Tuck IMV5

• Manufacturer: Jones
• Model Number: IMV5
• Frain Number: R31900

Jones Model IMV5, semi automatic, intermittent motion, vertical tuck cartoner rated from 10 to 60 cartons per minute – depending on materials, application and operators dexterity. Carton size range: 1" to 4-1/4" in Length; 3/4" to 4-1/4" in Width; 2-1/2" to 8" in Depth. Equipped with (2) chains fixed set on 5" centers, 24" long blank carton magazine, with reciprocating suction cup pic-n-place, 48" long hand load area on each side, minor flap tuckers, major flap closers, self contained vacuum system. Control panel has panelview with start, stop and e-stop push buttons. Mounted on heavy duty frame with safety guarding.

Hot stamp foil coder available at additional cost.

OAD: 136" L x 60" W x 66" H

Jones Cartoner Semi Vertical Tuck IMV5

• Manufacturer: Jones
• Model Number: IMV5
• Frain Number: R31720

Jones Model IMV5, semi automatic, intermittent motion, vertical bottom glue and top tuck cartoner. Rated from 10 to 45 cartons per minute – depending on materials, application, machine configuration and operator dexterity. Carton size range: 1" to 4" in Length; ¾" to 2¾" in Width; 2¼" to 7" in Depth. Equipped with (2) chains fixed set on 5" centers, 24" long carton magazine, recipicating suction cup pic-n-place, 48" long load area each side, Nordson hot melt glue system with pattern controller, major flap tuckers and minor flap closers. Control panel with on / off switch, variable speed dial and e-stop. Mounted on heavy duty frame with safety guarding.

OAD: 136"L x 57"W x 60"H

Jones Cartoner Semi Vertical Tuck IMV5

• Manufacturer: Jones
• Model Number: IMV5
• Frain Number: 5C6861

Jones IMV5, semi automatic intermittent motion vertical tuck cartoner rated from 20 to 40 cartons per minute – depending on materials, application and machine configurations. Carton size range: 1" to 4" in Length; 3/4" to 2 3/4" in Width; 2-1/8" to 7" in Depth.
Equipped with (2) chain system set on 5" centers, blank carton magazine, reciprocating suction cup pic-n-place, major flap tuckers, and minor flap closers, self contained vacuum system and safety guarding. Mounted on heavy duty base frame.

OAD: 104” L x 60” W x 60” H
