American Film & Machinery Shrink Tunnels WSN-GEN 300 2M

  Back to All Equipment
  • Model: WSN-GEN 300 2M
  • Frain Number: R30721
  • Category: Shrink
  • Subcategory: Tunnels
  • Condition: Used, in excellent condition
  • Availability: In Stock

American Film & Machinery Model WSN-GEN-2M stainless steel, steam shrink tunnel and conveyor with self contained steam generator and number of containers per minute – depending on materials and application. Can handle middle or full body and cap shrink applications with materials of PVC, PETG, OPS and PLA and a wide range of round, square, oval and other irregularly shaped containers. Equipped with 1 zone and 2 tier shrink steam tunnel with 5-1/4" wide x 8" high total aperature x 79" long tunnel with multiple steam zones and adjustable manifold with direct steam heat, 4-1/2" wide x 128" long stainless steel table top product conveyor has 36" in feed and discharge height hand crank adjustable to + / – 2", with A/C vari-speed controller. self contained 20KW electric steam boiler, with 50 psi, internally plumbed and steam pressure controls, drip pan for condensation recovery has a maximum operating temperature of 212° F, with temperature gauge and adjustable manifold for direct steam heat and steam pressure of 3-4 Kg/cm2 with 43 to 57 psi and dual top 3-3/4" OD steam exhaust, hot and cold water in / output ports with consumption rates of 200 litres or 52 gallons an hour. Mounted on stainless steel frame with casters and leveling legs.

OAD: 128" L x 36" W x 53" H
