Feldmeier Tank SS Single Wall 650 GAL

  Back to All Equipment
Get a Free Quote

Feldmeier, 600 gallon capacity, 316 stainless steel single wall jacketed vertical tank. Vessel dimensions: 60" diameter x 70" deep with a 50" straight wall. Equipped with dome top, 18" OD top manway, double motion scrape agitation powered by a 3 hp drive and dixie agitation powered by a 10 hp drive, (2) CIP spray balls supplied by 2"OD / 1½"ID Tri Clamp fitting and flush mount sensor. Cone bottom has 3½" OD / 3" ID tri-clamp center bottom discharge with 14" ground clearance.

Top Access Ports:
(1) 4½"OD / 4"ID Tri-Clamp
(3) 3½"OD / 3"ID Tri-Clamp
(1) 3" diameter open vent

OAD: 65"L x 60"W x 125"H
